- Page 1 TESLA K10 GPU ACCELERATOR BD-06280-001_v05 | June 2012 Board Specification...
- Page 2 Removed “Preliminary Information” statement as • May 14, 2012 GG, SM this board specification is no longer considered preliminary Updated title to Tesla K10 GPU Accelerator • Board Specification Updated number of core processors • • Updated Figure 2 and Figure 3...
-
Page 3: Table Of Contents
TABLE OF CONTENTS Overview ................... 1 Key Features ..................1 Tesla K10 Block Diagram ............... 2 Configuration ..................3 Mechanical Specifications ............... 4 PCI Express System ................4 Standard I/O Connector Placement ............5 Internal Connectors and Headers ............. 7 External PCI Express Power Connectors .......... - Page 4 LIST OF FIGURES Figure 1. Tesla K10 Block Diagram ............2 Figure 2. Tesla K10 GPU Accelerator ............4 Figure 3. Tesla K10 Bracket ..............5 Figure 4. Tesla K10 with Bracket .............. 6 Figure 5. Tesla K10 without Bracket ............6 Figure 6.
-
Page 5: Overview
8 GB of GDDR5 on-board memory (4 GB per GPU) and supports PCI Express Gen3. The Tesla K10 can be configured by the OEM or by the end user to enable or disable ECC or error correcting codes that can fix single-bit errors and detect double-bit errors. -
Page 6: Tesla K10 Block Diagram
TESLA K10 BLOCK DIAGRAM Figure 1 is the block diagram for Tesla K10 GPU accelerator. It comprises two identical GK104 GPUs, each with 4 GB of GDDR5 memory. The GPUs are connected via a PCI Express switch. The board supports PCI Express Gen3. -
Page 7: Configuration
Overview CONFIGURATION The Tesla K10 boards are available in the following configurations (Table 1) based on the orientation of the airflow inside the system. Table 1. Board Configurations Specifications Tesla K10 • 900-22055-0010-000: Airflow towards the bracket Generic SKU reference 900-22055-0020-000: Airflow away from the bracket •... -
Page 8: Mechanical Specifications
MECHANICAL SPECIFICATIONS PCI EXPRESS SYSTEM The Tesla K10 boards (Figure 2) conform to the PCI Express full height (4.376 inches by 10.5 inches) form factor. Figure 2 is shown without the bracket. 10.5 inches 4.376 inches Figure 2. Tesla K10 GPU Accelerator Note: The final product will ship with an 8 and 6-pin connector and shroud. -
Page 9: Standard I/O Connector Placement
Mechanical Specifications STANDARD I/O CONNECTOR PLACEMENT As shown in Figure 3, the Tesla K10 includes a vented bracket. If you are an OEM who qualifies for bracket modifications, you have the option of receiving your modules with no bracket installed. -
Page 10: Figure 4. Tesla K10 With Bracket
Slide the washer in between the PCB and the backplate to maintain clearance between the PCB and the backplate. Attach the shoulder screws. Figure 4. Tesla K10 with Bracket Figure 5. Tesla K10 without Bracket Tesla K10 GPU Accelerator BD-06280-001_v05 | 6... -
Page 11: Internal Connectors And Headers
External PCI Express Power Connectors The Tesla K10 GPU accelerator is a performance optimized, high-end product and uses power from the PCI Express connector as well as external power connectors. The board can be used in two different ways. -
Page 12: Figure 6. 6-Pin Pci Express Power Connector
Mechanical Specifications Figure 6. 6-Pin PCI Express Power Connector Tesla K10 GPU Accelerator BD-06280-001_v05 | 8... -
Page 13: Figure 7. 8-Pin Pci Express Power Connector
Mechanical Specifications Figure 7. 8-Pin PCI Express Power Connector Tesla K10 GPU Accelerator BD-06280-001_v05 | 9... -
Page 14: Table 2. 6-Pin Pci Express Power Connector Pinout
6-Pin PCI Express Power Connector Pinout Pin Number Description +12 V +12 V +12 V Sense Table 3. 8-Pin PCI Express Power Connector Pinout Pin Number Description +12 V +12 V +12 V Sense1 Sense0 Tesla K10 GPU Accelerator BD-06280-001_v05 | 10... -
Page 15: Power Specifications
POWER SPECIFICATIONS The Tesla K10 GPU accelerator requires power from the PCI Express connector as well as one or two auxiliary power connectors. Table 4. Configuration with External PCI Express Connectors Connector Type 6-Pin Power Connector Supported Notes 8-pin connected... -
Page 16: Support Information
Conformité Européenne (CE) Federal Communications Commission (FCC) Industry Canada - Interference-Causing Equipment Standard (ICES) Korean Communications Commission (KCC) Underwriters Laboratories (cUL) Voluntary Control Council for Interference (VCCI) Tesla K10 GPU Accelerator BD-06280-001_v05 | 12... -
Page 17: Languages
Chinese, Simplified Chinese, Traditional Danish Dutch Finnish French French (Canada) German Italian Japanese Korean Norwegian Portuguese (Brazil) Russian Spanish Spanish (Latin America) Swedish Thai Note: NVIDIA’s CUDA™ software is only supported in English (U.S.) Tesla K10 GPU Accelerator BD-06280-001_v05 | 13... - Page 18 No license is granted by implication of otherwise under any patent rights of NVIDIA Corporation. Specifications mentioned in this publication are subject to change without notice. This publication supersedes and replaces all other information previously supplied. NVIDIA Corporation products are not authorized as critical components in life support devices or systems without express written approval of NVIDIA Corporation.
