AudioEngine 5 Setup Manual page 6

Connecting Your System (continued)
Con guration C
(for use with iPod):
C1 For charging your iPod while playing, connect the 30-pin cable from the
iPod to USB jack on the Combo Port. Use the included USB extender
cable, if extra cable length is needed on a desktop, for example.
C2
Connect the long 1/8" mini-jack audio cable from iPod headphone jack
to the AUDIO IN jack on the Combo Port
MENU
MP3
Player
8 audioengine 5 setup guide
A5 Top View
2
AUDIO INPUT
CHARGE
1
Con guration D (all products with 1/8" or RCA outputs):
D1 Connect the 1/8" mini-jack audio cable from 1/8" output to the AUDIO
IN jack on the Combo Port (or rear panel) – or use the included RCA to
1/8" Y adapter for components with RCA L/R audio outputs.
A5 Top View
audioengine 5 setup guide
DVD
TV
Video Game
1
1
9
