atX 24-Pin Power Connector: JPWR
this connector allows you to connect an atX 24-pin power supply. to connect the
atX 24-pin power supply, make sure the plug of the power supply is inserted in
the proper orientation and the pins are aligned. then push down the power supply
firmly into the connector.

atX 4-Pin Power Connector: JPWR2

this 4-Pin power connector is used to provide power to the CPu.
imPoRtant
make sure that all the connectors are connected to proper atX power supplies to
ensure stable operation of the mainboard.
ide Connector: ide
this connector supports ide hard disk drives, optical disk drives and other ide
devices.
imPoRtant
if you install two ide devices on the same cable, you must configure the drives
to cable select mode or separately to master / slave mode by setting jumpers.
Refer to ide device documentation supplied by the vendors for jumper setting
instructions.
6
