Hanna Instruments HI9224 Instruction Manual

Hanna Instruments HI9224 Instruction Manual

Portable microprocessor printing and logging ph meters
Hide thumbs
Table of Contents

Advertisement

Quick Links

Instruction Manual

HI9224 - HI92240
Portable
Microprocessor
Printing and Logging
pH Meters
This Instrument is in
h t t p : / / w w w . h a n n a i n s t . c o m
Compliance with the CE Directives

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the HI9224 and is the answer not in the manual?

Questions and answers

Related Manuals for Hanna Instruments HI9224

Summary of Contents for Hanna Instruments HI9224

  • Page 1: Instruction Manual

    Instruction Manual HI9224 - HI92240 Portable Microprocessor Printing and Logging pH Meters This Instrument is in h t t p : / / w w w . h a n n a i n s t . c o m...

  • Page 2: Table Of Contents

    Dear Customer, Thank you for choosing a Hanna Instruments Product. Please read this instruction manual carefully before using the instrument. This manual will provide you with all the necessary information for the correct use of the instrument, as well as a precise idea of its versatility in a wide range of applications.

  • Page 3: Preliminary Examination

    GENERAL DESCRIPTION HI9224 and HI92240 respectively, are the first printing and printing/ logging microprocessor-based portable pH/°C meters in the world. All pH measurements are automatically compensated for temperature (ATC). The instruments' housing is made of rugged, lightweight mate- rial, making it truly portable.

  • Page 4: Functional Description Hi9224

    FUNCTIONAL DESCRIPTION HI9224 instrum nts HI 9224 MICROPROCESSOR PRINTING pH METER ON/OFF PAPER BUFF RANGE PRINT 1) Electrode Connector 2) Temperature Probe Connector 3) LCD Display 4) PAPER key to move the paper up 5) ON/OFF key, to turn the meter on or off 6) CAL key to enter or exit calibration mode 7) RANGE key, to select the pH or the °C measurement modes...

  • Page 5: Functional Description Hi92240

    FUNCTIONAL DESCRIPTION HI92240 instrum nts HI 92240 MICROPROCESSOR LOGGING pH METER PRINT PAPER RANGE TIME 1) Electrode Connector 2) Temperature Probe Connector 3) LCD Display 4) PAPER key to move the paper up 5) PRINT key to obtain a printout 6) ALT key Alternate Function Key 7) RANGE key to display the temperature or the pH 8) Power Adapter Plug for 12VDC battery charger...

  • Page 6: Specifications

    Printer Low power impact type-belt, 14 characters per line; 38 mm plain paper (HI 710034) Printing Interval 5 minutes (HI9224 only) Printing/Logging 1, 2, 5,10, 15, 30, 60, 120 and 180 minutes Interval (HI92240 only) Power supply 4x1.5V AA alkaline type/250 hours without printing.

  • Page 7: Lcd Functional Description

    °C capability. If the temperature probe is left disconnected, a default temperature of 25°C is assumed and the "C" symbol blinks. To switch the HI9224 on, press the ON/OFF key. ON/OFF To switch the HI92240 on, press the RANGE key.

  • Page 8: Operational Guide

    OPERATIONAL GUIDE SET DATE / TIME / PRINTING INTERVAL (FOR HI92240 ONLY): Press the ALT and the TIME keys simultaneously. The display will show the date setting. At the bottom of the display the year will be flashing. DATE RANGE TIME Use the UP or the DOWN arrow key to select the year.
  • Page 9 Use the UP or the DOWN arrow key to select the correct day. Press the ALT and the TIME keys simultaneously. RANGE TIME The display will now show the clock time with the printing interval flashing. TIME INTV Any interval can be selected from 1, 2, 5, 10, 15, 30, 60, 120 or 180 minutes by using the UP and the DOWN arrow keys.
  • Page 10 The right hand side of the display showing the minutes will flash. TIME INTV Use the UP or the DOWN key to select the minute. Press the ALT and the TIME keys simultaneously to leave this mode. RANGE TIME Your clock, date and printing interval are now set and stored in memory even when the display is switched off.
  • Page 11 Note: the pH value will be displayed without any symbol. The temperature value will be displayed together with the °C symbol. TO VIEW PH / TEMPERATURE (WITH HI9224 ONLY) When the instrument is turned on the display will be in pH measurement mode. To view temperature simply press the RANGE key.

  • Page 12: Taking Ph Measurements

    TAKING PH MEASUREMENTS To take pH measurements, simply submerge the bottom 4 cm (1½") of the electrode and the temperature probe in the reading solution to be tested, stir gently and allow for the electrode to 4 cm (1½") adjust and stabilize. For greatest accuracy, it is recommended to calibrate the meter regularly (see page 13).

  • Page 13: Ph Calibration Procedure

    pH CALIBRATION PROCEDURE For greatest accuracy, it is recommended that the instrument is calibrated frequently. For a faster procedure, it is possible to calibrate at 1 point (pH 7.01), but it is always a good practice to calibrate at 2 points. Due to electrode conditioning time the electrode must be kept immersed a few seconds to stabilize.
  • Page 14 5. “4” can be changed to “10” (indicating pH 10.01) by pressing BUFF button. If you are measuring acid samples (pH 7 or less) use BUFF the pH 4.01 buffer (HI7004). For alkaline solutions (pH 7 or greater) use pH 10.01 (HI7010).
  • Page 15 3. When the “7” stops blinking, the calibration can be confirmed. Wait 30 seconds and press the CON key to confirm the first buffer. If wrong solution or electrode has been used or if the buffer is out of specifications the “7” symbol will not stop blinking to alert the user.
  • Page 16 CALIBRATION PRINTOUT (FOR HI92240 ONLY) During calibration, the characteristics of the electrode will be printed to record the electrode's performance over time. After the first point calibration a first set of data will be printed. This will consist of: 10-01-96 *02.13 date, time, the temperature compensated pH 7.04...

  • Page 17: Printing / Recording With Hi 9224

    PRINTING / RECORDING WITH HI 9224 To print the measured values press the PRINT key. The printout provides the following informa- tion: PRINT a - Running sample numbers 0001 *07.25 b - Total accumulative time 4.25 25.0 c - pH value d - Temperature in Degrees Centigrade.
  • Page 18 Note: If the PRINT key is pressed while still in recording mode, a printout is produced without affecting the running number. PRINT TO STOP RECORDING In order to quit the recording mode, press the ON/OFF key. The running log number can be reset by simply removing the batteries.

  • Page 19: Printing / Logging With Hi 92240

    PRINTING / LOGGING WITH HI 92240 To print the measured values shown on display, press the PRINT key. This function can be acti- vated in normal operational mode as well as PRINT during logging and scanning data on display (see below).
  • Page 20 To log without printing press the ALT and the PAPER keys at the same time and the "LOG" symbol on display will start to blink. Press ALT and PAPER again to resume logging with printing. PRINT PAPER After approximately 5 minutes the display will switch off but the logging function remains active.
  • Page 21 print a complete set of data and the "LOG" symbol will appear on the bottom left hand side of the display. If no key is pressed, the display goes blank after about 5 minutes. During printing, the display shows the time, interval and the “LOG”...
  • Page 22 data at different time (see above). • It is possible to insert a new paper roll during logging session (see page 27) • Once in the logging mode, the interval cannot be changed. Exit the logging mode first (pressing the ALT and the LOG keys) before setting the new interval.
  • Page 23 Press the CAL key and the time will be displayed. TIME Press the CAL key and the temperature will be displayed. °C Press the CAL key and the pH value will be displayed. Continue pressing the CAL key to display one by one all the memorized data of the same log in the above sequence i.e.
  • Page 24 TO PRINT STORED DATA Having selected a log number by using ALT and CON keys, as detailed in the chapter "TO SCAN STORED DATA ON DISPLAY" you can print all or part of that log section by using the ALT and PRINT keys. The printer will then start to print the logged section PRINT beginning with the selected sample number...

  • Page 25: Data Transfer To Pc

    Data transmission from the instrument to the PC is now much easier with new HI92000 Windows ® compatible application software offered by Hanna Instruments. HI92000 allows you to use the powerful means of the most spread sheet programs (e.g.Excel ©...

  • Page 26: Fault Functions

    FAULT FUNCTIONS HI 9224 and HI 92240 are factory programmed to automatically diagnose a fault. This is displayed with error codes on the LCD. Error codes: PEr0, PEr1, PEr2 = Short circuit on the system, the meter should be returned for repair (see Warranty section). PEr3 = Printer mechanism fault - repair needed (see Warranty section).

  • Page 27: Printer Maintenance

    When printouts become faint, it might be necessary to change the ink cartridge. Contact your Hanna authorized center. TO INSERT THE PAPER ROLL The HI9224 and HI92240 use plain paper rolls 38 mm width. To insert a new roll is very easy. Open the paper cover pulling it gently.
  • Page 28 Allow about 5 cm (2") to exit from the printer and replace the paper cover. TO RESET PRINTER Take the battery cover off by re- moving the screws. Using a pencil press the black button. This will 1.5V reset the printing mechanism. 1.5V SCREW POTS...

  • Page 29: Electrode Conditioning And Maintenance

    ELECTRODE CONDITIONING AND MAINTENANCE Reference Filling Hole Reference Filling Hole Sensitive Reference Wire Wire Sensitive Reference Wire Wire Reference Reference Junction Junction Glass Glass Bulb Bulb Plastic Body Glass Body pH Electrode pH Electrode PREPARATION Remove the protective cap. DO NOT BE ALARMED IF ANY SALT DEPOSITS ARE PRESENT. This is normal with electrodes and they will disappear when rinsed with water.
  • Page 30 For AmpHel electrodes: If the electrode does not respond to pH changes, the battery is run down and the electrode should be replaced. MEASUREMENT Rinse the electrode tip with distilled water. Immerse the tip (4 cm /1½") in the sample and stir gently for approx.
  • Page 31 Solution for 15 minutes. - Inorganic Soak in Hanna HI7074 or HI8074 Inorganic Cleaning Solution for 15 minutes. - Oil/grease Rinse with Hanna HI7077 or HI8077 Oil and Fat Cleaning Solution. IMPORTANT: After performing any of the cleaning procedures rinse the electrode thoroughly with distilled water, drain and refill the reference chamber with fresh electrolyte, (not necessary for GEL filled electrodes) and soak the electrode in HI70300 or HI80300 Storage...

  • Page 32: Battery Replacement

    BATTERY REPLACEMENT When the batteries are run down "LOBAT" is displayed on the Liquid Crystal Display to warn the user. LO BAT Battery replacement must only take place in a non hazardous area using 1.5V alkaline AA type batteries . In order to replace run down batter- 1.5V ies, simply remove the two screws on...

  • Page 33: Temperature-Resistance Correlation For Hanna Ph Sensitive Glass

    TEMPERATURE-RESISTANCE CORRELATION FOR HANNA PH SENSITIVE GLASS The resistance of glass electrodes partially depends on the tempera- ture. The lower the temperature, the higher the resistance. It takes longer time for the reading to stabilize if the resistance is higher. In addition, the response time will suffer to a greater degree at temperatures below 10°C.
  • Page 34 High concentrations of sodium ions interfere with readings in alkaline solutions; the pH at which the interference starts to be significant depends upon the composition of the glass. This interference is the alkaline error and causes the pH to be underestimated. Hanna's glass formulations have the indicated characteristics.

  • Page 35: Accessories

    ACCESSORIES pH CALIBRATION SOLUTIONS HI 70004P pH 4.01 Buffer Sachets, 20mL, 25 pcs HI 70007P pH 7.01 Buffer Sachets, 20mL, 25 pcs HI 70010P pH 10.01 Buffer Sachets, 20mL, 25 pcs HI 7004L pH 4.01 Buffer Solution, 460 mL HI 7006L pH 6.86 Buffer Solution, 460 mL HI 7007L pH 7.01 Buffer Solution, 460 mL...
  • Page 36 HI 7082 3.5M KCl Electrolyte, 4x50 mL, for double junction electrodes REFILL ELECTROLYTE SOLUTIONS IN FDA APPROVED BOTTLES HI 8071 3.5M KCl + AgCl Electrolyte, 4x50mL, for single junction electrodes HI 8072 1M KNO Electrolyte, 4x50 mL HI 8082 3.5M KCl Electrolyte, 4x50 mL, for double junction electrodes pH ELECTRODES All electrodes part numbers ending in B are supplied with a BNC...
  • Page 37 HI 1131B Glass-body, single junction, refillable, combination pH electrode. Use: general purpose. 9.5mm DIA 12 mm 0.37" 0.5" HI 1131 120 mm 4.7" "S" VERSION HI 1330B Glass-body, semimicro, single junction, refillable, combination pH electrode. Use: laboratory, vials. 5mm DIA 0.2"...
  • Page 38 HI 1332B Plastic-body (Ultem ® ), double junction, refillable, combination pH electrode. Use: general purpose. 12 mm 0.5" HI 1332 120 mm "S" VERSION 4.7" FC 100B Plastic-body (Kynar ® ), double junction, refillable, combination pH electrode. Use: general purpose for food industry. 12 mm 0.5"...
  • Page 39 FC 911B Plastic-body (Kynar ® ), double junction, refillable with built-in ampli- fier, combination pH electrode. Use: very high humidity. 12 mm 0.5" FC 911 110 mm 4.3" HI 1413B Glass-body, single junction, flat tip, Viscolene, non-refillable, combina- tion pH electrode. Use: surface measurement. 12 mm 0.5"...
  • Page 40 POWER UNITS: HI710005 Voltage adapter from 115 VAC to 12 VDC HI710006 Voltage adapter from 230 VAC to 12 VDC OTHER ACCESSORIES HI 710031 Rugged carrying case HI 710034 Plain Paper Spare Rolls (10 pcs) HI 710035 Spare Ink Cartridge (1 pc) HI 721308 1.5V AA batteries (10 pcs) HI 76405 Electrode holder...

  • Page 41: Electrode Application Reference Guide

    ELECTRODE APPLICATION REFERENCE GUIDE Application Electrodes 1. Aquarium HI 1332B, HI 1911B, HI 1312S 2. Bath-water HI 1910B, HI 1130B, HI 1110S 3. Beer HI 1131B, HI 1111S 4. Bread HI 2031B, FC 200B, HI 2020S, FC 200S 5. Cheese FC 200B, FC 200S 6.

  • Page 42: Warranty

    If the repair is not covered by the warranty, you will be notified of the charges incurred. If the instrument is to be returned to Hanna Instruments, first obtain a Returned Goods Authorization number from the Cus- tomer Service department and then send it with shipping costs prepaid.

  • Page 43: Ce Declaration Of Conformity

    CE DECLARATION OF CONFORMITY DECLARATION OF CONFORMITY Hanna Instruments Srl V.le delle industrie 12 35010 Ronchi di Villafranca (PD) ITALY herewith certify that the pH meters HI 9224 HI 92240 have been tested and found to be in compliance with the following regulations:...
  • Page 44 h t t p : / / w w w . h a n n a i n s t . c o m...
