Please Read The Following Carefully; Parts List - Central Machinery 35098 Operating Instructions Manual

pleaSe reaD tHe FOllOWinG careFully

THE MANUFACTURER AND/OR DISTRIBUTOR HAS PROVIDED THE PARTS LIST AND ASSEMBLY
DIAGRAM IN THIS MANUAL AS A REFERENCE TOOL ONLY. NEITHER THE MANUFACTURER OR
DISTRIBUTOR MAKES ANY REPRESENTATION OR WARRANTY OF ANY KIND TO THE BUYER THAT
HE OR SHE IS qUALIFIED TO MAKE ANY REPAIRS TO THE PRODUCT, OR THAT HE OR SHE IS
qUALIFIED TO REPLACE ANY PARTS OF THE PRODUCT. IN FACT, THE MANUFACTURER AND/OR
DISTRIBUTOR EXPRESSLY STATES THAT ALL REPAIRS AND PARTS REPLACEMENTS SHOULD BE
UNDERTAKEN BY CERTIFIED AND LICENSED TECHNICIANS, AND NOT BY THE BUYER. THE BUYER
ASSUMES ALL RISK AND LIABILITY ARISING OUT OF HIS OR HER REPAIRS TO THE ORIGINAL
PRODUCT OR REPLACEMENT PARTS THERETO, OR ARISING OUT OF HIS OR HER INSTALLATION
OF REPLACEMENT PARTS THERETO.
part Description
1 Gear Box Cover
2 Gear Shaft
3 Rotor
4 Gear Casing
5 Gear
6 Pin 5 x 25
7 Washer #12
8 Inner Flange
9 Wet Grinding Wheel
10 Outer Flange
11 Nut M12
12 Screw M5 x 12
13 Toothed Washer
14 End Bell
15 Screw M5 x 35
16 Stator
17 Motor Case
18 Bearing 6202zz
19 Screw M4 x 12
20 Washer #4
22 Water Reservoir
23 Worm Gear
24 Bolt M4 x 8
25 Plug
26 Screw M5 x 10
27 Capacitor
28 Strain Relief
29 Cable with Plug
30 Capacitor Holder
31 Plug-in Wire Lead
33 Wire Case
34 Washer #1
35 Washer Support #1
36 Bushing #1
SKU 35098 For technical questions, please call 1-800-444-3353.

partS liSt

Qty part
1 37 Base Plate
1 38 Rubber Pad
1 39 Motor Base
1 40 Bolt M8 x 25
1 41 Washer #2
2 42 Power Switch
2 43 Switch Plate
1 44 Bolt M3 x 12
1 45 Washer #6
1 47 Knob
1 48 Washer #6
8 49 Bolt M6 x 14
22 50 Spark Guard
2 51 Screw M5 x 0.8 x 55
8 52 Nut M5
1 53 Dry Grinding Wheel Cover
1 54 Tool Rest
2 55 Nut M14
3 56 Outer Flange
7 57 Inner Flange
1 59 Dry Grinding Wheel
1 60 Eye Shield
1 61 Screw M4 x 12
1 62 Nut M8
3 63 Wire Tie
1 65 Screw M4 x 5
1 66 Screw M5 x 8
1 67 Eyeshield Bracket
1 68 Eyeshield Mount
2 69 Bolt M6 x 10
5 70 Toothed Washer #6
1 71 Washer #6
1 72 Internal Toothed Washer M5 (not
1 shown in Assembly Diagram)
Description Qty
1
4
1
2
2
1
1
2
2
1
1
1
1
3
3
1
1
1
1
1
1
1
1
2
1
2
2
1
1
1
1
1
3
Page 14
