1 alignment post 2 processor cover
4 processor
5 processor cover notch
8. Clean the thermal grease from the bottom of the heat sink.
CAUTION:
Ensure that you apply new thermal grease. New thermal grease is critical for ensuring adequate thermal bonding, which is a
requirement for optimal processor operation.
9. Apply the new thermal grease to the top of the processor.
10. Replace the processor fan and heat sink assembly (see
CAUTION:
Ensure that the processor fan and heat sink assembly is correctly seated and secure.
11. Replace the computer cover (see
12. Connect your computer and devices to electrical outlets, and turn them on.
Back to Contents Page
3 release lever
Replacing the Processor Fan and Heat Sink
Replacing the Computer
Cover).
Assembly).
