- Page 1 DIGITAL FLAME-AMP STYLE 6 FARAD CAPACITOR BANK ACAP601Q...
- Page 2 With four levels of play, one is right for you to get started in the Audiobahn family. Our Technical Department and entire staff look to strive above and beyond the rest of the pack by going that extra mile to help you out.
- Page 3 Table of Contents Table of Contents INTRODUCTION CAPACITOR INTRODUCTION SPECIFICATIONS INSTALLATION AND MOUNTING ADJUSTMENTS AND TROUBLESHOOTING WARNING / DISCLAIMER WARRANTY 10-11...
- Page 4 Congratulations on your purchase of the worlds finest brand of car audio products. Here at Audiobahn Inc. we are devoted to making our musical reproduction the very best, and we are pleased you have chosen our product. Through years of engineering expertise, hand craftsmanship, and critical testing procedures, we have created a wide range of products that reproduce music with all the clarity and richness you deserve.
- Page 5 Remote Turn-on Distribution Auto on/off Blue L.E.D. Four Digit Readout Electronic Polarity Protection Circuit Overvoltage Protection Circuit Soft on/off Circuit Aluminum Heat Sink with Chrome Plated Cover Wooden Gift Box Dimensions ACAP601Q: 12 3/4" (W) x 3 1/2" (H) x 13" (D)
- Page 6 Capacitor Introduction When installed properly, your new stiffening capacitor will provide years of dependable service. There are many benefits of adding a stiffening capacitor. The most significant benefit is the capacitors ability to improve bass performance in your sound system. This is possible due to the voltage stabilizing effects of the capacitor.
- Page 7 Installation and Mounting You can find the mounting screw sin the attached hardware bag.. Then use the lock screws to hold the tab in the car's wall. Make sure the whole unit does not move after you install all four tabs.
- Page 8 Features A) Blue lite digital voltage meter with 4 digit readout that can measure 0.01 DCV. B) Positive pole distribution block with 4 maxi fuses. Negative pole distribution block. These connections can offer a simple alternative to using various power and ground distribution blocks when connecting multiple amplifiers and accessories.
- Page 9 Charging / Discharging WARNING!!! Before making or breaking any electrical connections, please make sure to read the following instructions on how to properly charge and discharge the capacitor. Not following the charge / discharge instructions can lead to permanent damage to the capacitor, which is not covered under the manufacturer warranty. Charging After mounting the capacitor in its final position, attach the ground to the capacitor and the chassis grounding location.
- Page 10 Wiring Follow the attached wiring diagram to connect all wiring and parts. Below is an illustration showing correct wiring for the capacitor. BEFORE MAKING ANY POWER CONNECTIONS, DISCONNECT THE BATTERY POWER FROM YOU SOUND SYSTEM.
- Page 11 Dicharging the Capacitor Discharging If you plan to store your vehicle or plan on not using the system for a long period of time, we suggest to remove the capacitor. Anytime you disconnect the capacitor's power wire from the battery, you need to properly discharge the capacitor. This is done by using the same supplied bulb as you used for charging the capacitor.
- Page 12 Troubleshooting Should you encounter a problem with your capacitor, you can follow the steps below to make sure that it is working properly. 1. Follow all power (+) and ground (-) connections to and from the capacitor. Make sure there are no kinks in the wire and no cuts either. If there is a problem in the wiring, make sure to use new wire and place the wire in a good location where it will not be roughed up and abused.
- Page 13 Using a fuse of different type or rating may result in damage to this system which is not covered by the warranty. Disclaimer Specifications are subject to change with out notice. For the most updated Specifications call Audiobahn, or your local Authorized Audiobahn Dealer, or check the Audiobahn website. www.audiobahninc.com...
