  • Page 1 Powerline AV+ 200 Nano Dual-Port XAV2602 Installation Guide...
  • Page 2 See http://support.netgear.com/app/answers/detail/a_id/984. Trademarks NETGEAR, the NETGEAR logo, and Connect with Innovation are trademarks and/or registered trademarks of NETGEAR, Inc. and/or its subsidiaries in the United States and/or other countries. Information is subject to change without notice. Other brand and product their names are registered trademarks or trademarks of respective holders.

  • Page 3: Package Contents

    Package Contents Products sold in some locations include a Resource CD. Ethernet cable Powerline AV+ 200 (North America) Your adapter might look like one of these: Germany/Europe Australia Switzerland France...

  • Page 4: Hardware Features

    Hardware Features Filtered AC socket Factory Reset Power LED button Powerline LED Security Ethernet LED button Ethernet Port 2 for Ethernet Port 1 lower-priority data for higher- traffic priority traffic...
  • Page 5 LEDs The LEDs indicate the status of your Powerline adapter. • When you plug in the adapter, the Power LED lights up and turns green. • The adapter is not active when no Ethernet link has occurred for more than 10 minutes. The adapter enters power saving mode, and the Power LED turns amber •...

  • Page 6: Compatible Netgear Powerline Devices

    To create a Powerline network you need at least two compatible Powerline devices. Your Powerline adapter can share a Powerline network with these compatible NETGEAR devices: XAV101, XAV1004, XAV2001, XAV2101, XAV1101, XAV1301, XAV1601, XAV2501, XAV5001, XAV5501, XAV5601, XAV5004, and XAVN2001.

  • Page 7: Install Your Powerline Adapter

    Install Your Powerline Adapter The filtered AC The ports use Quality socket removes of Service (QoS) to some electrical prioritize traffic. Port 1 noise. Plugging on the left is the high- a nearby device priority video port. into the filtered AC socket improves performance.
  • Page 8 You can set up a new Powerline network with your XAV2602 and a compatible Powerline device, or you can add your XAV2602 to an existing Powerline network. Set up a new Powerline network: Obtain at least one more Powerline device that is compatible with the XAV2602.
  • Page 9 2 seconds and release the button. Then within 2 minutes, press the Security button on the XAV2602 for 2 seconds and release the button. The Power LED on the XAV2602 starts to blink as security is setting up.
  • Page 10 Check to make sure that the Powerline devices you already use are compatible. Plug the XAV2602 adapter into another electrical outlet. The XAV2602 will start to communicate with other Powerline devices (indicated by the linking Powerline LED). Use Ethernet cables (one is included in the package) to connect your equipment to the Ethernet ports on the adapter.

  • Page 11: Secure Your Powerline Network

    Secure Your Powerline Network A Powerline network forms when at least two compatible Powerline devices communicate. After the Powerline network is up and running, you can use the Security buttons on the adapters to add encryption to your Powerline network. CAUTION: Do not press the Security button until each adapter has powered up and its Power LED is solid green.

  • Page 12: Technical Support

    For additional information about setting up, configuring, and using your Powerline AV+ 200 Adapter, see the User Manual For complete DoC please visit the NETGEAR EU Declarations of Conformity website at: http://support.netgear.com/app/answers/detail/a_id/11621/ For GNU General Public License (GPL) related information, please visit the NETGEAR support site at: http://support.netgear.com/app/answers/detail/a_id/2649...

  • Page 13: Safety Information

    Safety Information • AC input:100-125V~, 0.2A max in North America and 200-250V~, 0.2A max in other regions, for the XAV2602. • Operating temperature: 0C to 40C • The socket-outlet shall be installed near the equipment and be easily accessible. •...
  • Page 14 • If the input AC voltage is less than 125Vac, the device plugged into the filtered AC socket of the Powerline adapter might not perform as well as expected. • DO NOT PLUG MAJOR HOME APPLIANCES into the filtered AC socket or into an attached power strip.
  • Page 15 Compliance This symbol was placed in accordance with the European Union Directive 2002/ 96 on the Waste Electrical and Electronic Equipment (the WEEE Directive). If disposed of within the European Union, this product should be treated and recycled in accordance with the laws of your jurisdiction implementing the WEEE Directive.
  • Page 16 NETGEAR, Inc. 350 East Plumeria Drive San Jose, CA 95134, USA June 2011...
