GENERAL OPERATION

INITIAL SETUP
Important:
The Tuner Region must be selected for
correct operation. Default - USA.
Important: The Marine Region must be selected for
correct operation. Default - USA.
ADJUSTING THE VOLUME
Turn the 'Rotary Encoder' to adjust
the volume.
ZONE VOLUME
Press the 'Rotary Encoder' to step through zones.
All zones Zones 1 Zone 2
SETTINGS
» Press the 'Menu' button and select 'Settings'.
» Select the desired setting to adjust.
Note:
Whilst in Settings the 'Menu' button acts as a
back/return to the previous screen.
TONE
Adjust the treble and bass settings. Press the 'Rotary
Encoder' to cycle between bass and treble selection.
LCD
Press the Rotary Encoder to cycle between Contrast
and Brightness. Turn to adjust.
KEY SOUND
Press the Rotary Encoder to cycle between 'On' and
'Off '.
ZONE SETUP
The MS-RA200 Marine Stereo features Multi-Zone
technology which enables 2 'Zones' with independent
volume/balance control.
Select the Zone you wish to setup.
Select 'Balance' to adjust the audio balance from left
to right within the selected zone.
Select 'Volume Limit' to set the maximum volume limit
within the selected zone.
SUBWOOFER
Select 'Settings' then 'Zones' then 'Subwoofer'.
Select 'Sub Limit' to set the desired maximum
subwoofer output volume.
Select 'Sub Filter' to select the desired cut-off
frequency. 55hz - 85hz - 120hz - 160hz
Default: 85hz
Note: Press and Hold the 'Rotary Encoder' for quick
access to subwoofer level adjustment
LANGUAGE
Select the desired language for the on screen display
English - Deutsch - Nederlands - Espanol - Italiano - Francais
POWER SAVE
Press the Rotary Encoder to cycle between 'On' and
'Off '.
OFF
LCD/Buton backlight on constantly
ON LCD/Button backlight turns off after one minute
of non-activity
TUNER REGION
Select the appropriate Region.
Europe USA Japan Australasia
Important:
The correct Tuner Region must be selected.
Default - USA.
MARINE REGION
Select the appropriate VHF Marine Region.
USA Canada International
Important:
The correct Marine Region must be selected.
Default - USA.
Note: The MS-RA200 can be be completely
disconnected from the constant +12V voltage supply
(Battery switch) with no settings lost.
