Connections

NOTE: Do not connect/disconnect cables when turning on the monitor or other external equipment as this may result in a
loss of the monitor image.
NOTE: Use an audio cable without a built-in resistor. Using an audio cable with a built-in resistor turns down the sound.
Before making connections:
* First turn off the power of all the attached equipment and make connections.
* Refer to the user manual included with each separate piece of equipment.

Wiring Diagram

Computer (Analog)
*: Multiple monitors that are daisy-chained have a limit to the connectable monitors.
Connected Connecting
equipment terminal
DVI (DVI-D)
HDMI
VGA (D-Sub) +VIDEO1
AV VIDEO1 (BNC)
VGA (D-Sub)
VGA (D-Sub)
VGA (D-Sub)
VGA (D-Sub)
DVI (DVI-D)
PC
DisplayPort
HDMI
*1: depend on signal type.
DVD player
DVD player
with HDMI out
Computer (Digital)
Setting in Terminal Mode
DVI MODE: DVI-HD
1
RAW/EXPAND*
D-SUB MODE: SCART
-
D-SUB MODE: S-VIDEO
D-SUB MODE: VIDEO
D-SUB MODE: COMPONENT
-
DVI MODE: DVI-PC
-
RAW/EXPAND* 1
English-14
Solid lines = video signal
Dotted lines = audio signal
Second monitor*
VCR or
DVD Player
Connecting
Input signal name
Audio terminal
DVI AUDIO IN1
HDMI HDMI
SCART AUDIO IN1
VIDEO1 AUDIO IN1
S-VIDEO AUDIO IN1
VIDEO2 AUDIO IN1
DVD/HD2 AUDIO IN1
VGA AUDIO IN1
DVI AUDIO IN1
DPORT DPORT
HDMI HDMI
Stereo Amplifi er
DVD player with
SCART OUT
Input button
in remote control
DVI
HDMI
DVD/HD
VIDEO
S-VIDEO
VIDEO
DVD/HD
VGA
DVI
DISPLAYPORT
HDMI
