OWNER'S /
OPERATOR'S
MANUAL
MODEL NO.'s
PLR-48
PLR-60
PLR-72
PBX-42
CAUTION
For Safe Operation
Read Rules And
Instructions Carefully
SINO LEEINGLES, PIDA AYUDA
A AIGUIEN QUE SI LO LEA
PARA QUE LE TRADUZCA LAS
MEDIDAS DE SEGURIDAD.
THE FOLLOWING SAFETY PRECAUTIONS SHOULD BE THOROUGHLY UNDERSTOOD
1. Select an area for assembly that is clean and free of any
debris which might cause persons working on the
assembly to trip.
2. Do not lift heavy parts or assemblies. Use crane, jack,
tackle, fork trucks or other mechanical devices.
3. Preview the assembly instructions in your operator's
manual before proceeding further.
4. If the assembly instructions call for parts or assemblies to
be blocked up, use only blocking material that is in good
condition and is capable of handling the weight of the
assembly to be blocked. Also insure that the blocking
material is on a clean, dry surface.
5. Never put hands, or any part of body, under blocked up
assemblies if at all possible.
4 ft. Landscape Rake Shown
Safety Instructions
Tractor Preparation
Operating Instructions
CAUTION
BEFORE ATTEMPTING TO BEGIN ASSEMBLING THIS MACHINE
ATV or Garden Tractor
LANDSCAPE RAKE
BOX SCRAPER
6. After completing assembly, thoroughly inspect the
machine to be sure that all nuts, bolts, hydraulic fittings
or any other fastened assemblies have been thoroughly
tightened.
7. Before operating the machine, thoroughly read the
operation section of your operator's manual.
8. Before operating, read the maintenance section of your
operator's manual to be sure that any parts requiring
lubrication, such as gearboxes, are full, to avoid any
possible damage.
9. Before operating equipment – If you have any
questions regarding the proper assembly or
operation, contact your dealer or representative.
42" Box Scraper Shown
Assembly & Mounting
Maintenance
Repair Parts
Advertisement
Table of Contents
Related Manuals for Worksaver PLR-48
Summary of Contents for Worksaver PLR-48
-
Page 1: Tractor Preparation
OWNER’S / OPERATOR’S MANUAL MODEL NO.’s 4 ft. Landscape Rake Shown PLR-48 PLR-60 PLR-72 42” Box Scraper Shown PBX-42 ATV or Garden Tractor CAUTION LANDSCAPE RAKE For Safe Operation BOX SCRAPER Read Rules And Instructions Carefully SINO LEEINGLES, PIDA AYUDA Safety Instructions Assembly &... -
