NEC MultiSync
V322 DST (Single Touch)
®
1. Power (AC in)
2. Main switch (on/off)
3. LAN with SNMP
4. Remote Control in / out
5. External control RS-232 in / out
6. DisplayPort in
7. DVI in / out
8. HDMI in
9. RGB in
10. Composite in
11. Audio out
12. Audio in
SPECIAL CHARACTERISTICS
Advanced fan control, Copy display settings through RS232,
DICOM support, Hardware colour calibration possible, Input name
adjustment, Matrix memory, NaViSet Administrator 2, Optional
external programmable ambient light sensor, OSD rotation for
portrait mode, PIN as theft protection, Rapid input switching,
Scheduler, Screen saver functions, TileMatrix (10 x 10), User input
priority definition, Various picture in picture options
Energy Efficiency
ECOMode
Ecological Materials
Optional feet; Manuals on CD
Ecological Standards
Energy Star 5.1
Technical Specification NEC MultiSync
DISPLAY
Panel Technology
Active Screen Area (W x H) [mm]
Screen Size [inch/cm]
Aspect Ratio
Brightness (shipping) [cd/m
2
]
Contrast Ratio (typ.)
Viewing Angle [°]
Response Time (typ.) [ms]
Panel Refresh Rate [Hz]
SYNCHRONISATION RATE
Horizontal Frequency [kHz]
Vertical Frequency [Hz]
RESOLUTION
Native Resolution
Supported on digital and analogue inputs (PC)
Supported on digital inputs (Video)
CONNECTIVITY
Input Video Analogue
Input Video Digital
Input Audio Analogue
Input Audio Digital
Input Control
Output Video Digital
Output Audio Analogue
Output Control
Remote Control
OPTION SLOT
Slot Technology
Inrush Current [A]
Power Consumption [W]
Voltage / Current [V/A]
ELECTRICAL
Power Consumption on Mode [W]
Power Savings Mode [W]
Power Management
ENVIRONMENTAL CONDITIONS
Operating Temperature [°C]
Operating Humidity [%]
Storage Humidity [%]
Storage Temperature [°C]
MECHANICAL
Dimensions (W x H x D) [mm]
Weight [kg]
Bezel Width [mm]
VESA Mounting [mm]
AVAILABLE OPTIONS
Accessories
Option Slot
ADDITIONAL FEATURES
Safety and Ergonomics
Plug and Play
Audio
Shipping Content
Warranty
TOUCH
Protection Glass
Input Method
Light Transmission [%]
Reflection Rate [%]
Driver
Communication Protocol
V322 DST (Single Touch)
®
S-PVA with CCFL backlights
697.7 x 392.3
31.5 / 80
16:9
340, (420 max)
3000:1
178 horizontal / 178 vertical (typ. at contrast ratio 10:1)
8 (grey-to-grey)
60
31.5 - 91.1 (analog and digital)
50 - 85
1366 x 768 at 60 Hz
1920 x 1080; 1680 x 1050; 1600 x 1200; 1400 x 1050; 1366 x 786; 1360 x 768;
1280 x 1024; 1280 x 960; 1280 x 800; 1280 x 768; 1280 x 720; 1024 x 768; 800 x
600; 720 x 576; 720 x 400; 640 x 480
1920 x 1080i (59.94/60)16:9; 1920 x 1080p (59.94/60)16:9; 1920 x 1080p (50)
16:9; 1920 x 1080p (23.97/24)16:9; 1920 x 1080p (25)16:9; 1920 x 1080p
(29.97/30)16:9; 1280 x 720p (50)16:9; 720 x 576p (50)16:9; 720 x 480p
(59.94/60)16:9
D-Sub15 (PC RGB, Component, S-Video, Composite) Composite (BNC)
1 x DVI-D (with HDCP); 1 x HDMI 1.3 (with HDCP); 1 x DisplayPort (with HDCP)
1 x 3,5 mm jack
DisplayPort; 1 x HDMI
LAN 100Mbit; remote control wire (3,5mm jack); RS232
1 x DVI-D (with HDCP)
3,5mm jack
remote control wire (3,5mm jack); RS232
LAN with SNMP; RS-232C (9-pin D-sub) Input and Output; Remote Control IR
(internal/external (optional) sensor)
STv2 (compatible with Intel / NEC OPS standard)
max. 10
max. 61
16/4
90 shipping; 192 (max.)
< 0.5 (ECO Standby); < 1
VESA DPMS
+5 to +40
20 to 80
10 to 90
-20 to +60
Without stand: 786.8 x 476.2 x 100.5
Without stand: 14.1
43.2 (left and right); 40.3 (top and bottom)
200 x 200 (FDMI); 4 holes; M6
Feet (ST-322); Wall mount (PDW 32-70 L+P); Wall mount (PDW S 32-55 L/P)
Built-in PC; HD-SDI board
CE; TÜV GS; C-tick; Energy Star 5.1; FCC Class B; UL/C-UL or CSA; PSB; VCCI;
RoHS
VESA DDC2Bi
Integrated Speakers (8 W + 8 W)
Display; Power Cable; VGA cable; Free LAN control software (download); Remote
Control
3 years warranty incl. backlight
Chemically-strengthened glass substrate
Finger; Stylus; Gloves
92 (+/- 2%)
Anti-glare tech (low reflection)
MicroTouch MT7 for MicroTouch DST driver for Microsoft®; Windows 7;
Windows® 2000/XP/VISTA; HID-compliant
USB-HID
