D-Link DFE-550TX Quick Install Manual
With snmp agent, for windows xp, 2000, me, 98se
Hide thumbs
Also See for DFE-550TX:
- User manual (34 pages) ,
- Quick instruction manual (4 pages) ,
- Product specification (2 pages)
Advertisement
Quick Links
Package Contents:
!
!
!
If any of the contents are missing, please contact the reseller
This installation guide will instruct you on how to monitor your
workstation from another with the SNMP Agent feature on the
DFE-550 TX.
Install the DFE-550 TX driver
Make sure to configure the IP address, subnet mask, and default gateway.
Install onto the CD drive the SNMP Agent software
For example, type G:\PC_Agent.exe
D-Link DFE-550TX with SNMP Agent
Printed Quick Installation Guide
CD with Manual and Drivers
.
Advertisement
Subscribe to Our Youtube Channel
Related Manuals for D-Link DFE-550TX
Summary of Contents for D-Link DFE-550TX
- Page 1 Package Contents: D-Link DFE-550TX with SNMP Agent Printed Quick Installation Guide CD with Manual and Drivers If any of the contents are missing, please contact the reseller This installation guide will instruct you on how to monitor your workstation from another with the SNMP Agent feature on the DFE-550 TX.
- Page 2 After you click OK, the Install Shield Wizard page will appear:...
- Page 3 Click Next and the following Choose Destination Location page will appear: Click Browse to select another folder to install PC Agent. Otherwise click Next to select the default folder C:\Program Files\D- Link\PC Agent. The Install Shield Wizard will come to completion. Click Finish to restart the computer.
- Page 4 Start#Programs#D-Link PC Agent#D-Link Go to PC Agent...
- Page 5 Windows will prompt you to select a default card: You may also enter Personal Settings (Name, Location, Contact):...
- Page 6 After you enter personal settings and click OK, the D-Link PC Agent becomes an icon in the taskbar. Double-click the D-Link PC Agent icon to bring up the D-Link Ethernet Adapter Agent:...
- Page 7 The Configuration tab allows you to pick which card the agent is for. The Error Log tab lists error messages. You may save them by clicking Save or eliminate them by clicking Clear.
- Page 8 Under Options check “Auto launch when Windows start up” so that the D-Link Ethernet Adapter Agent will automatically appear when Windows starts up. Click Personal to enter settings for name, location, and contact as in Step 3.
- Page 9 Click Password to set the password to desired from default password of “private.”...
- Page 10 Now you can use any MIB browser, for example the D-Link MIB compiler, to view information on the workstation with the DFE-550TX card SNMP Agent feature. The D-Link Network Adapter SNMP Agent supports the following functions of the dlk_pc.mib: Function...
- Page 11 hrDeviceEntry pertaining to the device that this host is configured to load its initial operating system configuration from. This object contains the parameter (e.g. a pathname) supplied to the load device hrSystemInitialLoadParameter when requesting the initial operating system configuration from that device. The number of distinct users hrSystemNumUsers...
- Page 12 is no fixed maximum, the value should be zero. The IP address of the hrSystemAddress interface. The IP net mask for hrSystemNetMask this interface. The default gateway hrSystemDefaultRouter for this IP interface. The MAC address of this IP interface. For interfaces that do not have such an address hrSystemMacAddr...
- Page 13 the host. A description of the type and instance of hrStorageDescr the storage described by this entry. The size of the storage represented hrStorageSize by this entry, in units of Mega bytes. The amount of the storage represented hrStorageUsed by this entry that is allocated, in units of Mega bytes.
- Page 14 agent to the next re- initialization. A textual description of this device, hrDeviceDescr including the device's manufacturer. The current operational state of the device described by this row of the table. A value 1 indicates that the current state of the device is unknown.
- Page 15 The number of errors hrDeviceErrors detected on this device. In addition, the D-Link Network Adapter SNMP Agent supports an RFC 1213-Mib (DLK).mib and a Transmission.mib.
