FS116P IG 21sept12.fm Page 1 Friday, September 21, 2012 11:17 AM
Installation Guide
ProSafe 16-Port Ethernet Switch with
8-Port PoE FS116P
Step 1. Connect equipment
Computer
Server
FS116P
Optional router
Step 2. Connect power
Internet
Optional
modem
Step 3. Check status
Power LED
Port 1-8 right LEDs
On
PoE in use
PoE fault
Off
No PoE use (off)
Port 1-8 left LEDs
PoE Max. LED
Less than 7W of
100 Mbps link
PoE power is available
PoE MAX LED was
10 Mbps link
active in the previous
2 minutes
Activity (blinking)
PoE ports are
working normally (off)
No link (off)
Port 9-16 LEDs
100 Mbps link
(left LED
10 Mbps link
(right LED
Activity (blinking)
No link (off)
