MS-1 and MS-1WL
Switcher Accessories for Compatible Hitachi 3LCD Projectors
Easy-to-use accessories offer expanded
wireless connectivity.
Receiver
MS-1WL Key Features and Benefits
Upon purchase of the MS-1WL, the WHDI
transmitter comes equipped, inserted and
already paired upon delivery.
Built-in networking capabilities to allow for
LAN connectivity, WIFI connectivity, PC-less
presentations and more. Optional
USB-WL-11N needed for WIFI connectivity.
Can control switcher via RS232, IP, optional
hard wired remote control or Hitachi's PJ
Quick Connection (iPad
and iPhone
®
or top panel button access control for direct
response.
Top button access for switching control
for simpler installs where you have switcher
on desk or podium.
Built-in microphone capabilities to connect
directly to switcher to utilize with projector
speakers.
Many more innovative features from Hitachi
projectors integrated into switcher.
Our iOS application Projector Quick
Connection App offers simple control
options including sending photo and
document files and web site contents
for the MS-1 and
MS-1WL.
1.800.HITACHI
dmd.info@hal.hitachi.com
hitachi-america.us/projectors
Switcher
MS-1WL Wireless Multifunction Switcher
The MS-1WL Wireless Multifunctional Switcher operates in conjunction with the receiver to
provide expanded source selection and switching options for connected devices. It offers a
10 input selector including computer, HDMI, USB, RGB, video, LAN and other connections.
As a user option, the MS-1 is sold separately and offers all the functions of the MS-1WL with
the exception of wireless operation. It connects to a Hitachi projector using an HDMI cable.
Ten input selector—HDMI, USB, computer, video and LAN. Plus additional
connections on back panel.
MS-1WL is a simple wireless installation using the receiver or a wired installation
using one HDMI cable.
) utility,
®
The MS-1 offered separately as a wired installation using one HDMI cable. Ten input
selector—HDMI, USB, computer, video and LAN. Plus additional connections on
back panel.
Input Selector
Switcher Terminals
Switcher Accessories
HDMI/WHDI Indicator
Switcher Controls
