D-Link DFE-550TX User Manual

Ethernet / fast ethernet adapter for pci bus with wol
Hide thumbs Also See for DFE-550TX:
Table of Contents

Advertisement

Quick Links

Download this manual See also: User Manual, Installation Manual
Model DFE-550TX
Ethernet / Fast Ethernet Adapter for PCI
Bus
with WOL
User's Guide
Rev. 03 July, 2000
6DFE550TX.03
Printed in Taiwan
RECYCLABLE

Advertisement

Table of Contents
loading

Related Manuals for D-Link DFE-550TX

Summary of Contents for D-Link DFE-550TX

  • Page 1 Model DFE-550TX Ethernet / Fast Ethernet Adapter for PCI with WOL User’s Guide Rev. 03 July, 2000 6DFE550TX.03 Printed in Taiwan RECYCLABLE...

  • Page 2: Wichtige Sicherheitshinweise

    D-Link DFE-550TX Ethernet Adapter Wichtige Sicherheitshinweise 1. Bitte lesen Sie sich diese Hinweise sorgfältig durch. 2. Heben Sie diese Anleitung für den spätern Gebrauch auf. 3. Vor jedem Reinigen ist das Gerät vom Stromnetz zu trennen. Vervenden Sie keine Flüssig- oder Aerosolreiniger.

  • Page 3: Limited Warranty

    Registration Card. If a Registration Card for the product in question has not been returned to a D-Link office, then a proof of purchase (such as a copy of the dated purchase invoice) must be provided when requesting warranty service. The term "purchase" in this software warranty refers to the purchase transaction and resulting licence to use such software.
  • Page 4 D-Link with such software product, for a period of ninety (90) days from the date of purchase from D-Link or its Authorized Reseller. D-Link warrants the magnetic media, on which D-Link provides its software product, against failure during the same warranty period.

  • Page 5: Copyright Statement

    D-Link Offices for Registration and Warranty Service The product's Registration Card, provided at the back of this manual, must be sent to a D-Link office. To obtain an RMA number for warranty service as to a hardware product, or to obtain warranty service as to a software product, contact the D-Link office nearest you.
  • Page 6 D-Link DFE-550TX Ethernet Adapter VCCI Class B Warning BSMI Warning...

  • Page 7: Table Of Contents

    D-Link DFE-550TX Ethernet Adapter Table of Contents INTRODUCTION ..............................1 ACPI P ..........................1 OWER ANAGEMENT LAN..............................1 ..............................1 ONTROL IP M ............................... 1 ULTICASTING DMI/D ......................2 ESKTOP ANAGEMENT NTERFACE IEEE802.1 ......................... 2 RIORITY AGGING IEEE802.1Q VLAN ............................2 ........................

  • Page 8: Introduction

    IP Multicasting is a much better way to send data to groups, especially since routers and even switches can filter packets so they only reach those stations that are part of the group. The DFE-550TX goes one step further by examining multicast packets on the card itself (rather than using the computer’s CPU) and only accepting those packets for the group(s) in which the host belongs, thus conserving CPU utilization.

  • Page 9: Dmi/Desktop Management Interface

    DMI supports a management schema (Management Information Format [MIF]), allowing manageable components to be described within various platforms in a standard descriptive language. MIFs are extensible, allowing the DFE-550TX to export value-added management capabilities. These value-added management features enable remote troubleshooting and higher quality management of computer resources.

  • Page 10: Traffic Management Statistics

    This is far greater than the three mandatory counters implemented by most other network interface cards. The large number of counters on the DFE-550TX allows network management applications to provide accurate and detailed statistics on a wide range of network attributes. The packet counters...

  • Page 11: Installation

    WOL Connector. After you have located the † The WOL Cable is an optional component of your DFE-550TX kit. If a cable is not included in your kit, purchase the cable through your local computer retailer.

  • Page 12: Connecting The Network Cable

    550TX and the supporting hub or switch is 100m. The cable must be straight-through (not a crossover cable), with an RJ-45 plug at each end. Make the network connection by plugging one end of the cable into the RJ-45 jack of the DFE-550TX, and the other end into a normal (non-Uplink) port on the supporting device.

  • Page 13: Verification/Diagnostic Program

    To run the Verification/Diagnostic Program, proceed with these steps: Adapter Function Test Insert the DFE-550TX Software CD-ROM in an available drive (here shown as drive A). At the DOS prompt (here shown as >), key in: > A:\DIAG.EXE and <RETURN>.

  • Page 14: Network Operation Test

    Verification/Diagnostic run. Skip the remaining steps shown below. Remove the DFE-550TX Software CD-ROM from your station's (the primary station's) CD-ROM drive, and insert it into an available drive of a second station on your LAN. At the DOS prompt (here shown as >), key in:...

  • Page 15: Troubleshooting

    LINK/ACT Indicator A steady green LED indicates that the card is receiving power and there is a good link between the DFE-550TX and the device it is connected to. The LED will flash when the adapter is sending or receiving data.

  • Page 16: Specifications

    Ethernet 10BASE-T IEEE 802.3 standard for 10Mbps baseband CSMA/CD local area network Jumperless Hardware NWay Auto-negotiation enabled Media interface: RJ-45 LAN Chip Set: Interface controller: D-Link DL10050A EMI Compatibility: FCC Class B VCCI Class B CE Class B C-Tick Host interface: PCI 2.1 Bus (Bus Master)
  • Page 18 2F, No. 119 Pao-Chung Road, Hsin-Tien, Taipei, Taiwan, R.O.C. TEL: 886-2-2910-2626 FAX: 886-2-2910-1515 URL: www.dlinktw.com.tw E-MAIL: dssqa@tsc.dlinktw.com.tw U.K. D-LINK EUROPE D-Link House, 6 Garland Road, Stanmore, London HA7 1DP U.K. TEL: 44-20-8235-5555 FAX: 44-20-8235-5500 BBS: 44-20-8235-5511 URL: www.dlink.co.uk E-MAIL: info@dlink.co.uk U.S.A D-LINK U.S.A.
  • Page 20 3. What network protocol(s) does your organization use ? !XNS/IPX !TCP/IP !DECnet !Others_______________________________________________________ 4. What network operating system(s) does your organization use ? !D-Link LANsmart !Novell NetWare !NetWare Lite !SCO Unix/Xenix !PC NFS !3Com 3+Open !Banyan Vines !DECnet Pathwork !Windows NT !Windows NTAS !Windows '95 !Others__________________________________________________________________________ ______ 5.
  • Page 21 _________________________________________________________________________________ _________________________________________________________________________________ _________________________________________________________________________________ _________________________________________________________________________________...
