BASIC SHREDDING OPERATION

Continuous operation:
Up to 5-minute maximum
NOTE: Shredder runs briefly after each pass to
clear entry. Continuous operation beyond 5-minutes
will trigger 20-minute cool down period.

ADVANCED PRODUCT FEATURES

SAFESENSE
TECHNOLOGY
®
Stops shredding immediately when hands touch the paper opening.

SET-UP AND TESTING

1
Press Auto-On ( )
For more information about all of Fellowes Advanced Product Features go to www.fellowes.com

PRODUCT MAINTENANCE

OILING SHREDDER

All cross-cut shredders require oil for peak performance. If not oiled, a
machine may experience diminished sheet capacity, intrusive noise when
shredding, and could ultimately stop running. To avoid these problems, we
recommend you oil your shredder each time you empty your waste bin.
FOLLOW OILING PROCEDURE BELOW AND REPEAT TWICE
1
2
Set to Off
* Apply oil
across entry
* Only use a non-aerosol vegetable oil in long
nozzle container such as Fellowes 35250

TROUBLESHOOTING

PAPER JAM

2
1
Press and hold
Alternate slowly back and forth
Reverse (R)
2-3 seconds
ATTENTION: If the SafeSense
®
light remains on, you must engage the
Once the jam is cleared, reset the SafeSense
SafeSense
paper jam: If the SafeSense
®
to think the shredder has jammed when it has not, use the
feature and clear the paper. Warning – when switch is in override position, the SafeSense
the SafeSense
®
feature will NOT function. Once the paper is cleared, reset the SafeSense
PAPER/CARD
1
2
Plug in and put
Press Auto-On ( )
disconnect power switch
in ON (I) position
2
3
10
Touch test area
Sensor lights up

CLEANING AUTO-START INFRARED SENSORS

Paper detection sensors are designed for maintenance free operation. However, on rare occasions, the
sensors may become blocked by paper dust causing the motor to run even if there is no paper present.
(Note: two paper detection sensors are located in the center of the paper entry)
TO CLEAN THE SENSORS
3
Turn off and unplug
Press and hold Reverse
shredder
(R) 2-3 seconds
4
3
Set to Off (O)
and unplug
Override Switch in order to perform steps above.
feature. (See SafeSense
instructions below.)
®
®
feature activates (SafeSense
®
Override Switch to deactivate the SafeSense
3
Feed paper/card
straight into paper
entry and release
2
1
Locate Auto-start
infrared sensor
6
5
Press Auto-On ( )
Gently pull uncut
paper from paper
and resume shredding
entry. Plug in
light remains on) to cause the user
®
®
light will flash and
®
feature.
4
When finished
shredding, set to Off
.
4
3
Dip cotton swab in
Using cotton swab, wipe
rubbing alcohol
away any contamination
from the paper sensors
Shredder doesn't start:
Yellow - SafeSense
active
®
Yellow flashing - SafeSense
Make sure head is on basket correctly
Wait 20 minutes for motor to cool down
Remove and empty basket
®
®
not active
