Summary of Contents for Mitsubishi MDT401S
-
Page 2: Table Of Contents
Index Important Information .......................... English-1 Safety Precautions, Maintenance, & Recommended Use ..............English-2 Contents ..............................English-3 Attaching LCD Options ..........................English-4 Parts Name and Functions Control Panel ..........................English-5 Terminal Panel .......................... English-6 Wireless Remote Control ......................English-7 Operating Range for the Remote Control ................English-8 Handling the Remote Control .................... -
Page 3: Important Information
CAN/CSA 60950. FCC Information 1. Use the attached specified cables with the MDT401S (L40HV201) color monitor so as not to interfere with radio and television reception. (1) Please use the supplied power cord or equivalent to ensure FCC compliance. (2) Please use the supplied shielded video signal cable, 15-pin mini D-SUB to 15-pin mini D-SUB. -
Page 4: Safety Precautions, Maintenance & Recommended Use
Safety Precautions, Maintenance & Recommended Use Safety Precautions and Maintenance FOR OPTIMUM PERFORMANCE, PLEASE NOTE THE FOLLOWING WHEN SETTING UP AND USING THE MDT401S LCD COLOR MONI- CAUTION TOR: Immediately unplug your monitor from the wall outlet and refer •... -
Page 5: Contents
*Install an attached stand at the time of unpacking when it uses with the stand. *Remember to save your original box and packing material to transport or ship the monitor. The following components are available to use with the MDT401S. • Macintosh Cable Adapter •... -
Page 6: Attaching Lcd Options
This device cannot be used or installed without the Tabletop Stand or other mounting accessory. For proper installation it is strongly recommended to use a trained, MITSUBISHI authorized service per- son. Failure to follow MITSUBISHI standard mounting procedures Before moving the LCD monitor, the cord or chain should be removed. -
Page 7: Parts Name And Functions
Parts Name and Functions Control Panel Button Location EXIT INPUT MUTE POWER button ( DOWN ( ) button Switches the power on/off. See also page 17. Activates the OSM menu when the OSM menu is turned-off. Acts as button to move the highlighted area down to select the MUTE button adjustment with OSM menu. -
Page 8: Terminal Panel
Parts Name and Functions –continued Terminal Panel AC IN connector AUDIO IN 1,2,3 Connects with the supplied power cord. To input audio signal from external equipment such as a computer, VCR or DVD player. RGB 1 IN (DVI-D) AUDIO OUT To input digital RGB signals from a computer having a digital RGB output. -
Page 9: Wireless Remote Control
Parts Name and Functions –continued Wireless Remote Control VOLUME UP button Increase the audio output level. VOLUME DOWN button Decrease the audio output level. PIP (Picture In Picture) button ON/OFF button: Toggle switches between PIP-ON/ POP-ON/OFF. INPUT button: Select the ‘picture in picture’ input signal. CHANGE button: Replaces to the main picture and sub picture. -
Page 10: Operating Range For The Remote Control
Parts Name and Functions –continued Operating Range for the Remote Control Caution Point the top of the remote control toward the LCD monitor's remote The remote control system may not function when direct sunlight or sensor during button operation. strong illumination strikes the remote control sensor of the LCD moni- Use the remote control within a distance of about 7 m/23 ft. -
Page 11: Setup Procedure
Remove 2 screws by screwdriver and place them in a safe place for reuse. CAUTION How to install stand Incorrect usage of batteries can result in leaks or bursting. MITSUBISHI Please turn monitor off. recommends the following battery use: Insert claws of monitor to stand holes until clicks. -
Page 12: Connections
Connections Before making connections: First turn off the power of all the attached equipment and make connections. Refer to the user manual included with each separate piece of equipment. Wiring Diagram Wiring Diagram Mounting Position of Ferrite Core Attaching the Ferrite Core Attach the Ferrite Core to PC Audio Cable and S-VIDEO Cable. -
Page 13: Connecting The Lcd Monitor To A Pc
Connections –continued Connecting the LCD Monitor to a PC Connecting your computer to your LCD monitor will enable you to display your computer's screen image. Some video cards may not display an image correctly. • To connect the RGB 2 IN connector (mini D-sub 15 pin) on the LCD monitor, use the provided RGB signal cable (mini D-sub 15 pin to mini D-sub 15 pin). -
Page 14: Connecting To A Macintosh Computer
Connections –continued Connecting to a Macintosh Computer Connecting your Macintosh computer to your LCD monitor will enable you to display your computer's screen image. Some video cards or drivers may not display images correctly. • To connect the RGB 2 IN connector (mini D-sub 15 pin) on the LCD monitor, use the provided RGB signal cable (mini D-sub 15 pin to mini D-sub 15 pin). -
Page 15: Connecting To A Computer With A Digital Output
Connections –continued Connecting to a Computer with a Digital Output Connections can be made with equipment that is equipped with a digital interface compliant with the DVI (Digital Visual Interface) standard. • The RGB 1 IN connector also accepts a DVI-D cable. •... -
Page 16: Connecting To A Vcr Or Laser Disc Player
Connections –continued Connecting to a VCR or Laser Disc Player Connecting your VCR or laser disc player to your LCD monitor will enable you to display your VCR or laser disc player video. Refer to your VCR or laser disc player owner's manual for more information. •... -
Page 17: Connecting To A Dvd Player
Connections –continued Connecting to a DVD Player Connecting your DVD player to your LCD monitor will enable you to display your DVD video. Refer to your DVD player owner’s manual for more information. • To connect the RGB 3 DVD/HD In connector (BNC) on the LCD monitor, use a separately available BNC connector cable. You will need a BNC-to-RCA adapter to connect a DVD player with an RCA pin jack to the BNC connector cable (not provided). -
Page 18: Connecting To A Stereo Amplifier
Connections –continued Connecting to a Stereo Amplifier You can connect your stereo amplifier to your LCD monitor. Refer to your amplifier owner's manual for more information. • Turn on the LCD monitor and the amplifier only after all hookups have been made. •... -
Page 19: Basic Operation
Basic Operation –Power ON and OFF Modes The LCD monitor power indicator will turn green while powered on or red in off mode. The monitor can be powered on or off using the following three options: 1. Pressing the power button. NOTE: Before pressing the power button, be sure to turn on the Main Power Switch on the LCD monitor. -
Page 20: Power Indicator
Basic Operation –continued OSM Information Power Indicator Power Indicator RGB1, 2, 3 Status Video Input mode RGB2 Power ON Green 1024 x 768 Input signal Information 48kHz 60Hz Power OFF Audio input mode AUDIO : 1 Power Standby Red and Green SCREEN SIZE : FULL Picture Size mode When Using Power Management Function... -
Page 21: Osm (On-Screen-Menu) Controls
OSM (On-Screen Menu) Controls –Computer Press MENU button to open Press MENU or EXIT Press SET Press UP or DOWN, and button to exit Main-menu PLUS or MINUS button to Press UP or DOWN button select function, or control to select sub-menu which you like Press SET button to decide Remote Control... -
Page 22: Osm Controls
OSM Controls –Computer continued To adjust the color temperature of entire screen. COLOR TEMPERATURE BRIGHTNESS Adjusting lower color temperature make the CONTRAST SHARPNESS screen reddish and adjusting higher color COLOR TEMPERATURE BLACK LEVEL COLOR CONTROL temperature make the screen bluish. COLOR TEMPERATURE PICTURE RESET :SEL... -
Page 23: Audio Reset
OSM Controls –Computer continued Main-Menu PICTURE SCREEN AUDIO AUDIO PICTURE IN PICTURE CONFIGURATION 1 CONFIGURATION 2 :SEL EXIT:PRE SET:NEXT MENU:END Sub-Menu To accentuate or control the high frequency TREBLE TREBLE sound. BASS AUDIO RESET TREBLE Press + button to increase TREBLE sound. Press - button to decrease TREBLE sound. -
Page 24: Auto Brightness
OSM Controls –Computer continued AUTO SETUP Selecting the Auto Brightness ON/OFF. AUTO ADJUST AUTO BRIGHTNESS When Select 'ON' , the Brightness will adjust AUTO BRIGHTNESS POWER SAVE automatically. AUTO BRIGHTNESS LANGUAGE OSM TIME OFF TIMER SCREEN SAVER FACTORY PRESET *:INPUT RGB2/3 only :SEL EXIT:PRE MENU:END... -
Page 25: Dvd & Hd
OSM Controls –DVD & HD Main-Menu PICTURE AUDIO PICTURE IN PICTURE CONFIGURATION PICTURE :SEL EXIT:PRE SET:NEXT MENU:END Sub-Menu Adjusts the overall image and background screen BRIGHTNESS BRIGHTNESS brightness. CONTRAST SHARPNESS BRIGHTNESS COLOR BLACK LEVEL PICTURE RESET Press + button to increase brightness. Press - button to decrease brightness. -
Page 26: Picture In Picture
OSM Controls –DVD & HD continued Main-Menu PICTURE IN PICTURE PICTURE AUDIO PICTURE IN PICTURE CONFIGURATION :SEL EXIT:PRE SET:NEXT MENU:END Sub-Menu Selecting the size of picture inserted at the PIP SIZE 'Picture-in-Picture' (PIP) mode. PIP SIZE 'Large', 'Middle', and 'Small' are available. PIP SIZE LARGE PIP AUDIO... -
Page 27: Av Input
OSM Controls –AV Input Main-Menu PICTURE AUDIO PICTURE IN PICTURE PICTURE CONFIGURATION :SEL EXIT:PRE SET:NEXT MENU:END Sub-Menu Adjusts the overall image and background screen BRIGHTNESS BRIGHTNESS brightness. CONTRAST SHARPNESS BRIGHTNESS TINT COLOR BLACK LEVEL Press + button to increase brightness. NOISE REDUCTION PICTURE RESET Press - button to decrease brightness. - Page 28 OSM Controls –AV Input continued To accentuate or control the low frequency sound. BASS TREBLE BASS AUDIO RESET Press + button to increase BASS sound. BASS Press - button to decrease BASS sound. :SEL EXIT:PRE SET:NEXT MENU:END :SEL EXIT:PRE MENU:END Selecting Audio Reset allows you to reset all AUDIO RESET TREBLE...
- Page 29 OSM Controls –AV Input continued English-27...
-
Page 30: Using The Lcd With A Personal Computer (Pc)
Using the LCD with a Personal Computer (PC) This LCD monitor can be controlled by connecting a personal computer with a RS-232C terminal. Functions that can be controlled by a personal computer are: • Power ON or OFF • Switching between input signals Connection LCD Monitor + PC to RS-232C terminal... - Page 31 Using the LCD with a Personal Computer –continued 3) Control sequence (1) The command from a personal computer to the LCD monitor will be sent in 400ms. (2) The LCD monitor will send a return command 400ms* after it has received an encode. If the command isn't received correctly, the LCD monitor will not send the return command.
-
Page 32: Features
On Screen Menu (OSM) puts you in complete control of display setting adjustments. MITSUBISHI’s quality and reliability provide peace of mind with a 1-year warranty (including backlight). No Touch Auto Adjust: No Touch Auto Adjust automatically adjusts the monitor to optimal settings upon initial setup. -
Page 33: Troubleshooting
NOTE: As with all personal display devices, NEC-Mitsubishi Electronics Display recommends using a moving screen saver at regular intervals whenever the screen is idle or turning off the monitor when not in use. -
Page 34: Specifications
Specifications English-32... - Page 35 Declaration of the Manufacturer We hereby certify that the color monitor MDT401S(L40HV201) is in compliance with Council Directive 73/23/EEC: – EN 60950 Council Directive 89/336/EEC: — EN 55022 — EN 61000-3-2 — EN 61000-3-3 — EN 55024 and marked with...
-
Page 37: Declaration Of Conformity
PROPRIETARY NOTICE AND LIABILITY DISCLAIMER The information disclosed in this document, including all designs and related materials, is the valuable property of NEC-Mitsubishi Electric Visual Systems Corporation and/or its licensors, as appropriate, reserve all patent, copyright and other proprietary rights to this document, including all design, manufacturing, reproduction, use and sales rights thereto, except to the extent said rights are expressly granted to others. - Page 38 PROPRIETARY NOTICE AND LIABILITY DISCLAIMER The information disclosed in this document, including all designs and related materials, is the valuable property of NEC-Mitsubishi Electric Visual Systems Corporation and/or its licensors, as appropriate, reserve all patent, copyright and other proprietary rights to this document, including all design, manufacturing, reproduction, use and sales rights thereto, except to the extent said rights are expressly granted to others.
