Contact SAMSUNG WORLDWIDE
If you have any questions or comments relating to Samsung products, please contact the SAMSUNG customer care center.
Comuníquese con SAMSUNG WORLDWIDE
Si desea formular alguna pregunta o comentario en relación con los productos de Samsung, comuníquese con el centro de
atención al cliente de SAMSUNG.
Country
Customer Care Center
Web Site
CANADA
1-800-SAMSUNG(726-7864)
www.samsung.com
U.S.A
1-800-SAMSUNG(726-7864)
www.samsung.com
Address
Samsung Electronics Canada Inc., Customer
Service 55 Standish Court Mississauga,
Ontario L5R 4B2 Canada
Samsung Electronique Canada Inc.,
Service à la Clientèle 55 Standish Court
Mississauga, Ontario L5R 4B2 Canada
Samsung Electronics America, Inc.
105 Challenger Road
Ridgefield Park, NJ 07660-0511
BN68-02972A-01
LCD TV
user manual
imagine the possibilities
Thank you for purchasing this Samsung product.
To receive more complete service, please register
your product at
www.samsung.com/register
Model
Serial No.
Advertisement
Table of Contents
Troubleshooting
Related Manuals for Samsung LCD TV
Summary of Contents for Samsung LCD TV
-
Page 1: User Manual
If you have any questions or comments relating to Samsung products, please contact the SAMSUNG customer care center. Comuníquese con SAMSUNG WORLDWIDE Si desea formular alguna pregunta o comentario en relación con los productos de Samsung, comuníquese con el centro de atención al cliente de SAMSUNG. -
Page 2: Securing The Installation Space
United States, for the warranty period originally specified, and to the Original Purchaser only. The above described warranty repairs must be performed by a SAMSUNG Authorized Service Center. Along with this Statement, the Original Limited Warranty Statement and a dated Bill of Sale as Proof of Purchase must be presented to the Service Center. Transportation to and from the Service Center is the responsibility of the purchaser. -
Page 3: Table Of Contents
Network Connection ..........24 Accessories .............. 4 Connecting to a Wired Network Connecting to a Wireless Network Installing the LCD TV Stand (40 ~ 55 inch TVs) ..4 Media Play .............. 31 Viewing the Control Panel ......... 5 Connecting a USB Device Viewing the Remote Control ........ -
Page 4: Getting Started
: You can check picture and sound operation. (P. 22) Accessories ✎ Please make sure the following items are included with your LCD TV. If any items are missing, contact your dealer. ✎ The items' colors and shapes may vary depending on the models. -
Page 5: Viewing The Control Panel
Make sure that at least two persons lift and move the LCD TV. ✎ Stand the product up and fasten the screws. If you fasten the screws with the LCD TV placed down, it may lean to one side. Viewing the Control Panel ✎... -
Page 6: Viewing The Remote Control
Use these buttons in Media Play and Audio Program (SAP broadcast). (P. 17) Anynet+ modes. P.MODE: Selects picture mode. (P. 13) (�: controls recording on Samsung P.sIZE: Choose the picture size. (P. 16) recorders with the Anynet+ feature) CC: Controls the caption decoder. (P. 20) Installing batteries (Battery size: AAA) ✎... -
Page 7: Connecting To An Antenna
Connecting to an Antenna When the TV is initially powered on, basic settings proceed automatically. ✎ Connecting the mains and antenna. VHF/UHF Antenna Cable ANT OUT Power Input R-AUDIO-L Plug & Play (Initial Setup) When the TV is initially powered on, a sequence of on-screen prompts will assist in configuring basic settings. Press the POWERP button. -
Page 8: Connections
Connections Connections Connecting to an AV Device Using an hDMI / DVI Cable: hD connection (up to 1080p) We recommend using the HDMI connection for the best quality HD picture. Available devices: DVD, Blu-ray player, HD cable box, HD satellite receiver (STB). BD/DVD player/ Device HD cable/Sat. -
Page 9: Connecting To An Audio Device
Connecting to an Audio Device Using an Optical (Digital) or Audio (Analog) Cable Connection Available devices: Digital Audio System, Amplifier, Home Theater Home Theater AUDIO IN R-AUDIO-L Digital audio system OPTICAL Red White ✎ DIgITAl AUDIO OUT (OPTICAl) When a Digital Audio System is connected to the DIgITAl AUDIO OUT (OPTICAl) jack, decrease the volume of both the TV and the system. -
Page 10: Changing The Input Source
Connections Display Modes (D-sub and hDMI/DVI Input) Optimal resolution is 1920X1080@60Hz. Mode Resolution horizontal Frequency (Khz) Vertical Frequency (hz) Pixel Clock Frequency (Mhz) sync Polarity (h / V) 640 x 350 31.469 70.086 25.175 720 x 400 31.469 70.087 28.322 640 x 480 35.000 66.667... -
Page 11: Basic Features
Edit name m → Input → Edit name → EnTERE MEnU VCR / DVD / Cable sTB / satellite sTB / PVR sTB / AV Receiver / game / Camcorder / PC / DVI PC / DVI Devices / ■ TV / IPTV / Blu-ray / hD DVD / DMA: Name the device connected to the input jacks to make your input source selection easier. -
Page 12: Using Favorite Channels
Basic Features ✎ Memorizing channels Using the color buttons with the Channel list ¦ Red (Antenna): Switches to Air or Cable. m → Channel → EnTERE MEnU Green (Zoom): Enlarges or shrinks a channel number. Yellow (select): Selects multiple channel lists. Antenna (Air / Cable) Select desired channels and press the Yellow button to set all the selected channels at the same time. -
Page 13: Picture Menu
how to stop searching scrambled Channels Programmed 1. Press the EnTERE button to select stop. (in Channel list) 2. Press the ◄ button to select Yes. You can view, modify or delete a show you have reserved to 3. Press the EnTERE button. watch. -
Page 14: Adjusting Picture Settings Power
Off, the screen is turned off , but the sound remains on. the same basic set-up information will apply in most cases. Press any button to turn on the screen again. (If not, contact your computer manufacturer or Samsung Dealer.) Eco sensor (Off / On) : To enhance your power savings;... -
Page 15: Changing The Picture Options
EnTERE function. Interval: Select interval to adjust. (available in standard / Movie mode) Red: Adjust the red level. Compared to previous models, new Samsung TVs have more precise pictures. green: Adjust the green level. ✎ Blue: Adjust the blue level. - Page 16 Basic Features size : Your cable box/satellite receiver Digital noise filter (Off / low / Medium / high / Auto / ■ ■ SLEEP P.MODE P.SIZE may have its own set of screen sizes as Auto Visualization): If the broadcast signal received well.
-
Page 17: Sound Menu
SLEEP P.MODE P.SIZE SLEEP P.MODE Sound Menu Preferred language (digital channels only) Changing the Preset sound Mode ¦ FAV.CH Digital-TV broadcasts are capable of FAV.CH simultaneous transmission of many audio SLEEP P.MODE m → sound → sRs Theatersound → MEnU tracks (for example, simultaneous translations EnTERE of the program into foreign languages). -
Page 18: Setup Menu
Basic Features sPDIF Output DsT (Off / On): Switches the DST(Daylight Saving Time function) on or off. POWER SPDIF (Sony Philips Digital Interface) is used to provide digital ✎ This function is only available when the Clock sound, reducing interference going to speakers and various Mode is set to Auto. -
Page 19: Locking Programs
Channel (when the source is set to TV): Select the TV Parental guidelines: You can block TV programs desired channel. depending on their rating. This function allows you to control what your children are watching. Contents (when the source is set to UsB): Select a folder in the USB device containing music or photo files TV-Y : Young children / TV-Y7: Children 7 and over /... -
Page 20: Other Features
Basic Features POWER INFO Canadian French: You can block TV programs how to watch a restricted channel depending on their French Canadian rating. If the TV is tuned to a restricted channel, the V-Chip : General / 8 ans+: Programming generally –... - Page 21 : Provides the optimal picture quality ■ selected in Caption Mode. for Samsung DVD, Blu-ray and Home Theater products which support BD Wise. When BD Wise is turned On, The availability of captions depends on the the picture mode is automatically changed to the optimal program being broadcasted.
-
Page 22: Picture In Picture (Pip)
Yes: If the test pattern does not appear or there is noise in the test pattern, select Yes. There may be a ✎ nOTE problem with the TV. Contact Samsung’s Call Center for For PIP sound, refer to the sound select assistance (1-800-SAMSUNG). -
Page 23: Software Upgrade
Network Setup, refer to network connection or downloading the latest firmware from the “Network connection” instructions. “www.samsung.com,” to a USB memory device. ✎ If the Internet connection does not operate Current Version - the software already installed in the TV. -
Page 24: Advanced Features
Advanced Features Network Connection You can set up your TV so that it can access the Internet through your local area network (LAN) using a wired or wireless connection. Connecting to a Wired network ¦ You can attach your TV to your LAN using cable in three ways: You can attach your TV to your LAN by connecting the LAN port on the back of your TV to an external modem using a Cat 5 cable. - Page 25 1. Follow Steps 1 through 6 in the “How to set up Network Test automatically” procedure. : Off SWL(Samsung Wireless Link) 2. Set Internet Protocol setup to Manual. SWL connect 3. Press the ▼ button on your remote to go to the first entry field.
-
Page 26: Connecting To A Wireless Network
Keep the Samsung Wireless LAN Adapter at a distance from the TV. If you watch the TV with the Adapter connected nearby, images may appear corrupted for some channels. If your router, modem, or device is not certified, it may not connect to the TV via the “Samsung Wireless LAN Adapter.” Connection Methods : You can setup the wireless network connection on six ways. -
Page 27: Network Setup
2. Connect the extension cable and Samsung Wireless LAN you must perform the Samsung Auto Configuration Adapter. procedure again, beginning from Step 1. 3. Attach the Samsung Wireless LAN Adapter to the back of the TV near the top, using double-sided adhesive tape. English... - Page 28 Advanced Features network setup (PBC(WPs)) how to set up automatically To set up the wireless connection automatically, follow these how to set up using PBC(WPs) steps: 1. Follow Steps 1 through 6 in the “How to set up using If your router has a PBC(WPS) button, follow these steps: PBC(WPS)”...
-
Page 29: Network Setup (Ad-Hoc)
You can connect to a mobile device without an access point 3. On the dialog that appears, click the Support tab. through the “Samsung Wireless LAN Adapter” by using a 4. On the Support tab, click the Details button. The peer to peer network. - Page 30 Wireless link) If Your TV Fails to Connect to the Internet This function lets you connect your TV to a Samsung device Your TV may not be able to connect to the Internet (router, etc.) that supports PBC (WPS). You can connect because your ISP has permanently registered the devices to the TV even if a sharer is not connected to the TV.
-
Page 31: Media Play
PC IP addresses should be the same and only the last part (the host address) should be changed. (e.g. IP Address: 123.456.789.**) 2. Using a LAN cable, connect between the external modem and the PC onto which the Samsung PC Share Manager program will be installed. - Page 32 ✎ The Divx DRM, Multi-audio, embedded caption does not supported. ✎ Samsung PC Share manager should be permitted by the firewall program on your PC. ✎ When you use Media Play mode through a network connection, According to functions of the provided server: The sorting method may vary.
-
Page 33: Screen Display
screen Display ¦ Move to the desired file using the up/down/right/left buttons and then press the EnTERE or � (Play) button. The file is played. ✎ Supports the View Devices and Contents Mode in Media Play homepage. Information: Videos /Movie 01.avi Page You can ascertain the selected file name and the number of... - Page 34 WMA sampling rate 22050Hz mono is not supported. – Below 1280 x 720: 60 frame max – Above 1280 x 720: 30 frame max • H.263 is not supported. • GMC 2 is not support. • Only Samsung Techwin MJEPG is supported. English...
- Page 35 Playing movie continuously (Resume Play) If you exit the playing movie function, the movie can be played later from the point where it was stopped. 1. Select the movie file you want to play continuously by pressing the ◄ or ► button to select it from the file list section. 00:04:03 / 00:07:38 Movie 01.avi 2.
-
Page 36: Playing Multiple Files
Advanced Features Playing Multiple Files ¦ Playing selected video/music/photo files 1. Press the Yellow button in the file list to select the desired file. Videos 2 files selected Page /Movie 01.avi 2. Repeat the above operation to select multiple files. ✎... - Page 37 Videos/Music/Photos Play Option menu During playing a file, press the TOOls button. Category Operation Videos Music Photos Title You can move the other file directly. Repeat Mode You can play movie and music files repeatedly. Picture size You can adjust the picture size to your preference. (Mode1 / Mode2 / Original) Picture setting...
-
Page 38: Anynet
Anynet+ is a function that enables you to control all connected Samsung devices that support Anynet+ with your Samsung TV’s remote. The Anynet+ system can be used only with Samsung devices that have the Anynet+ feature. To be sure your Samsung device has this feature, check if there is an Anynet+ logo on it. -
Page 39: Setting Up Anynet
Make sure to switch to an Anynet+ device by using the Device list. Recording ¦ You can make a recording of a TV Program using a Samsung recorder. 1. Select Recording. ✎ When there are more than two recording devices When multiple recording devices are connected, the recording devices are listed. -
Page 40: Listening Through A Receiver
Advanced Features listening through a Receiver ¦ You can listen to sound through a receiver (i.e Home Theater) instead of the TV speaker. 1. Select Receiver and set to On. 2. Press the EXIT button to exit. ✎ If your receiver supports audio only, it may not appear in the device list. ✎... -
Page 41: Allshare
¦ ✎ Media function is available in all mobile devices which support Allshare. Allshare connects your TV and compatible Samsung mobile phones/ devices through a network. On your TV, you can Allowed / Denied : Allows/Blocks the mobile phone. ■... - Page 42 E Select Return Media function on that device. Using your samsung Phone to Operate Your TV Before you can use this feature, you must connect to "Unknown Device 0" is requesting that the media file be allowed to play. a Samsung mobile phone that supports ScreenShare If you wish to allow the media file to be played at your device, please press functions.
-
Page 43: Other Information
Anti-theft Kensington Lock The Kensington Lock is not supplied by Samsung. It is a device used to physically fix the system when using it in a public place. The appearance and locking method may differ from the illustration depending on the manufacturer. Refer to the manual provided with the Kensington Lock for additional information on proper use. - Page 44 Do not fasten the screws too strongly; this may damage the product or cause the product to fall, leading to personal injury. Samsung is not liable for these kinds of accidents. Samsung is not liable for product damage or personal injury when a non-VESA or non-specified wall mount is used or the consumer fails to follow the product installation instructions.
-
Page 45: Securing The Tv To The Wall
Securing the TV to the Wall Caution: Pulling, pushing, or climbing on the TV may cause the TV to fall. In particular, ensure your children do not hang over or destabilize the TV; doing so may cause the TV to tip over, causing serious injuries or death. Follow all safety precautions provided on the included Safety Flyer. -
Page 46: Troubleshooting
If the TV seems to have a problem, first try this list of possible problems and solutions. If none of these troubleshooting tips apply, visit samsung.com, then click on Support, or call Samsung customer service at 1-800-SAMSUNG. solutions and Explanations... - Page 47 If you are using a HDMI connection, check the audio output setting on your PC. Network Connection The wireless network connection failed. • Samsung Wireless USB dongle is required to use a wireless network. • Make sure the Network Connection is set to Wireless. (P. 26) •...
- Page 48 The cable/set top box remote control • Program the Cable/Sat remote control to operate the TV. Refer to Cable/Sat user manual for does not turn the TV on or off, or adjust SAMSUNG TV code. the volume. A “Mode not supported” message •...
-
Page 49: Specifications
Specifications PC Resolution (Optimum) 1920 x 1080 @ 60 Hz Environmental Considerations Operating Temperature 50°F to 104°F (10°C to 40°C) Operating Humidity 10% to 80%, non-condensing Storage Temperature -4°F to 113°F (-20°C to 45°C) Storage Humidity 5% to 95%, non-condensing Stand Swivel (Left / Right) -20˚... -
Page 50: License
Other Information license ¦ Manufactured under license from Dolby Laboratories. Dolby and the double-D symbol are trademarks of Dolby Laboratories. DivX Certified to play DivX video up to HD 1080p, including premium content. ABOUT DIVX VIDEO: DivX® is a digital video format created by DivX,Inc. This is an official DivX Certified device that plays DivX video. -
Page 51: Dimensions
NOTE: All drawings are not necessarily to scale. Some dimensions are subject to change without prior notice. Refer to the dimensions prior to performing installation of your TV. Not responsible for typographical or printed errors. © 2010 Samsung Electronics America, Inc English... -
Page 52: Index
Other Information Index AllShare Screen Fit Antenna HDMI Sleep Timer Anynet+ Home theater 9, 38 Slide Show AUDIO OUT Software Upgrade Auto Adjustment Source List Auto Program Speaker Select Internet Protocol Setup Standby mode Supported Subtitle Formats Supported Video Formats Blanking Bracket License Balance... - Page 53 This page is intentionally left blank.
