Firex CCPB User Manual

Firex CCPB User Manual

Photoelectric/ionization smoke alarm 9v battery powered
Hide thumbs Also See for CCPB:
Table of Contents

Advertisement

Quick Links

Photoelectric/
Ionization
Smoke Alarm
9V Battery
Powered
Thank you for purchasing a Firex
component of your home safety system. Please read this booklet
thoroughly. The more familiar you are with the information it
contains, the easier you will find it to install, operate, and
maintain your smoke alarm properly, which ultimately means
greater security and peace of mind for you and your family.
The ionization type alarms are generally more effective at
detecting fast, flaming fires which consume combustible
materials rapidly and spread quickly. Sources of these fires
may include flammable liquids or paper burning in a waste
container. The photoelectric type alarms are generally more
effective at detecting slow, smoldering fires which smolder for
hours before bursting into flame. Sources of these fires may
include cigarettes burning in couches or bedding.
both types of alarms are designed to provide adequate
detection of both types of fires. If you desire the benefits of
both systems, you should install smoke alarms that combine
in one alarm both photoelectric and ionization sensing
technologies.
Page 1
Smoke Alarm Features
Page 2
Agency Alarm Placement Recommendations
Page 3
Additional Smoke Alarm Placement Information
Page 4
How to Install Your Smoke Alarm
Page 4
Testing Your Smoke Alarm
Page 5
LED Power/Alarm Indicator
Page 5
Special Features of Model CCPB
Page 5
Maintenance and Cleaning
Page 6
Troubleshooting
Page 6
Important Safety Information
Page 7
Home Fire Safety Tips and Procedures
Page 8
Limited Warranty
Smoke Alarm Features
• Model CCPB is a dual sensor photoelectric / ionization-type
smoke alarm.
• Unique "battery missing" feature. The smoke alarm will not attach
to the mounting bracket if a battery is not in the battery pocket.
• Low battery signal. The smoke alarm will sound a short beep about
once a minute if the battery needs replacement.
• Optional tamper-resist feature can serve as a safeguard against
tampering.
• Visual LED flashes about once a minute. This indicates the smoke
alarm is receiving power.
• Loud alarm horn — 85 decibels at 10 feet — sounds to alert you
of an emergency.
• Test button checks smoke alarm operation. Model CCPB
features Quick-Quiet™ Alarm Control. When activated, this quiets
unwanted alarms for a maximum of 15 minutes.
smoke alarm. It is an important
®
Invensys Controls
1
Model CCPB
PLEASE READ AND
SAVE THIS MANUAL
Installer: Please leave
this manual with the
product.
352-00066-001 Rev A
However,

Advertisement

Table of Contents
loading

Related Manuals for Firex CCPB

Summary of Contents for Firex CCPB

  • Page 1 Page 8 Limited Warranty Smoke Alarm Features • Model CCPB is a dual sensor photoelectric / ionization-type smoke alarm. • Unique “battery missing” feature. The smoke alarm will not attach to the mounting bracket if a battery is not in the battery pocket.
  • Page 2 Agency Alarm Placement Recommendations Invensys Controls Americas recommends complete coverage protection achieved by installing a smoke alarm in every room of your home. For your information, the National Fire Protection Association’s Standard 72, reads as follows: 11.5.1* Required Detection. 11.5.1.1* Where required by applicable laws, codes, or standards for a specific type of occupancy, approved single- and multiple-station smoke alarms shall be installed as follows: (1) *In all sleeping rooms and guest rooms...

  • Page 3: Additional Smoke Alarm Placement Information

    WARNING Model CCPB smoke alarms DO NOT meet NFPA minimum requirements for new construction. Use this alarm only in recommended smoke alarm locations. Mobile Home Installation •...

  • Page 4: How To Install Your Smoke Alarm

    How to Install Your Smoke Alarm WARNING This smoke alarm is shipped with the battery disconnected. You MUST properly connect the battery before mounting the smoke alarm to the wall or ceiling. The smoke alarm will not operate without the battery first being properly connected. Read SMOKE ALARM PLACEMENT information on page 3.

  • Page 5: Led Power/Alarm Indicator

    Quick-Quiet Alarm Control is actively quieting an ™ unwanted alarm Special Features of Model CCPB Quick-Quiet™ Alarm Control When activated, Quick-Quiet™ Alarm Control quiets unwanted alarms for a maximum of 15 minutes. Always check that the smoke alarm has activated in a false alarm situation. Be sure a real fire emergency does not exist.

  • Page 6: Troubleshooting

    3505 Laird Road Unit #14 Mississauga, Ontario L5L 5Y7 CANADA If the smoke alarm is no longer under warranty, replace the smoke alarm immediately with a comparable Firex ® brand smoke alarm. Troubleshooting DO NOT disconnect battery to quiet an unwanted alarm. This will remove your protection.

  • Page 7: Home Fire Safety Tips And Procedures

    This smoke alarm meets all NFPA requirements for existing homes and can be used as additional protection in locations not required but recommended for new construction. Per the National Fire Protection Association (NFPA) Standard 72, Chapter 2, this type of smoke alarm can be used to meet the minimum requirements for existing residential dwellings.

  • Page 8: Limited Warranty

    Limited Warranty Invensys Controls warrants only to the original purchaser of this smoke alarm that, other than the battery, the smoke alarm is free from defects in material and workmanship under normal residential use and service for a period of five (5) years from the date of purchase. Invensys Controls warrants only to the original purchaser of the Items #470L and 470LC smoke alarms that the battery sold with this smoke alarm is free from defects in material and workmanship under normal...
