- Page 1 PDP COLOUR TV USER'S MANUAL PDP4220EU Part No: IES050723...
- Page 2 The presence of certain substances can have harmful effects on the environment. The presence of certain substances can have harmful effects on the environment. This apparatus profits from a specific treatment of recycling for the re-use of the matters which make it This apparatus profits from a specific treatment of recycling for the re-use of the matters which make it This apparatus must be thrown only to the places envisaged.
-
Page 3: Osd Language Settings
OSD Language Settings Using the OSD settings menu OSD settings OSD language 1) Press the MENU button to enter the main menu. 2) Press the [VOL+ or VOL-] button to select the item OSD settings. CHANGE PASSWORD 3) Press the [CH+ or CH-] button to select OSD language,and press OSD position the [VOL+]button to enter the OSD language OSD timeout... -
Page 4: Important Safeguard
CAUTION CAUTION: TO REDUCE THE RISK OF ELEC- TRIC SHOCK, DO NOT REMOVE COVER(OR BACK).NO USER- SERVICEABLE PARTS INSIDE. REFER SERVICING TO QUALIFIED SERVICE PERSONNEL. IMPORTANT SAFEGUARD WARNING: TO PREVENT FIRE OR SHOCK HAZARD, DO NOT EXPOSE THIS APPLIANCE TO RAIN OR MOISTURE. FIRE AND SHOCK PRECAUTIONS Adequate ventilation must be provided to prevent heat build up inside unit. -
Page 5: Stand Installation
STAND IN STALLATION WARNING: TO PREVENT FIRE OR SHOCK HAZARD, DO NOT EXPOSE THIS APPLIANCE TO RAIN OR MOISTURE. Stand installation STAND INSTALLATION STAND INSTALLATION If the TV is to be desktop mounted If the TV is to be desktop mounted 1.You will Take out stand from accessory box and put aside level flat roof , and then support groupware 1.You will Take out stand from accessory box and put aside level flat roof , and then support groupware like fig.1 using six screw A (M5X12) stand groupware. -
Page 6: Preparation For Using Your New Tv
Preparation for Using your new TV Selecting a location for the TV 1)Place the TV on the floor or on a sturdy platform in a location where light does not directly hit the screen. 2)Place the TV far enough from the walls to allow proper ventilation. Inadequate ventilation may cause overheating, which may damage the TV. - Page 7 Preparation for Using your new TV CVBS/RGB CVBS/YC Remote Sensing Window Power indicator Menu button Source Volume up / cursor right Volume down / cursor left Channel up / cursor up Channel down / cursor down Power button (standby) Power Switch (ON/OFF) Note: The above figures are for reference only, please refer to the actual units to determine their appearance.
-
Page 8: Connecting Your Tv
Preparation for Using your new TV Connecting your TV Caution: Do not plug the TV in until you have finished connecting all of your equipment. Connecting to A/V equipments To enjoy its multimedia features, you can connect your receiver, Camcorder, Audio amplifier etc., and select signal sources using your remote control. devices as shown below. -
Page 9: Connecting To An Antenna
Preparation for Using your new TV PC/NB To speaker To VGA Connecting to an antenna To enjoy the terrestrial signal transmitted by your local TV station, you need an indoor or outdoor antenna (not supplied). Perfect picture quality requires a good signal and generally means that an outdoor antenna must be used. -
Page 10: Using The Remote Control
Using the remote control Preparing the remote control for use Installing the remote control batteries 1. Open the battery cover on the back of the remote control. 2. Install two AAA size(1.5V) batteries. Match the + and - signs on the batteries to the signs on the battery compartment. -
Page 11: Learning About The Remote Control
Using the remote control Learning about the remote control Channel number: Direct channel selection Recall : Return to previous channel P.Mode:Select picture mode CH+:Channel up VOL-:Volume down CH-:Channel down S.Mode:Select sound mode Still:Snapshooting Zoom:Ajust zoom ration Video:Switch to Video source Source:Switch input source :Switch to YP source... -
Page 12: Using The Tv Features
Using the TV features Understanding the TV features Multimedia - TV receiver, Video monitor and PC display, all in one. Wider viewing angle, 16:9 display - 160¡ã viewing angle at typical value Digital display device - truthfully reproducing the images, without distortion or blurring, irrespective of magnetic or geomagnetic effect. - Page 13 Using the TV features Select channels by [CH+/CH-] You can also use[CH+ / CH-] to select channels. number decrease. Select channels by numbers To select a channel : Press the channel numbers in series to select channel directly. For example, to seclect channel 120, then press the button 2, 12 will display, press the button zero, you can enjoy the program of channel 120.
-
Page 14: Using The Tv Settings Menu
Using the TV features Using the TV settings menu Program 1) Press the [MENU] button to enter the main menu. 2) Press the [VOL+ or VOL-] button to select the item 3) Press the [CH+ or CH-] button to select Program. 4) Press the [VOL+ or VOL-] button to select the present channel. -
Page 15: Using The Picture Menu
Using the TV features Program edit 1) Press the MENU button to enter the main menu. 2) Press the [VOL+ or VOL-] button to select the item TV settings. 3) Press the [CH+ or CH-] button to select 4) Press the [ VOL+] button to start 5)Program edit can carry out program1 and program2 to be interchanged by the button [SWAP],or copy program1 to program2 by the button [COPY]. -
Page 16: Change Password
Using the TV features Using the OSD settings menu OSD position 1) Press the [MENU] button to enter the main menu. 2) Press the [VOL+ or VOL-] button to select the item OSD settings. 3) Press the [CH+ or CH-] button to select OSD position 4) Press the [VOL+ or VOL- ] button to adjust the OSD POSITION OSD timeout... -
Page 17: Using The General Settings Menu
Using the TV features Using the General settings menu Colour system You can set colour syetem. 1) Press the [MENU] button to enter the main menu. 2) Press the [VOL+ or VOL-] button to select the item General settings 3) Press the [CH+ or CH-] button to select colour system and press the [VOL+] button to enter colour system... -
Page 18: Using The Pc Menu
Using the TV features Using the PC menu 1) Press the MENU button to enter the main menu. 2) Press the [VOL+ or VOL-] button to select the item PC Parameters. 3) Press the [CH+ or CH-] button to select the item you want to adjust. -
Page 19: Teletext Operations
Using the TV features Teletext Operations Sub code Some Teletext pages contain sub page that require you to input the sub code. Press [ Zoom ] button until ***|**** is displayed, and enter last four-digit sub code for the sub page you need. You can mix Teletext with TV pictures, which means transparent teletext. -
Page 20: The Scart Interface
Appendix The SCART interface Scart Connector Pinout Details Pin Signal Audio output B (right) Audio input B (right) Audio output A (left) Ground (audio) Ground (blue) Audio input A (left) Blue input Function select (AV control) Ground (green) 11 Green input 13 Ground (red) 14 Ground (blanking) 15 Red input... -
Page 21: Cleaning And Care
Appendix Pin Signal Audio output B (right) Audio input B (right) Audio output A (left) Ground (audio) Ground Audio input A (left) Function select (AV control) Ground 11 - 13 Ground 14 Ground (blanking) 16 - 17 Ground Ground Video output Video input 21 Common ground (shield) WARNING: Do NOT attempt to work on ANY equipment unless you KNOW what you are doing. -
Page 22: Troubleshooting
Appendix Troubleshooting Before calling a service technician, please check the following table for a possible cause of the problem and some solutions. Symptoms TV will not turn on No picture, no sound No sound, picture OK Poor sound, picture OK Poor picture, sound OK Unable to select a certain channel Poor colour or no colour... -
Page 23: Specifications
1 S-video audio 1Y P audio 1 audio output 1 PIP audio output 1 video output SCART1 ( forCVBS, RGB andCANAL+ ) SCART2 ( for CVBS and Y/C) 1 RS232C ( for software updating ) ( LXWXH ) -20- PDP4220EU... - Page 24 Appendix PDP Wall-mounting Bracket Installation Guide READ CAREFULLY BEFORE INSTALLATION! THE INSTALLATION GUIDE SHOULD BE RETAINED FOR FUTURE REFERENCE. Caution: 1. Do NOT attempt to install the TV by yourself to avoid mistakes or hazard. Refer all installation to qualified servicing personnel. 2.
- Page 25 Appendix -22-...
