USER'S MANUAL

Revision 1.0a

Table of Contents

Need help?

Do you have a question about the H8QM3-2+ and is the answer not in the manual?

Questions and answers

Summary of Contents for Supero H8QM3-2+

Page 1 UPER ® H8QM3-2+ H8QMi-2+ USER’S MANUAL Revision 1.0a...
Page 2 Please Note: For the most up-to-date version of this manual, please see our web site at www.supermicro.com. Super Micro Computer, Inc. ("Supermicro") reserves the right to make changes to the product described in this manual at any time and without notice. This product, including software, if any, and documentation may not, in whole or in part, be copied, photocopied, reproduced, translated or reduced to any medium or machine without prior written consent.
Page 3 128 GB of DDR2-667 registered ECC SDRAM. Please refer to the serverboard speciﬁ cations pages on our web site for updates on supported processors (http://www.supermicro.com/aplus/). This product is intended to be professionally installed. Manual Organization Chapter 1 includes a checklist of what should be included in your serverboard box, describes the features, speciﬁ...
Page 4: Table Of Contents
H8QM3-2+/H8QMi-2+ User’s Manual Table of Contents Chapter 1 Introduction Overview ......................1-1 Checklist ......................1-1 Contacting Supermicro ..................1-2 Serverboard Details ..................1-4 H8QM3-2+/H8QMi-2+ Quick Reference ............1-5 Serverboard Features ..................1-6 Chipset Overview .................... 1-9 MCP55 Pro Media and Communications Processor ........1-9 NEC uPD720404 .....................
Page 5 Table of Contents Reset Button ....................2-9 Power Button ....................2-9 Universal Serial Bus Ports (USB0/1) .............. 2-9 USB Headers ....................2-9 Serial Ports ....................2-10 Fan Headers ....................2-10 Overheat LED ....................2-10 Power LED/Speaker ................... 2-10 JLAN1/2 (Ethernet Ports) ................2-11 ATX PS/2 Keyboard and PS/2 Mouse Ports ..........2-11 Chassis Intrusion ..................2-11 Wake-On-LAN ....................2-11...
Page 6 H8QM3-2+/H8QMi-2+ User’s Manual 2-11 Installing Software Drivers ................2-24 Chapter 3 Troubleshooting Troubleshooting Procedures ................3-1 Before Power On .................... 3-1 No Power ......................3-2 No Video ......................3-2 Memory Errors ....................3-2 Losing the System’s Setup Conﬁ guration ............3-3 Technical Support Procedures ................
Page 7: Chapter 1 Introduction
Chapter 1: Introduction Chapter 1 Introduction Overview Checklist Congratulations on purchasing your computer serverboard from an acknowledged leader in the industry. Our boards are designed with the utmost attention to detail to provide you with the highest standards in quality and performance. Please check that the following items have all been included with your serverboard.
Page 8: Contacting Supermicro
Super Micro Computer, Inc. 980 Rock Ave. San Jose, CA 95131 U.S.A. Tel: +1 (408) 503-8000 Fax: +1 (408) 503-8008 Email: marketing@supermicro.com (General Information) support@supermicro.com (Technical Support) Web Site: www.supermicro.com Europe Address: Super Micro Computer B.V. Het Sterrenbeeld 28, 5215 ML...
Page 9 Chapter 1: Introduction Figure 1-1. H8QM3-2+ Image Note: the H8QMi-2+ has the same layout but does not include SAS ports or com- ponents.
Page 10: Serverboard Details
H8QM3-2+/H8QMi-2+ User’s Manual Serverboard Details Figure 1-2. Serverboard Layout (not drawn to scale) JOH1 UPER H8QM3-2+ DIMMB 1B DIMMB 1A DIMMB 2B DIMMB 2A CPU 4 CPU2 DIMMs FAN1 DIMMB 3B DIMMB 3A DIMMB 4B DIMMB 4A FAN7/ DIMMC 4A CPU4 Speaker DIMMC 4B...
Page 11: H8Qm3-2+/H8Qmi-2+ Quick Reference
Chapter 1: Introduction H8QM3-2+/H8QMi-2+ Quick Reference Jumper Description Default Setting JBT1 CMOS Clear (See Section 2-7) JCF1 Compact Flash Card Master/Slave Closed (Master) JPS1* SAS RAID Select Closed (SR RAID) C3/JI C to PCI-E Pins 2-3 (Disabled) JPG1 VGA Enable/Disable Pins 1-2 (Enabled) JPL1 JLAN Enable/Disable...
Page 12: Serverboard Features
H8QM3-2+/H8QMi-2+ User’s Manual Serverboard Features • Two (dual) or four (quad) AMD Opteron 8000 series Socket F type processors • See web site for details on supported processors Memory • Thirty-two dual-channel DIMM slots supporting up to 128 GB of registered ECC DDR2-667/533/400 SDRAM •...
Page 13 Chapter 1: Introduction Onboard I/O • On-chip SATA controller supporting six (6) 3 Gb/s SATA ports (RAID 0, 1, 0+1, 5 and JBOD) • LSI 1068E SAS controller supporting eight (8) SAS ports (RAID 0, 1, 10 and JBOD, optional RAID 5 support with iButton installed) (H8QM3-2+ only) •...
Page 14: System Block Diagram
H8QM3-2+/H8QMi-2+ User’s Manual DDR2-667/533/400 DDR2-667/533/400 AMD Socket F Type AMD Socket F Type DIMMs 1A ~ 4B DIMMs 1A ~ 4B Processor (CPU3) Processor (CPU4) 16 x 16 HT link (1 GHz) DDR2-667/533/400 DDR2-667/533/400 AMD Socket F Type AMD Socket F Type DIMMs 1A ~ 4B DIMMs 1A ~ 4B Processor (CPU2)
Page 15: Chipset Overview
Chapter 1: Introduction Chipset Overview The H8QM3-2+/H8QMi-2+ serverboard is based on the nVidia MCP55 Pro chipset. The MCP55 Pro functions as Media and Communications Processor (MCP). An NEC uPD720404 chip is also included as a bridge for the GB LAN ports. Note that the controllers for the system memory are integrated directly into the AMD CPUs.
Page 16: Pc Health Monitoring
H8QM3-2+/H8QMi-2+ User’s Manual PC Health Monitoring This section describes the PC health monitoring features of the H8QM3-2+/H8QMi- 2+. The serverboard has an onboard System Hardware Monitor chip that supports PC health monitoring. Onboard Voltage Monitors for four CPU cores, Hyper Transport (1.2V), memory (1.8V), chipset (1.5V) The onboard voltage monitor will scan these voltages continuously.
Page 17: Power Supply
Chapter 1: Introduction Slow Blinking LED for Suspend-State Indicator When the CPU goes into a suspend state, the chassis power LED will start blinking to indicate that the CPU is in suspend mode. When the user presses any key, the CPU will wake-up and the LED will automatically stop blinking and remain on.
Page 18: Super I/O
H8QM3-2+/H8QMi-2+ User’s Manual The H8QM3-2+/H8QMi-2+ accommodates 12V ATX power supplies. Although most power supplies generally meet the speciﬁ cations required by the CPU, some are in- adequate. A 2 amp current supply on a 5V Standby rail is strongly recommended. It is strongly recommended that you use a high quality power supply that meets 12V ATX power supply Speciﬁ...
Page 19: Chapter 2 Installation
Chapter 2: Installation Chapter 2 Installation Static-Sensitive Devices Electrostatic Discharge (ESD) can damage electronic com ponents. To prevent dam- age to your system board, it is important to handle it very carefully. The following measures are generally sufﬁ cient to protect your equipment from ESD. Precautions •...
Page 20: Installation Procedure
H8QM3-2+/H8QMi-2+ User's Manual Installation Procedure Perform the following procedures in the order listed below to install the serverboard into a chassis: Install the processor(s) and the heat sink(s). Install the serverboard in the chassis. Install the memory and add-on cards. Finally, connect the cables and install the drivers.
Page 21 Chapter 2: Installation Triangle Use your thumb and your index ﬁ nger to hold the CPU. Locate and align pin 1 of the CPU socket with pin 1 of the CPU. Both are marked with a triangle. Align pin 1 of the CPU with pin 1 of the socket.
Page 22: Mounting The Serverboard Into A Chassis
H8QM3-2+/H8QMi-2+ User's Manual Mounting the Serverboard into a Chassis All serverboards have standard mounting holes to ﬁ t different types of chassis. Ensure that the locations of all the mounting holes for both the serverboard and the chassis match. Although a chassis may have both plastic and metal mount- ing fasteners, metal ones are highly recommended because they ground the serverboard to the chassis.
Page 23 Chapter 2: Installation Support The H8QM3-2+/H8QMi-2+ supports single or dual-channel, registered ECC DDR2- 667/533/400 SDRAM. Both interleaved and non-interleaved memory are supported, so you may populate any number of DIMM slots (see note on previous page). Populating two adjacent slots at a time with memory modules of the same size and type will result in inter- leaved (128-bit) memory, which is faster than non-interleaved (64-bit) memory.
Page 24: I/O Port And Control Panel Connections
H8QM3-2+/H8QMi-2+ User's Manual I/O Port and Control Panel Connections The I/O ports are color coded in conformance with the PC99 speciﬁ cation to make setting up your system easier. See Figure 2-2 below for the colors and locations of the various I/O ports. Figure 2-2.
Page 25: Connector Deﬁ Nitions
Chapter 2: Installation Connector Deﬁ nitions ATX Power 24-pin Connector ATX Power Connector Pin Deﬁ nitions (J1B1) Pin# Deﬁ nition Pin # Deﬁ nition +3.3V +3.3V The primary ATX power supply con- -12V +3.3V nector (J1B1) meets the SSI (Super- set ATX) 24-pin speciﬁ...
Page 26: Hdd Led
H8QM3-2+/H8QMi-2+ User's Manual HDD LED HDD LED The HDD (IDE Hard Disk Drive) LED Pin Deﬁ nitions (JF1) connection is located on pins 13 and Pin# Deﬁ nition 14 of JF1. Attach the IDE hard drive LED cable to display disk activity. HD Active Refer to the table on the right for pin deﬁ...
Page 27: Reset Button
Chapter 2: Installation Reset Button Reset Button Pin Deﬁ nitions (JF1) The Reset Button connection is lo- Pin# Deﬁ nition cated on pins 3 and 4 of JF1. Attach Reset it to the hardware reset switch on the Ground computer case. Refer to the table on the right for pin deﬁ...
Page 28: Serial Ports
H8QM3-2+/H8QMi-2+ User's Manual Serial Ports Serial Port Pin Deﬁ nitions (COM1, COM2) Pin # Deﬁ nition Pin # Deﬁ nition The COM1 serial port is located beside the USB ports on the I/O backplane. COM2 is a header located near the SIMLC slot. Refer to the table on the right for pin deﬁ...
Page 29: Jlan1/2 (Ethernet Ports)
Chapter 2: Installation JLAN1/2 (Ethernet Ports) Two Gigabit Ethernet ports (desig- nated JLAN1 and JLAN2) are located beside the COM2 port. These Ethernet ports accept RJ45 type cables. PS/2 Keyboard and Mouse Port Pin ATX PS/2 Keyboard and Deﬁ nitions (J3) PS/2 Mouse Ports Pin# Deﬁ...
Page 30: Wake-On-Ring
H8QM3-2+/H8QMi-2+ User's Manual Wake-On-Ring The Wake-On-Ring header is desig- Wake-On-Ring Pin Deﬁ nitions nated JWOR. This function allows your (JWOR) computer to receive and "wake-up" by Pin# Deﬁ nition an incoming call to the modem when Ground (Black) in suspend state. See the table on the Wake-up right for pin deﬁ...
Page 31: Jumper Settings
Chapter 2: Installation Jumper Settings Explanation of Jumpers To modify the operation of the Connector serverboard, jumpers can be used Pins to choose between optional settings. Jumpers create shorts between two pins to change the function of the Jumper connector. Pin 1 is identiﬁ ed with a square solder pad on the printed cir- cuit board.
Page 32: Vga Enable/Disable
H8QM3-2+/H8QMi-2+ User's Manual VGA Enable/Disable VGA Enable/Disable Jumper Settings (JPG1) JPG1 allows you to enable or disable Jumper Setting Deﬁ nition the VGA port. The default position is on Pins 1-2 Enabled pins 1 and 2 to enable VGA. See the Pins 2-3 Disabled table on the right for jumper settings.
Page 33: Watch Dog Enable/Disable
IT ﬁ rmware ﬂ ash procedure. Flashing IT Firmware Download the appropriate IT ﬁ rmware from the web site: ftp://ftp.supermicro. com/driver/SAS/LSI/Firmware/IT/ Unzip it to a bootable ﬂ oppy or USB pen. With JPS1 on (closed) boot to the device with the unzipped ﬁ rmware and type "clear"...
Page 34: Onboard Indicators
H8QM3-2+/H8QMi-2+ User's Manual Onboard Indicators LAN1/LAN2 LEDs The Ethernet ports (located beside the VGA port) have two LEDs. On each Gb LAN port, one LED indicates LAN LED activity when blinking while the other (Connection Speed Indicator) LED may be amber or off to indicate LED Color Deﬁ...
Page 35: Floppy, Ide, Sata And Sas Drive Connections
Chapter 2: Installation Floppy, IDE, SATA and SAS Drive Connections Use the following information to connect the ﬂ oppy and hard disk drive cables. • The ﬂ oppy disk drive cable has seven twisted wires. • A red mark on a wire typically designates the location of pin 1. •...
Page 36: Ide Connector
H8QM3-2+/H8QMi-2+ User's Manual IDE Drive Connector Pin Deﬁ nitions (IDE) Pin# Deﬁ nition Pin # Deﬁ nition Reset IDE Ground Host Data 7 Host Data 8 Host Data 6 Host Data 9 Host Data 5 Host Data 10 Host Data 4 Host Data 11 Host Data 3 Host Data 12...
Page 37: Sas Ports
Chapter 2: Installation SAS Ports SAS Ports Pin Deﬁ nitions (JSM1/JSM2) There are two SAS ports, one Pin # Deﬁ nition located on the backplane and Ground the other on the serverboard near the ﬂ oppy connector. See the table on the right for pin Ground deﬁ...
Page 38: 2-10 Enabling Sata Raid
H8QM3-2+/H8QMi-2+ User's Manual 2-10 Enabling SATA RAID Note: For SAS RAID, please refer to LSI manual on the driver CD. Serial ATA (SATA) Serial ATA (SATA) is a physical storage interface that employs a single cable with a minimum of four wires to create a point-to-point connection between devices. This connection is a serial link.
Page 39: Enabling Sata Raid In The Bios
Chapter 2: Installation Enabling SATA RAID in the BIOS Before installing the Windows Operating System, you must change some settings in BIOS. Boot up the system and hit the <Del> key to enter the BIOS Setup Utlility. After the Setup Utility loads, perform the following steps: Use the arrow keys to move to the Exit menu.
Page 40 H8QM3-2+/H8QMi-2+ User's Manual After you have ﬁ nshed, press the <Ctrl> and <X> keys simultaneously. Figure 2-5 shows a list of arrays that have been set up with the utility. Installing the OS and Drivers With the Windows OS installation CD in the CD-ROM drive, restart the sys- tem.
Page 41 Chapter 2: Installation Figure 2-4. SATA RAID Utility: Main Screen Figure 2-5. SATA RAID Utility: Array List 2-23...
Page 42: 2-11 Installing Software Drivers
2-11 Installing Software Drivers After all the hardware and operating system have been installed, you need to install certain drivers. The necessary drivers are all included on the Supermicro CD that came packaged with your serverboard. After inserting this CD into your CD-ROM drive, the display shown in Figure 2-6 should appear.
Page 43: Chapter 3 Troubleshooting
Chapter 3: Troubleshooting Chapter 3 Troubleshooting Troubleshooting Procedures Use the following procedures to troubleshoot your system. If you have followed all of the procedures below and still need assistance, refer to the ‘Technical Support Procedures’ and/or ‘Returning Merchandise for Service’ section(s) in this chapter. Always disconnect the AC power cord before adding, changing or installing any hardware components.
Page 44: No Power
H8QM3-2+/H8QMi-2+ User's Manual No Power Checklist Make sure that no short circuits exist between the serverboard and the chas- sis. Verify that all jumpers are set to their default positions. Check that the 115V/230V switch on the power supply is properly set. Turn the power switch on and off to test the system.
Page 45: Losing The System's Setup Conﬁ Guration
Chapter 3: Troubleshooting Losing the System’s Setup Conﬁ guration Checklist Make sure that you are using a high quality power supply. A poor quality power supply may cause the system to lose the CMOS setup information. Refer to Section 1-6 for details on recommended power supplies. The battery on your serverboard may be old.
Page 46: Frequently Asked Questions
H8QM3-2+/H8QMi-2+ User's Manual Frequently Asked Questions Question: What type of memory does my serverboard support? Answer: The H8QM3-2+/H8QMi-2+ supports up to 128 GB of registered ECC DDR2-667/533/400 SDRAM with four CPUs installed. In a dual-CPU conﬁ guration the maximum memory support is 64 GB and in a single-CPU conﬁ guration the maxi- mum memory support is 32 GB.
Page 47: Returning Merchandise For Service
For faster service, RMA authorizations may be requested online (http://www. supermicro.com/support/rma/). The warranty only covers normal consumer use and does not cover damages in- curred in shipping or from failure due to the alteration, misuse, abuse or improper maintenance of products.
Page 48 H8QM3-2+/H8QMi-2+ User's Manual Notes...
Page 49: Chapter 4 Bios
Chapter 4: BIOS Chapter 4 BIOS Introduction This chapter describes the AMIBIOS™ Setup utility for the H8QM3-2+/H8QMi-2+. The AMI ROM BIOS is stored in a ﬂ ash chip and can be easily upgraded using a ﬂ oppy disk-based program. Note: Due to periodic changes to the BIOS, some settings may have been added or deleted and might not yet be recorded in this manual.
Page 50: Main Menu
H8QM3-2+/H8QMi-2+ User’s Manual Main Menu When you ﬁ rst enter AMI BIOS Setup Utility, you will see the Main Menu screen. You can always return to the Main Menu by selecting the Main tab on the top of the screen with the arrow keys. The Main Menu screen provides you with a system overview, which includes the version, built date and ID of the AMIBIOS, the type, speed and number of the processors in the system and the amount of memory installed in the system.
Page 51 Chapter 4: BIOS PS/2 Mouse Support Set this value to modify support for a PS/2 mouse. The options are Auto, En- abled and Disabled. Wait for ‘F1’ If Error Select Enable to activate the Wait for F1 if Error function. The options are En- abled and Disabled.
Page 52 H8QM3-2+/H8QMi-2+ User’s Manual Power Conﬁ guration: Power Button Mode Allows the user to change the function of the power button. Options are On/Off and Suspend. Restore on AC Power Loss This setting allows you to choose how the system will react when power returns after an unexpected loss of power.
Page 53 Chapter 4: BIOS SVM uCode Option This setting is used to Enable or Disable processor-assisted virtualization. Power Now This setting is used to Enable or Disable the AMD Power Now feature. Thermal Throttling This setting is used to Enable or Disable Thermal Throttling. Floppy/IDE/SATA Conﬁ...
Page 54 H8QM3-2+/H8QMi-2+ User’s Manual LBA/Large Mode LBA (Logical Block Addressing) is a method of addressing data on a disk drive. The options are Disabled and Auto. Block (Multi-Sector Transfer) Block mode boosts IDE drive performance by increasing the amount of data transferred.
Page 55 Chapter 4: BIOS Serial ATA0/1/2 Primary/Secondary Channel Highlight one of the items above and press <Enter> to access the submenu for that item. If a drive is present, information on that drive will be displayed here. Type Select the type of device connected to the system. The options are Not Installed, Auto, CDROM and ARMD.
Page 56 H8QM3-2+/H8QMi-2+ User’s Manual S.M.A.R.T. Self-Monitoring Analysis and Reporting Technology (SMART) can help predict impending drive failures. Select "Auto" to allow BIOS to auto detect hard disk drive support. Select "Disabled" to prevent AMI BIOS from using the S.M.A.R.T. Select "Enabled" to allow AMI BIOS to use the S.M.A.R.T. to support hard drive disk.
Page 57 Chapter 4: BIOS PCI/PnP Conﬁ guration Clear NVRAM Select Yes to clear NVRAM during boot-up. The options are Yes and No. Plug & Play OS Select Yes to allow the OS to conﬁ gure Plug & Play devices. (This is not required for system boot if your system has an OS that supports Plug &...
Page 58 H8QM3-2+/H8QMi-2+ User’s Manual IRQ3/IRQ4/IRQ5/IRQ7/IRQ9/IRQ10/IRQ11/IRQ14/IRQ15 This feature speciﬁ es the availability of an IRQ to be used by a PCI/PnP device. Select Reserved for the IRQ to be used by a Legacy ISA device. The options are Available and Reserved. DMA Channel 0/Channel 1/Channel 3/Channel 5/Channel 6/Channel 7 Select Available to indicate that a speciﬁ...
Page 59 Chapter 4: BIOS Chipset Conﬁ guration NorthBridge Conﬁ guration Memory Conﬁ guration Memclock Mode This setting determines how the memory clock is set. Auto has the memory clock by code and Limit allows the user to set a standard value. MCT Timing Mode Sets the timing mode for memory.
Page 60 H8QM3-2+/H8QMi-2+ User’s Manual DRAM ECC Enable DRAM ECC allows hardware to report and correct memory errors automati- cally. Options are Enabled and Disabled. 4-Bit ECC Mode Allows the user to enabled 4-bit ECC mode (also known as ECC Chipkill). Options are Enabled and Disabled. DRAM Scrub Redirect Allows system to correct DRAM ECC errors immediately, even with background scrubbing on.
Page 61 Chapter 4: BIOS PCIE Spread Spectrum Allows you to Enable or Disable spread spectrum for PCI-Express. SATA Spread Spectrum Enables spread spectrum for the SATA. Options are Enabled and Disabled. Primary Graphics Adapter Options are PCI Express PCI and PCI PCI Express.
Page 62 H8QM3-2+/H8QMi-2+ User’s Manual Event Log Conﬁ guration View Event Log Highlight this item and press <Enter> to view the contents of the event log. Mark All Events as Read Highlight this item and press <Enter> to mark all events as read. Clear Event Log Select Yes and press <Enter>...
Page 63 Chapter 4: BIOS VT-UTF8 Combo Key Support Allows you to Enable or Disable VT-UTF8 combination key support for ANSI/ VT100 terminals. Sredir Memory Display Delay Use this setting to set the delay in seconds to display memory information. Op- tions are No Delay, 1 sec, 2 secs and 4 secs. System Health Monitor CPU Overheat Temperature Use the "+"...
Page 64: Boot Menu
H8QM3-2+/H8QMi-2+ User’s Manual Boot Menu This feature allows the user to conﬁ gure the following items: Boot Device Priority This feature allows the user to prioritize the boot sequence from the available de- vices. The devices to set are: · 1st Boot Device ·...
Page 65: Security Menu
Chapter 4: BIOS Security Menu AMI BIOS provides a Supervisor and a User password. If you use both passwords, the Supervisor password must be set ﬁ rst. Change Supervisor Password Select this option and press <Enter> to access the sub menu, and then type in the password.
Page 66: Exit Menu
H8QM3-2+/H8QMi-2+ User’s Manual Exit Menu Select the Exit tab from AMI BIOS Setup Utility screen to enter the Exit BIOS Setup screen. Save Changes and Exit When you have completed the system conﬁ guration changes, select this option to leave BIOS Setup and reboot the computer, so the new system conﬁ guration parameters can take effect.
Page 67: Appendix A Bios Error Beep Codes
Appendix A: BIOS Error Beep Codes Appendix A BIOS Error Beep Codes During the POST (Power-On Self-Test) routines, which are performed each time the system is powered on, errors may occur. Non-fatal errors are those which, in most cases, allow the system to continue the boot-up process.
Page 68 H8QM3-2+/H8QMi-2+ User’s Manual Notes...
Page 69: Appendix B Bios Post Checkpoint Codes
Appendix B: BIOS POST Checkpoint Codes Appendix B BIOS POST Checkpoint Codes When AMIBIOS performs the Power On Self Test, it writes checkpoint codes to I/O port 0080h. If the computer cannot complete the boot process, diagnostic equipment can be attached to the computer to read I/O port 0080h. B-1 Uncompressed Initialization Codes The uncompressed initialization checkpoint codes are listed in order of execution: Checkpoint...
Page 70 H8QM3-2+/H8QMi-2+ User's Manual B-2 Bootblock Recovery Codes The bootblock recovery checkpoint codes are listed in order of execution: Checkpoint Code Description The onboard floppy controller if available is initialized. Next, beginning the base 512 KB memory test. Initializing the interrupt vector table next. Initializing the DMA and Interrupt controllers next.
Page 71 Appendix B: BIOS POST Checkpoint Codes B-3 Uncompressed Initialization Codes The following runtime checkpoint codes are listed in order of execution. These codes are uncompressed in F0000h shadow RAM. Checkpoint Code Description The NMI is disabled. Next, checking for a soft reset or a power on condi- tion.
Page 72 H8QM3-2+/H8QMi-2+ User's Manual Checkpoint Code Description Interrupt vector initialization is done. Clearing the password if the POST DIAG switch is on. Any initialization before setting video mode will be done next. Initialization before setting the video mode is complete. Conﬁ guring the mono- chrome mode and color mode settings next.
Page 73 Appendix B: BIOS POST Checkpoint Codes Checkpoint Code Description The memory below 1 MB has been cleared via a soft reset. Clearing the memory above 1 MB next. The memory above 1 MB has been cleared via a soft reset. Saving the memory size next.
Page 74 H8QM3-2+/H8QMi-2+ User's Manual Checkpoint Code Description The password was checked. Performing any required programming before WINBIOS Setup next. The programming before WINBIOS Setup has completed. Uncompressing the WINBIOS Setup code and executing the AMIBIOS Setup or WINBIOS Setup utility next. Returned from WINBIOS Setup and cleared the screen.
Page 75 Appendix B: BIOS POST Checkpoint Codes Checkpoint Code Description Returned from adaptor ROM at E000h control. Performing any initialization required after the E000 option ROM had control next. Initialization after E000 option ROM control has completed. Displaying the system configuration next. Uncompressing the DMI data and executing DMI POST initialization next.
Page 76 H8QM3-2+/H8QMi-2+ User's Manual Notes...
