2.

Scanner Overview

Name
1 Power Button
2 Custom Button
3 Guide Lever
4 Indicator light
5 Feeding Slot
6 Power connector
7 Mini USB connector
8 Flash disk slot
9 Memory card slot
Function/ Description
Press to power on or off.
Press the button to start cleaning the roller.
Slide the guide lever to adjust for various sized
originals to ensure the proper alignment.
Indicates the operating status of the scanner.
Insert an original to begin scanning.
For connecting to the supplied power adapter.
For connecting to a computer via a USB cable.
For inserting a USB Stick.
For inserting a memory card.
4
