Accessing The Utility; The Home Screen - Cisco Linksys NSLU2 Quick Installation Manual

4
Configuring the Network Storage Link
For advanced users, a web-
based utility has been pro-
grammed into the Network
Storage Link. This section will
explain some of the functions
in this web utility. All adminis-
trative tasks are performed
through this web utility. The
web utility can be accessed
by any PC on the network by
entering http://192.168.1.77
in the PC's web browser
Address window.
After you press the Enter key,
the Home screen will appear.
Click the Administration tab
to configure the Network Stor-
age Link and the Administra-
tion screen will appear
NOTE:
as FAT32 or NTFS, then you will not be
able to use the Users, Groups, or
Backup features of the Network
Storage Link. These features will only
work with EXT3-formatted drives.

Accessing the Utility

The Home screen

The Administration screen
If your USB drive is formatted
9
