Haan FS-50 User Manual

Steam cleaning floor sanitizer
Hide thumbs
Table of Contents

Advertisement

Quick Links

Steam Cleaning
Floor
Sanitizer
FS-50/FS50+
The Fast, Easy Way
to Sanitize and
Clean Your Floors
for a Fresh and
Healthy Home!
U se r Ma n ua l
®

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the FS-50 and is the answer not in the manual?

Questions and answers

Related Manuals for Haan FS-50

Summary of Contents for Haan FS-50

  • Page 1 ® Steam Cleaning Floor Sanitizer FS-50/FS50+ The Fast, Easy Way to Sanitize and Clean Your Floors for a Fresh and Healthy Home! U se r Ma n ua l...
  • Page 2 Copyright ©2010 HAAN Corporation ® Notice The information contained in this document is subject to change without notice. HAAN Corporation assumes no ® responsibility for any errors that may appear in this document nor does it make expressed or implied warranty of...
  • Page 3 FS-50 Steam ® Cleaning Floor Sanitizer. Step up to a cleaner, healthier home with the FS-50. Designed with an ergonomic pistol grip handle and pole that’s easier on your back, the FS-50 makes it simple to clean and sanitize every sealed hard surface floor in your home with the power of steam.

  • Page 4: Important Safety Information

    CaUtion Customer Service for instructions. 10. Do not handle Floor Sanitizer with wet hands. The FS-50 emits steam at 11. Do not pull or carry by cord, use cord as a handle, 212˚F to sanitize the area close door on cord, bend the cord excessively, pull cord of use.
  • Page 5 Grounded The HAAN FS-50 must be connected to a grounded (3-prong) Outlet Grounded wiring system. Grounding provides a safe path of least resistance for electrical current, in the event the unit should malfunction or break down thereby reducing the risk of elec- trical shock.

  • Page 6: Steam Cleaning

    FS-50 Steam Cleaning Floor Sanitizer Included Accessories: Carpet Tray (1; included Floor Protector/ Fill Cup (1) Ultra-Microfiber with FS-50 + ) Resting Mat (1) Pad (2) www. HA ANUS A.com pg 4 877- HAA N D I RECT / 877-422-6347...
  • Page 7 Ultra-Microfiber Pad may be cleaning – place on the floor with the “bumpy” side facing up. used to act as a “blotter” for 15. Carpet Tray (1; included with FS-50+) - easily attaches to removing most fresh, wet spills and stains.
  • Page 8 After unpacking the FS-50, identify Unit Head the product parts before assembling. Pay specific attention to the product descriptions to familiarize yourself with all the parts of your FS-50 Floor Sanitizer. No additional tools Lower are needed to put the unit together. It Ergonomic is quick and easy.
  • Page 9 While it is acceptable to use regular Never use your FS-50 without a cleaning pad attached to the base. tap water, if the tap water in your area is hard, we...

  • Page 10: Operating Instructions

    FS-50. The Orange button is the POWER button only. To release the handle/pole, simply place your foot gently on top of the FS-50 and pull back. Fig 5 Your FS-50 is ready to use when the Thermal Indicator on the tank cap changes from black to orange.
  • Page 11 10) When there is no more water in the tank, the RED Refill Light will illuminate (Fig 7). 11) To refill the Water Tank, turn your FS-50 off, unplug it from the electrical wall outlet and let the unit cool for 30 seconds. Then remove the fill cap and pour in the water.
  • Page 12 Simply place the pad on the floor with the Fig 12 ‘hook & loop’ side up (Fig 12), and lightly press the FS-50 Floor Sanitizer down on the pad. ‘Hook & Loop’ Strips As high temperature steam passes through a pad to contact the floor to kill germs, molds and mites, it is natural that the pad gradually absorbs moisture.
  • Page 13 (Steps 4-8, pg 8). Fig 14 With pad in place (Fig 14), put the FS-50 over the stain and hold it in place for a few seconds to allow the steam to penetrate the area of the stain.
  • Page 14 To attach the tray, make sure the high back tabs are at the back of the unit. (Fig 17) Then simply tilt the Front FS-50 so the front of the steam head slips under the Clips front clips, press down until the back tabs snap Fig 18 over the back lip of the steam head.
  • Page 15 Remove the Sanitizing Tray by using your foot to pull back on the silver bar and then holding the tray with your foot, lift the FS-50 off the tray. The tray is designed for this No Touch method of removal. (Fig 21)

  • Page 16: Helpful Hints

    The FS-50 does not have any suction power. The easiest way to use the FS-50 is to tilt the handle to a 45° angle and then push and pull the unit slowly across each section of your floor – approximately 2 to 3 yards at a time.

  • Page 17: Care And Maintenance

    We recommend that you air dry the pads for 24 hours, but they can also be dried in a clothes dryer on a low heat setting. To clean the body of your FS-50, wipe it rotates down with a damp cloth.
  • Page 18 ‘Lime & Scale Remover’ every 2 or 3 months to Keep the Fresh Rinse Lime ™ ensure optimum functionality from your Haan ® & Scale remover in a cool, Floor Sanitizer. You can purchase this directly from dry place. Keep out of reach the Haan web site (see below).
  • Page 19 Steam Cleaning Floor Sanitizer on the mat (with the “bumpy” side facing up) as soon as you assemble your unit and before you fill the Water Tank. The FS-50 should remain on the Pad while it heats up, AND you should always set your FS-50 on the mat if you need to take a quick break from steaming.
  • Page 20 (with the white hook & loop side facing up) and set the base of the FS-50 on top of it. The hook & loop system will cause the pad to attach itself easily, so you won’t have to touch it.
  • Page 21 QUestioN: Will the Haan Fs-50 clean grout? ® Yes, but it needs a little help. If you glide your Haan over ® the problem grout areas allowing the steam to soften the surface dirt and then scrub with your standard blue Ultra- Microfiber Pad, it should effectively clean surface dirt off your grout.
  • Page 22 11, steps 1-8. QUestioN: Where does the dirt go? The FS-50 is NOT a vacuum, so it does not have any suction power to pick up dirt. Be sure to vacuum or sweep up any loose dirt before using your FS-50 Steam Cleaning Floor Sanitizer.

  • Page 23: Troubleshooting

    Possible Solution: 1) Check plug in outlet and set plug firmly. 2) Check fuse or breaker. Replace fuse and/or reset breaker. PRoBLeM: Fs-50 does not emit steam. Possible Cause: 1) No water in water tank. Possible Solution: 1) Add water to the water tank following the instructions on page 9.

  • Page 24: Troubleshooting (Cont)

    Possible Solution: 1) Always place your FS-50 on the Floor Protector/ Resting Mat whenever not actively using it. Never leave the FS-50 in one spot on any surface for any period of time. 2) Use distilled water in the FS-50.

  • Page 25: One-Year Limited Warranty

    30 days of purchase. This is essential for your warranty to be effective should any problem arise with this product. Should any defect covered by the terms of the limited warranty be discovered within one year, Haan ® Corporation will repair or replace the defective part...
  • Page 26 www. HA ANUS A. com pg 2 4 877- H AAN DI RECT / 877-422-6347...

  • Page 27: Specifications

    Specifications Product Specifications: Model FS-50 Color Orange & Charcoal Grey Size: 51″ x 11.5″ x 7.5″ Weight 4 lbs Voltage/Hz 120 volts / 60 Hz Wattage 800 watts Cord Length 19’ 8” Tank Capacity 11.83 fluid ounces (350 ml )
  • Page 28 (Fold here and tape closed before mailing)
  • Page 29 Place ® Stamp Here Product Registration Haan Corporation ® 1866 Colonial Village Lane Lancaster, PA 17601...
  • Page 30 HAAN Corporation 1866 Colonial Village Lane Lancaster, PA 17601 w ww.HA A NU sA .c o m...
