Page 10: Introduction
Introduction Important information About this manual Decals Risk of damage to the vehicle Risk of injury Footnotes G031590 Display texts Doors auto lock...
Page 11 Introduction Important information Information Types of lists used in the manual Bullet lists Procedures Continued Options and accessories NOTE Position lists...
Page 12 Introduction Important information Shiftlock (automatic transmission) NOTE WARNING CALIFORNIA proposition 65 Keylock (automatic transmission) WARNING Anti-lock Brake System (ABS) WARNING Fuel filler door...
Page 13 Introduction Important information Fuel filler cap Vehicle event data (Black box) Points to keep in mind...
Page 14 Introduction Environment Volvo and the environment...
Page 15 Introduction Important warnings Accessory Installation Driver distraction...
Page 18: Safety
01 Safety Occupant safety Volvo's concern for safety Reporting safety defects in the U.S. Occupant safety reminders NHTSA can be reached at:...
Page 19 01 Safety Occupant safety Reporting safety defects in Canada...
Page 20 01 Safety Seat belts Using seat belts NOTE Buckling a seat belt The seat belt retractor will lock up in the fol- lowing situations: Adjusting the seat belt When wearing the seat belt remember: Unbuckling the seat belt Seat belt pretensioners...
Page 21 01 Safety Seat belts Seat belt use during pregnancy WARNING Child seats Seat belt reminder WARNING Seat belt reminder light in ceiling console...
Page 22 01 Safety Seat belts READ regardless of whether or not Seat belt maintenance Rear seats READ READ...
Page 23 01 Safety Supplemental Restraint System Supplemental Restraint System (SRS) WARNING SRS AIRBAG SERVICE URGENT SRS AIRBAG SERVICE REQUIRED WARNING Automatic transmission SRS warning light I II...
Page 24 01 Safety Supplemental Restraint System The front airbag system Location of the passenger's side front airbag SRS AIRBAG...
Page 25 01 Safety Supplemental Restraint System Front airbag deployment WARNING NOTE In the USA...
Page 26 01 Safety Supplemental Restraint System WARNING In Canada Airbag decal on passenger's side dashboard...
Page 27 01 Safety Supplemental Restraint System WARNING WARNING Airbag decal on the outside of both sun visors...
Page 28 01 Safety Occupant Weight Sensor (OWS) Disabling the passenger's side front PASSENGER AIRBAG OFF airbag PASSENGER AIRBAG NOTE Occupant Weight Sensor (OWS) indicator light PASS. AIRBAG OFF SERVICE URGENT...
Page 29 01 Safety Occupant Weight Sensor (OWS) WARNING PASSENGER AIRBAG OFF PASSENGER AIRBAG OFF WARNING PASSENGER AIRBAG OFF Modifications PASSENGER AIRBAG OFF...
Page 30 01 Safety Occupant Weight Sensor (OWS) WARNING WARNING In the USA In Canada...
Page 31 01 Safety Side impact protection airbags Side impact airbags – front seats only WARNING SIPS airbag deployment Location of the side impact (SIPS) airbag NOTE Components in the SIPS airbag system...
Page 32 01 Safety Volvo Inflatable Curtain (VIC) The Volvo Inflatable Curtain system NOTE WARNING both...
Page 33 01 Safety Volvo Inflatable Curtain (VIC) WARNING...
Page 34 01 Safety Whiplash Protection System Whiplash Protection System (WHIPS) – front seats only WARNING WARNING...
Page 35 01 Safety Whiplash Protection System WARNING WARNING...
Page 36 01 Safety Crash mode Driving after a collision Moving the vehicle WARNING CRASH MODE SEE MANUAL CRASH MODE SEE MANUAL WARNING CRASH MODE SEE MANUAL CRASH MODE SEE MANUAL Attempting to start the vehicle...
Page 37 01 Safety Child safety Children should be seated safely Canada WARNING...
Page 38 01 Safety Child safety Automatic Locking Retractor/ WARNING Emergency Locking Retractor (ALR/ ELR) When attaching the seat belt to a child Volvo's recommendations seat: Volvo has some very specific recommendations:...
Page 39 01 Safety Child restraint systems Child restraints Convertible seat WARNING Infant seat WARNING Passenger airbag off general infor- mation...
Page 40 01 Safety Child restraint systems WARNING...
Page 41 01 Safety Infant seats Securing an infant seat with a seat belt Fasten the seat belt Do not place the infant seat in the front passeng- WARNING er's seat Positioning the seat belt through the infant seat NOTE Passenger airbag off WARNING...
Page 42 01 Safety Infant seats Pull out the shoulder section of the seat belt Ensure that the seat is securely in place WARNING NOTE...
Page 43 01 Safety Convertible seats Securing a convertible seat with a seat WARNING WARNING belt WARNING Do not place the convertible seat in the front pas- senger's seat NOTE Route the seat belt through the convertible seat...
Page 44 01 Safety Convertible seats NOTE WARNING Fasten the seat belt Ensure that the seat is securely in place Pull out the shoulder section of the seat belt...
Page 45 01 Safety Booster cushions Securing a booster cushion Position the child correctly on the booster cushion WARNING and fasten the seat belt WARNING Passenger airbag off...
Page 46 01 Safety ISOFIX lower anchors Using the ISOFIX lower child seat WARNING anchors NOTE ISOFIX lower child restraint anchors To access the anchors: Fasten the attachment correctly to the ISOFIX lower anchors...
Page 47 01 Safety ISOFIX lower anchors WARNING...
Page 48 01 Safety Top tether anchors Top tether anchors WARNING Route the strap under the head restraint Top tether anchorage points WARNING Using the top tether anchorages...
Page 49 01 Safety Child restraint registration and recalls Registering a child restraint...
Page 52: Instruments And Controls
02 Instruments and controls Instrument overview...
Page 53 02 Instruments and controls Instrument overview Control panel in driver's door...
Page 54 02 Instruments and controls Instrument panel Instrument panel...
Page 55 02 Instruments and controls Instrument panel...
Page 56 02 Instruments and controls Indicator and warning symbols Function check Symbols in the center of the instrument panel READ CHECK ENGINE Information symbol PARK BRAKE Warning symbol READ TIME FOR REGULAR MAINTENANCE READ...
Page 57 02 Instruments and controls Indicator and warning symbols NOTE...
Page 58 02 Instruments and controls Symbols – instrument panel Symbols – left side CHECK ENGINE 3. Rear fog light 4. Stability system STC or DSTC NOTE 2. Anti-lock Brake system (ABS) 5. Tire Pressure Monitoring System 1. Malfunction indicator light 6. Fuel level warning light NOTE CHECK ENGINE...
Page 59 02 Instruments and controls Symbols – instrument panel Symbols – right side 2. Parking brake applied 4. Oil pressure warning light NOTE 5. Seat belt reminder 3. SRS system warning light 1. Turn signal indicator for trailer (certain markets only) 6.
Page 60 02 Instruments and controls Symbols – instrument panel 7. Brake failure warning light Hood and trunk Door open warning NOTE At low speeds WARNING BRAKE FAILURE STOP SAFELY DO NOT DRIVE At higher speeds...
Page 61 02 Instruments and controls Information display Messages NOTE Message Meaning ..SERVICE REQUIRED Message Meaning ..STOP SAFELY BOOK TIME FOR MAINTE- NANCE HIGH ENGINE TIME FOR TEMP STOP REGULAR SAFELY MAINTE- NANCE ..SERVICE READ URGENT READ MAINTE- NANCE OVER- ..SEE MAN-...
Page 62 02 Instruments and controls Information display Message Meaning TIME FOR REGULAR MAINTE- NANCE REMINDER CHECK OIL LEVEL...
Page 63 02 Instruments and controls 12-volt sockets 12-volt socket (front seat) NOTE Auxiliary equipment 12-volt socket (rear seat) 12-volt socket, auxiliary equipment Ashtrays/cigarette lighter NOTE...
Page 64 02 Instruments and controls Lighting panel Parking lights Active Bending Lights (ABL)* Pos. Lighting ± Lighting panel, vehicles with Active Bending head- lights Headlights NOTE...
Page 65 02 Instruments and controls Lighting panel Brake lights NOTE Fog lights Front fog lights* Instrument panel lighting Headlight pattern with ABL deactivated (left) and NOTE activated (right) Rear fog lights NOTE...
Page 66 02 Instruments and controls Lighting panel Unlocking the fuel filler door...
Page 67 02 Instruments and controls Left-side steering wheel lever Lever positions Turn signals High/low beam headlights When turning Continuous high beams ± High beam flash When changing lanes Home safe lighting NOTE...
Page 68 02 Instruments and controls Left-side steering wheel lever...
Page 69 02 Instruments and controls Trip computer --- MPH ACTUAL SPEED RESET --- MILES TO EMPTY TANK NOTE --- MILES TO EMPTY TANK MPG AVERAGE READ READ READ RESET RESET RESET Controls MPG INSTANTANEOUS ---- --- MILES TO EMPTY TANK Resetting --.- MPG AVERAGE MPH AVERAGE SPEED --.- MPG AVERAGE...
Page 70 02 Instruments and controls Trip computer RESET MPH ACTUAL SPEED (Canadian models only) NOTE...
Page 71 02 Instruments and controls Cruise control* Engaging the cruise control function Increasing or decreasing speed NOTE Temporarily disengaging the cruise control – – NOTE Cruise control is also automatically disengaged: – CRUISE CRUISE –...
Page 72 02 Instruments and controls Cruise control* Returning to the set speed Disengaging cruise control CRUISE WARNING...
Page 73 02 Instruments and controls Right-side steering wheel lever Windshield wipers Manual wiper function CAUTION Intermittent wiper function Headlight washers (certain models) Continuous wiper function – Windshield washers Low/high beam headlights on Windshield wipers off Parking lights on...
Page 74 02 Instruments and controls Right-side steering wheel lever – Rain sensor* – Thumb wheel Manual deactivation NOTE CAUTION Automatic deactivation On/Off Activating the rain sensor...
Page 75 02 Instruments and controls Steering wheel adjustment, Hazard warning flashers Steering wheel adjustment WARNING NOTE Hazard warning flashers...
Page 76 02 Instruments and controls Power windows Operation Opening a window WARNING Lockout switch for rear windows Control panel in driver's door NOTE I II Lockout switch Closing a window If the light in the switch is OFF:...
Page 77 02 Instruments and controls Power windows Power window controls – rear doors If the light in the switch is ON: Power window control – front passenger's side...
Page 78 02 Instruments and controls Mirrors Rearview mirror Rearview mirror with compass* Calibrating the compass N NE E SE S SW W Night position To calibrate the compass: Auto-dim function*...
Page 79 02 Instruments and controls Mirrors Power door mirrors Passenger's door mirror: Storing the mirrors' position Magnetic zones The mirror control switches are located on the driver's door armrest. Adjusting the mirrors WARNING Folding power door mirrors* Folding the mirrors in Driver's door mirror: ±...
Page 80 02 Instruments and controls Mirrors Folding the mirrors out Automatic folding Blind Spot Information System (BLIS)* NOTE Car settings… Mirror fold on locking Return to "neutral" position...
Page 81 02 Instruments and controls Power moonroof* Operating the moonroof Sliding moonroof Auto open/close Manual open/close Moonroof control in the ceiling console I II NOTE Tilt position ± ±...
Page 82 02 Instruments and controls Power moonroof* Visor CAUTION WARNING WARNING...
Page 83 02 Instruments and controls Personal settings Control panel ENTER NOTE To access the menu and adjust settings MENU AM/PM Car settings… Lock confirmation light ENTER ENTER Autolock To exit the menu ± EXIT Available settings NOTE Clock adjust Unlock...
Page 84: Climate
02 Instruments and controls Personal settings Temporarily turning off the alarm Information sensor(s) Activate once Ask on exit Climate functions Automatically folding the door mirrors Approach lighting Operating side windows Home safe lighting Keyless locking and unlocking* NOTE...
Page 85 02 Instruments and controls Personal settings Reset to factory settings...
Page 86 02 Instruments and controls HomeLink® Wireless Control System* Introduction Programming HomeLink WARNING NOTE...
Page 87 02 Instruments and controls HomeLink® Wireless Control System* replace “Programming HomeLink” NOTE step 2 with the following press and release - every two seconds press, hold for five seconds and release Using HomeLink stays on con- stantly, programming is complete Gate Operator/Canadian Programming rapidly for two seconds and then turns to a con-...
Page 88 02 Instruments and controls HomeLink® Wireless Control System* Erasing HomeLink Buttons NOTE Reprogramming a Single HomeLink Button DO NOT...
Page 89 02 Instruments and controls...
Page 92 03 Climate General information Air conditioning – A/C Fog on the inside of the windows Passenger compartment filter Climate control maintenance NOTE NOTE Refrigerant Display Ice and snow Personal settings...
Page 93 03 Climate General information AUTO Models equipped with ECC* Acceleration Sensors NOTE Side windows and optional moonroof...
Page 94 03 Climate Air vents Air vents in the dashboard...
Page 95 03 Climate Manual climate control Climate system control panel Manual climate system functions 2. Recirculation 1. Blower...
Page 96 03 Climate Manual climate control ± Timer 4. Airflow controls Reduced heating: ± Seat heating off: ± 3. Defroster 8. Heated rear window and door mirrors 5. A/C – On or Off 6/7. Heated front seats* Maximum heating: NOTE...
Page 97 03 Climate Manual climate control 9. Temperature selector...
Page 98 03 Climate Electronic Climate Control (ECC)* ECC functions 2. Blower speed 1. Auto – On/Off AUTO AUTO NOTE AUTO AUTO CLIMATE...
Page 99 03 Climate Electronic Climate Control (ECC)* 3. Recirculation 4. Defroster 6. Air conditioning On/Off Timer 7 and 8. Heated front seats* 5. Airflow controls NOTE Maximum heating: ± Reduced heating:...
Page 100 03 Climate Electronic Climate Control (ECC)* ± NOTE NOTE Seat heating off: ± 9. Rear window and door mirror 10. Temperature selector defrosters ±...
Page 101 03 Climate Air distribution Air distribution Use: Air distribution Use:...
Page 104: Interior
04 Interior Front seats Manual seat adjustment Power seats* NOTE WARNING...
Page 105 04 Interior Front seats Adjusting the seat Programming the seat memory, driver's NOTE seat only* NOTE Seat adjustment controls Power seat memory buttons Emergency stop...
Page 106 04 Interior Front seats Adjusting the front seat head restraints NOTE WARNING Central locking system remote key and driver's seat memory NOTE...
Page 107 04 Interior Front seats WARNING WARNING Removing a head restraint Raising or lowering a head restraint...
Page 108 04 Interior Interior lighting ± Interior lighting Footwell lighting ± Courtesy lighting – automatic function Rear reading lights Front courtesy lights and reading lights Rear reading lights (in ceiling) ±...
Page 109 04 Interior Interior lighting I II Vanity mirror...
Page 110 04 Interior Storage compartments...
Page 111 04 Interior Storage compartments Glove compartment Storage under the front, center armrest WARNING...
Page 112 04 Interior Storage compartments CD storage Cup holders in the center console Storage compartment behind the gear lever...
Page 113 04 Interior Rear seat Rear seat head restraints WARNING WARNING Folding down the rear seat backrests Adjust the head restraint vertically ± ± ±...
Page 114 04 Interior Rear seat NOTE WARNING WARNING NOTE...
Page 115 04 Interior Trunk Load anchoring eyelets...
Page 118: Locks And Alarm
05 Locks and alarm Remote key and key blade Remote keys Immobilizer (start inhibitor) NOTE USA – FCC ID: LTQVO315TX California Only: CAUTION Canada – IC: 3659AVO315TX USA – FCC ID: LTQWFS 125VO Loss of a remote key Canada – IC: 3659A-WFS125VO...
Page 119 05 Locks and alarm Remote key and key blade Remote key functions Unlock Automatic locking: NOTE Approach lighting Lock Unlock trunk NOTE NOTE Automatic relocking:...
Page 120 05 Locks and alarm Remote key and key blade Panic alarm KEY BATTERY LOW VOLTAGE Key blade Replacing the battery in the remote key NOTE Weak battery in the remote key CAUTION Removing the key blade Removing the key blade...
Page 121 05 Locks and alarm Remote key and key blade Locking the doors with the detached key blade Reinserting the key blade in the remote Unlocking the doors with the detached key blade NOTE To disable the alarm...
Page 122 05 Locks and alarm Valet locking Locking points remote key: Locking/unlocking points with key blade removed (with valet locking activated) remote key: Normal locking/unlocking points Activating/deactivating the valet locking function Deactivating valet locking: Driver’s side Activating valet locking: Passenger’s side...
Page 123 05 Locks and alarm Keyless drive* Keyless locking and unlocking Locking the vehicle NOTE Unlocking the vehicle Keyless drive lock button Range of the keyless drive remote key–5 ft (1.5 meters) NOTE NOTE...
Page 124 05 Locks and alarm Keyless drive* Locking or unlocking the vehicle with the NOTE key blade To disable the alarm: Keyless drive information messages Keyless drive remote key and driver's seat memory NOTE Keyless drive keyhole cover READ...
Page 125 05 Locks and alarm Keyless drive* KR55WK48964 Location of the keyless drive antennas CAUTION Canada – IC:267T- 5WK48952, 267T- 5WK48964, 267T-5WK48891 USA – FCC ID:KR55WK48952,...
Page 126 05 Locks and alarm Keyless drive* WARNING...
Page 127 05 Locks and alarm Locking and unlocking Locking/unlocking the vehicle from the Opening the trunk from the inside NOTE inside ± Unlocking: ± Locking:...
Page 128 05 Locks and alarm Locking and unlocking Locking the glove compartment...
Page 129 05 Locks and alarm Child safety locks Manual child safety locks, rear doors...
Page 130 05 Locks and alarm Alarm* The alarm system The alarm indicator light Fault in the alarm system: Arming the alarm ± LOCK Disarming the alarm Alarm indicator light ± UNLOCK ALARM TRIGGERED CHECK CAR...
Page 131 05 Locks and alarm Alarm* Turning off (stopping) the alarm Temporarily turning off the accessory alarm sensor(s) UNLOCK NOTE MENU Car settings… Reduced guard… Activate once REDUCED GUARD SEE MANUAL Audible/visual alarm signal NOTE Ask on exit Reduced guard ask on exit Press ENTER to reduce guard until engine has started.
Page 132 05 Locks and alarm Alarm* FULL GUARD EXIT CAUTION U.S.A. FCC ID: MAYDA 5823(3) Canada IC: 4405A-DA 5823(3)
Page 133 05 Locks and alarm...
Page 136: Starting And Driving
06 Starting and driving General information Economical driving conserves natural WARNING resources Driving with the trunk open: Other factors that decrease gas mileage are: Weight distribution affects handling...
Page 137 06 Starting and driving General information Handling, roadholding CAUTION Driving through water Cold weather precautions WARNING...
Page 138 06 Starting and driving General information Conserving electrical current NOTE Before a long distance trip NOTE...
Page 139 06 Starting and driving General information...
Page 140 06 Starting and driving Fuel requirements Octane rating Use of Additives Minimum octane NOTE WARNING Fuel Formulations switched Typical pump octane label WARNING Demanding driving...
Page 141 06 Starting and driving Fuel requirements Deposit control gasoline (detergent additives) Alcohol – Ethanol: NOTE Ethers – MTBE: Methanol NOTE Unleaded fuel Fuel filler door Gasoline containing alcohol and ethers with the ignition switched off...
Page 142 06 Starting and driving Fuel requirements CAUTION Open the fuel filler cap slowly during hot weather Refueling...
Page 143 06 Starting and driving Ignition switch Ignition switch positions II – Drive position 0 – Locked position III – Start position NOTE I – Intermediate position...
Page 144 06 Starting and driving Starting the vehicle To start the engine NOTE WARNING Immobilizer Keylock Manual transmission NOTE...
Page 145 06 Starting and driving Starting the vehicle WARNING CAUTION Automatic transmission:...
Page 146 06 Starting and driving Starting the vehicle with keyless drive* Starting a vehicle with keyless drive NOTE autostart Removing the keyless drive start control Starting the vehicle with the ignition key (remote key) NOTE...
Page 147 06 Starting and driving Manual transmission, 5-speed* 5-speed manual transmission Engaging reverse gear, 5-speed CAUTION transmission WARNING NOTE...
Page 148 06 Starting and driving Manual transmission, 6-speed* 6-speed manual transmission Engaging reverse gear, 6-speed CAUTION transmission WARNING NOTE...
Page 149 06 Starting and driving Automatic transmission* Shiftgate positions Gear selector positions R – Reverse P – Park N – Neutral NOTE R N D D - left position: automatic shifting, M - right posi- tion: manual shifting CAUTION D – Drive...
Page 150 06 Starting and driving Automatic transmission* Manual shifting – Geartronic Cold starts (turbo engines) NOTE Kickdown While driving Safety function – –...
Page 151 06 Starting and driving Shiftlock override Overriding the shiftlock system To manually override the Shiftlock system: P R N D...
Page 152 06 Starting and driving All Wheel Drive* All Wheel Drive (AWD) – general Temporary Spare information Tire dimensions...
Page 153 06 Starting and driving Brake system Brake lights Power brakes function only when the engine is running Adaptive brake lights NOTE Water on brake discs and brake pads WARNING affects braking DO NOT DRIVE Brake circuit malfunction...
Page 154 06 Starting and driving Brake system Severe strain on the brake system For optimal ABS braking effect: WARNING BRAKES Electronic Brake Force Distribution (EBD) Emergency Brake Assistance – EBA Anti-lock brakes (ABS) The system performs a self-diagnostic test when the engine is started and when the vehicle first reaches a speed of approxi- mately 12 mph (20 km/h).
Page 155 06 Starting and driving Brake system NOTE...
Page 156 06 Starting and driving Parking brake Parking brake (hand brake) Parking on a hill Releasing the parking brake NOTE WARNING When applying the parking brake...
Page 157 06 Starting and driving Stability system Stability Traction Control (STC)/ Temporarily switching off Spin control Dynamic Stability Traction Control (DSTC) RESET STC SPIN CONTROL OFF STC DSTC SPIN CONTROL OFF DSTC ON NOTE Function/ DSTC STC SPIN CONTROL system OFF DSTC SPIN CONTROL OFF Spin control (SC) Traction control (TC) STC ON DSTC ON...
Page 158 06 Starting and driving Stability system Symbols used by the stability system Stability system indicator light WARNING WARNING Information symbol STC/DSTC-related messages in the text window TRACTION CONTROL TEMPORARILY ANTI-SKID SERVICE REQUIRED...
Page 159 06 Starting and driving Towing Emergency towing WARNING Towing a vehicle with all four wheels on the ground WARNING The following points should also be observed: Never exceed 50 mph (80 km/h) Never tow farther than 50 miles (80 km). WARNING...
Page 160 06 Starting and driving Towing Towing vehicles with front wheel drive WARNING WARNING CAUTION...
Page 161 06 Starting and driving Jump starting Jump starting the vehicle WARNING WARNING PROPOSITION 65 WARNING!
Page 162 06 Starting and driving Towing a trailer General information CAUTION WARNING Trailers without brakes Trailers with brakes The maximum recommended hitch tongue load...
Page 163 06 Starting and driving Towing a trailer NOTE...
Page 164 06 Starting and driving Detachable trailer hitch Installing the ball holder Removing the ball holder NOTE...
Page 165 06 Starting and driving Transporting loads Loading the vehicle WARNING Load carriers (accessory) Keep the following in mind when loading the vehicle:...
Page 166 06 Starting and driving Blind Spot Information System (BLIS)* Introduction WARNING A = approx. 10 ft. (3 meters), B = approx. 31 ft. (9.5 meters) NOTE CAUTION...
Page 167 06 Starting and driving Blind Spot Information System (BLIS)* When does BLIS function Darkness NOTE headlights When you pass another vehicle: Blind spot syst. Service required WARNING When you are passed by another vehicle: WARNING Light reflected from a wet road surface Limitations How BLIS functions in daylight and darkness...
Page 168 06 Starting and driving Blind Spot Information System (BLIS)* CAUTION READ The vehicle's own shadow against a large, light, BLIS system messages smooth surface such as barriers between lanes on Switching BLIS on and off Text in the System status a highway display BLIS SERVICE...
Page 169 06 Starting and driving Blind Spot Information System (BLIS)* Text in the System status display BLIS OFF BLIS REDUCED FUNCTION...
Page 170 06 Starting and driving Park assist* Introduction WARNING NOTE Front park assist Function Front/rear park assist Rear park assist...
Page 171 06 Starting and driving Park assist* Activating/deactivating park assist Faults in the system NOTE PARK ASSIST SERVICE REQUIRED Audible signals from the park assist CAUTION system Park Assist button (right button in the illustration) ± ±...
Page 172 06 Starting and driving Park assist* Cleaning the sensors Park assist sensors NOTE...
Page 173 06 Starting and driving...
Page 176: Wheels And Tires
07 Wheels and tires General information Introduction CAUTION Improving tire economy New Tires Tire age...
Page 177 07 Wheels and tires General information Summer and winter tires WARNING Storing wheels and tires CAUTION The arrows shows the direction of rotation of the tire Tire wear Tire rotation...
Page 178 07 Wheels and tires General information Tread wear indicator NOTE...
Page 179 07 Wheels and tires Tire inflation Inflation labels WARNING Tire inflation placard on Canadian models Tire inflation placard on U.S. models NOTE...
Page 180 07 Wheels and tires Tire inflation Checking tire pressure Load ratings Cold tires The tires are considered to be cold when they have the same temperature as the sur- rounding (ambient) air. Speed ratings Speed ratings NOTE To check inflation pressure: Load ratings Load ratings...
Page 181 07 Wheels and tires Inflation pressure—U.S. models Tire inflation pressure table Tire size Cold tire pressure up to five persons psi (kPa) Front Rear...
Page 182 07 Wheels and tires Inflation pressure—Canadian models Tire inflation pressure table Tire size Cold tire pressures Optional pressure Up to five persons Up to three persons psi (kPa) psi (kPa) Front Rear Front Rear...
Page 183 07 Wheels and tires Tire designations Tire designations M+S or M/ U.S. DOT Tire Identification Number (TIN): NOTE NOTE Maximum Load: example only...
Page 184 07 Wheels and tires Tire designations Treadwear, Traction, and Temperature grades: Maximum permissible inflation pres- sure:...
Page 185 07 Wheels and tires Glossary of tire terminology Terminology B-pillar Tire information placard Bead area of the tire Cold tires Sidewall of the tire Tire Identification Number (TIN) Tread area of the tire Inflation pressure Maximum load rating Standard load Maximum permissible inflation pres- sure Extra load...
Page 186 07 Wheels and tires Vehicle loading Loading the vehicle Gross vehicle weight (GVW) NOTE Curb weight Capacity weight Steps for Determining Correct Load Limit NOTE Permissible axle weight...
Page 187 07 Wheels and tires Vehicle loading WARNING...
Page 188 07 Wheels and tires Uniform tire quality gradings Uniform tire quality gradings WARNING ALL PASSENGER VEHICLE TIRES MUST CONFORM TO FEDERAL SAFETY REQUIREMENTS IN ADDITION TO THESE GRADES Quality grades can be found, where appli- WARNING cable, on the tire sidewall between the tread shoulder and maximum section width.
Page 189 07 Wheels and tires Snow chains, snow tires, studded tires Snow chains CAUTION NOTE All Wheel Drive models Snow tires, studded tires Tires for winter use:...
Page 190 07 Wheels and tires Temporary spare Temporary spare WARNING CAUTION...
Page 191 07 Wheels and tires Wheel nuts Wheel nuts Steel rims – type 1 wheel nuts WARNING Aluminum wheels – type 2 or 3 wheel nuts NOTE Lockable wheel nut Tightening torques: Type 1 wheel nuts Type 2 wheel nuts Type 3 wheel nuts Lockable wheel nuts...
Page 192 07 Wheels and tires Changing a wheel Changing a wheel Jack attachment points...
Page 193 07 Wheels and tires Changing a wheel Installing the wheel WARNING WARNING Returning the jack to its storage space...
Page 194 07 Wheels and tires Tire Sealing System Introduction Tire sealing system–overview NOTE WARNING Accessing the tire sealing system...
Page 195 07 Wheels and tires Tire Sealing System WARNING NOTE Tire sealing system–temporarily repairing a flat tire Stage 2: WARNING Precautions: Stage 1: Sealing the hole First aid: Stage 1:...
Page 196 07 Wheels and tires Tire Sealing System NOTE WARNING WARNING NOTE CAUTION WARNING WARNING...
Page 197 07 Wheels and tires Tire Sealing System Replacing the sealing compound WARNING container NOTE CAUTION Stage 2: Checking inflation pressure stage 1 NOTE CAUTION WARNING...
Page 198 07 Wheels and tires Tire Sealing System Inflating tires CAUTION WARNING...
Page 199 07 Wheels and tires Tire Pressure Monitoring System (TPMS) Introduction NOTE TIRE PRESS SYST SERVICE REQUIRED NOTE LOW TIRE PRESS. CHECK TIRES VERY LOW TIRE PRESSURE...
Page 200 07 Wheels and tires Tire Pressure Monitoring System (TPMS) NOTE WARNING NOTE Changing wheels with TPMS Erasing warning messages TIRE PRESS SYST SERVICE REQUIRED CAUTION...
Page 201 07 Wheels and tires...
Page 204: Car Care
08 Car care Washing and cleaning the car Washing the car CAUTION NOTE CAUTION Exterior components Bird droppings Special moonroof cautions:...
Page 205 08 Car care Washing and cleaning the car Automatic washing – simple and quick WARNING Exterior lighting CAUTION CAUTION Polishing and Waxing Chromed wheels:...
Page 206 08 Car care Washing and cleaning the car Upholstery care Fabric CAUTION Interior plastic components Cleaning leather upholstery Alcantera™ suede-like material Leather care Protecting leather upholstery...
Page 207 08 Car care Washing and cleaning the car Cleaning the seat belts Cleaning floor mats...
Page 208 08 Car care Paint touch up Touching up minor paint damage Minor stone chips and scratches NOTE Deep scratches Color code...
Page 209 08 Car care...
Page 212: Maintenance And Servicing
09 Maintenance and servicing Volvo maintenance General Maintenance Periodic maintenance helps minimize emissions The Federal Clean Air Act – U.S Applicable warranties – U.S/Canada...
Page 213 09 Maintenance and servicing Maintaining your car Owner maintenance As needed: Each time the car is refueled: NOTE Monthly: Emission inspection readiness Hoisting the vehicle What is an Onboard Diagnostic System (OBD II)?
Page 214 09 Maintenance and servicing Maintaining your car How Do States Use OBD II for Emission Inspections? How Can My Vehicle Fail OBD II Emission Inspection? How Can I Prepare for My Next OBD II Emission Inspection?
Page 215 09 Maintenance and servicing Hood Opening the hood WARNING...
Page 216 09 Maintenance and servicing Engine compartment WARNING...
Page 217 09 Maintenance and servicing Engine oil Changing engine oil and oil filter NOTE Location of dipstick and oil filler cap CAUTION Checking the oil Checking and adding oil If the engine is warm...
Page 218 09 Maintenance and servicing Engine oil WARNING NOTE...
Page 219 09 Maintenance and servicing Fluids Washer fluid Coolant CAUTION Washer fluid reservoir Coolant reservoir...
Page 220 09 Maintenance and servicing Fluids Power steering fluid WARNING Replace: Fluid type Replace WARNING Brake fluid WARNING DO NOT DRIVE Brake fluid reservoir Fluid type:...
Page 221 09 Maintenance and servicing Wiper blades Replacing windshield wiper blades...
Page 222 09 Maintenance and servicing Battery Battery maintenance Battery symbols WARNING PROPOSITION 65 WARNING!
Page 223 09 Maintenance and servicing Battery Installing a new battery Battery replacement NOTE Removing the battery WARNING...
Page 224 09 Maintenance and servicing Replacing bulbs Introduction Removing the headlight housing WARNING NOTE...
Page 225 09 Maintenance and servicing Replacing bulbs Low beam bulb CAUTION WARNING Low beam bulb Cover with retaining clamps Installing a new bulb...
Page 226 09 Maintenance and servicing Replacing bulbs High beam bulb (halogen) Parking light bulb WARNING Halogen high beam bulb NOTE...
Page 227 09 Maintenance and servicing Replacing bulbs Turn signal Side marker light Front fog lights*...
Page 228 09 Maintenance and servicing Replacing bulbs Removing the taillight bulb holder NOTE Location of taillight bulbs High-level brake light Location of taillight bulbs...
Page 229 09 Maintenance and servicing Replacing bulbs License plate lighting Footwell lighting Trunk lighting...
Page 230 09 Maintenance and servicing Replacing bulbs Vanity mirror lighting...
Page 231 09 Maintenance and servicing Fuses Replacing fuses same color and amperage WARNING...
Page 232 09 Maintenance and servicing Fuses Fuse box in the engine compartment...
Page 233 09 Maintenance and servicing Fuses Fuses in the engine compartment...
Page 234 09 Maintenance and servicing Fuses...
Page 235 09 Maintenance and servicing Fuses Fuse box in the passenger compartment...
Page 236 09 Maintenance and servicing Fuses Fuses in the passenger compartment...
Page 237 09 Maintenance and servicing Fuses...
Page 240 10 Audio Audio functions Audio system controls Auxiliary connector VOLUME AM/FM MODE Selecting a sound source ± MODE AM/FM TUNING SOUND ± MODE...
Page 241 10 Audio Audio functions MENU Steering wheel keypad USB/iPod connector* AUX volume AUX input volume AUX input volume Volume Steering wheel keypad MODE iPod Daytime/twilight display Connect device...
Page 242 10 Audio Audio functions LOADING iPod NOTE NOTE ENTER USB flash drive ENTER Sound settings NOTE ± Optimal sound reproduction ± MP3 player BASS TREBLE Equalizer front…...
Page 243 10 Audio Audio functions Equalizer rear… Surround sound SURROUND AM SURROUND FM SURROUND CD SURROUND AUX ENTER SOUND Dolby Pro Logic II ENTER Equalizer Front/Rear TUNING NOTE NOTE BASS TREBLE BALANCE FADER MENU ENTER Subwoofer AUDIO SETTINGS ENTER CENTER Equalizer front… Equalizer SURROUND rear…...
Page 244 10 Audio Audio functions Automatic sound control Medium High MENU ENTER AUDIO SETTINGS ENTER Auto. volume control… ENTER Low Medium High ENTER...
Page 245 10 Audio Radio functions Radio function controls EXIT Storing preset stations Manually storing a station AUTO Searching for stations Station stored ± TUNING NOTE ± Automatically storing a station AM/FM1/FM2 AUTO TUNING SCAN MENU NAVIGATION CONTROL AM/FM AUTO Autostoring Autostoring...
Page 246 10 Audio Radio functions No AST found Scanning Radio text ± EXIT SCAN Auto Auto MENU AM/FM EXIT Activating/deactivating SCAN AUTO ENTER AM/FM Radio text AUTO ENTER SCAN SCAN Radio text Saving auto-stored stations in the preset ENTER SCAN EXIT memory Storing a station found with SCAN AUTO...
Page 247 10 Audio Radio functions How HD broadcasting works HD Radio reception (U.S. models only) Introduction Limitations Benefits of digital broadcasting Main channel vs. sub-channels (FM Display when the radio is receiving an HD Radio only) broadcast...
Page 248 10 Audio Radio functions ENTER NOTE Reception coverage area Analogue to digital/digital to analogue blending The above items are dependant on the Sub-channels broadcaster's equipment settings and do not indicate a fault in the vehicle's radio receiver or antenna systems Switching HD on or off Example of an HD Radio station with sub-channels MENU...
Page 249 10 Audio Radio functions Listening to satellite radio NOTE NOTE Selecting sub-channels sub-chan- No HD reception Selecting Sirius radio mode 6 seconds MODE No HD reception Activating Sirius radio CALL 888-539-SIRIUS TO SUBSCRIBE...
Page 250 10 Audio Radio functions MENU ENTER NOTE AUTO ENTER Updating subscription NOTE SIRIUS ID Scanning Selecting a channel Selecting a channel category NOTE ENTER Direct channel entry Storing a channel long ENTER short...
Page 251 10 Audio Radio functions Song seek Advanced settings Song Seek and Song Memory MENU ± ENTER EXIT ADVANCED SIRIUS SETTINGS MENU WARNING Song seek ENTER Song memory NOTE MENU Add song to song memory Radio text ENTER AUTO Artist Skip options Track title: Composer Sirius radio text…...
Page 252 10 Audio Radio functions Channel lock list CHANGE CODE ENTER ENTER ENTER ENTER Unskip all channels ENTER Change code ENTER ENTER ENTER ENTER Temp. unskip all ch. ENTER Incorrect code Unlocking a channel: If you have forgotten the access code: Sirius ID: Channel lock ENTER...
Page 253 10 Audio CD player/CD changer CD function controls Playing a CD NOTE Single CD player Insert disc MODE NOTE CD eject Eject from Single CD player ± CD changer The CD changer can hold up to six discs. Eject from CD changer MENU NAVIGATION CONTROL MODE ±...
Page 254 10 Audio CD player/CD changer NOTE NOTE TUNING Navigating the disc and playing tracks ENTER Fast forward/back ± ENTER CD Pause Random play Audio files Activating/deactivating the random function-CD player If a normal CD is being played: NOTE Changing tracks MENU ENTER ENTER...
Page 255 10 Audio CD player/CD changer Disc Folder ENTER MENU NOTE ENTER Activating/deactivating the random Disc text function-CD changer ENTER If a normal CD is being played: MENU ENTER Random ENTER Disc text ENTER Single disc All discs ENTER Scan If a CD with audio files is being played: MENU ENTER Random...
Page 256 10 Audio CD player/CD changer...
Page 257 10 Audio Audio menu FM1/FM2 menu CD changer* menu Radio text When a normal music CD is selected. Audio settings… Random… Disc text AM menu Audio settings… Audio settings… CD changer* menu CD menu When a CD containing files in MP3 format is selected.
Page 258 10 Audio ® Bluetooth hands-free connection Introduction PHONE NOTE Connecting cell phones WARNING System overview Getting started ® Bluetooth hands-free PHONE Add phone Activating/deactivating PHONE PHONE Add phone...
Page 259 10 Audio ® Bluetooth hands-free connection NOTE My Car Making a call PHONE PHONE Handling calls Incoming calls ± PHONE ENTER ENTER. EXIT. ± EXIT Disconnecting the cell phone Automatic answer My Car Phone Menu… Call options… Automatic answer PHONE My Car Call settings MENU...
Page 260 10 Audio ® Bluetooth hands-free connection Mute microphone Phone Menu… Phone Transfer call to cell settings… Sounds and volume… Ring signals… Use cell phone signal Phone book Phone Menu… Phone settings… More information about registering Sounds and volume… Mute radio and connecting cell phones NOTE Ringing volume...
Page 261 10 Audio ® Bluetooth hands-free connection Call options… Voice mail number Searching for contacts Phone Menu… Bluetooth… Call lists Connect phone Change phone Phone book ENTER PHONE Call register… NOTE Phone book… Search Phone settings… Synchronize ENTER ENTER. phone book Entering text ENTER Voice control...
Page 262 10 Audio ® Bluetooth hands-free connection ® Bluetooth menus Call register… Call register… Bluetooth… Call options… Phone settings…...
Page 263 10 Audio...
Page 266 11 Specifications Label information...
Page 267: Specifications
11 Specifications Label information Model plate Vehicle Emission Control Information Federal Motor Vehicle Safety Standards (FMVSS) specifications (USA) and Ministry of Transport (CMVSS) standards (Canada) Loads and Tire Pressures Vehicle Identification Number (VIN)
Page 268 11 Specifications Dimensions and weights Dimensions Position Dimension...
Page 269 11 Specifications Dimensions and weights Position Dimension Weights Category Canada Gross vehicle weight Capacity weight Permissible axle weight, front Permissible axle weight, rear...
Page 270 11 Specifications Dimensions and weights Category Canada Curb weight Max. roof load Max. trailer weight (w/o brakes) Max. trailer weight (with brakes) Max. tongue weight CAUTION WARNING...
Page 271 11 Specifications Fuel, oils, and fluids Specifications and capacities Category Specification Capacity Fuel tank Engine oil (with filter replacement) Automatic transmission oil Manual transmission oil Coolant Brake fluid Power steering fluid...
Page 272 11 Specifications Fuel, oils, and fluids Category Specification Capacity Washer fluid reservoir Air conditioning system NOTE...
Page 273 11 Specifications Engine oil Oil specifications American Petroleum Institute (API) symbol Viscosity chart Extreme engine operation Oil additives must not be used. NOTE Oil viscosity...
Page 274 11 Specifications Engine specifications Engine designation B5244S4 B5254T7 B5244S7 Output Torque No. of cylinders Displacement (liters/cubic inches) Bore (mm/in.) Stroke (mm/in.) Compression ratio Spark plugs Charge air cooler (Intercooler)
Page 275 11 Specifications Engine specifications Fuel system...
Page 276 11 Specifications Electrical system General information WARNING Battery PROPOSITION 65 WARNING! Voltage 12 V 12 V Cold start capacity (CCA) Reserve capacity (RC) Capacity (Ah) Bulbs used in the car Bulb Output Type...
Page 277 11 Specifications Electrical system Bulb Output Type NOTE...
Page 278 11 Specifications Three-way catalytic converter Three-way catalytic converter – general information NOTE...
Page 279 11 Specifications Volvo programs Volvo On Call Roadside Assistance In the U.S. In Canada Technician certification...
Page 280 12 Index 1, 2, 3 ...
Page 281 12 Index...
Page 282 12 Index...
Page 283 12 Index...
Page 284 12 Index...
Page 285 12 Index...
Page 286 12 Index...
Page 287 12 Index...
Page 288 12 Index...
Page 290 Kdakd 8Vg 8dgedgVi^dc...

Volvo S40 Owner's Manual

Quick Links

Related Manuals for Volvo S40

Summary of Contents for Volvo S40

Table of Contents
