- Page 1 QUALITY, RLIABILITY, & PURE BLISS DIGITAL CYLINDER CAPACITORS ACAP7P / ACAP3P OPERATING INTSTRUCTIONS PLEASE RETAIN MANUAL FOR FUTRE USE AND REFERENCE...
- Page 2 With four levels of play, one is right for you to get started in the Audiobahn family. Our Technical Department and entire staff look to strive above and beyond the rest of the pack by going that extra mile to help you out.
-
Page 3: Table Of Contents
Table of Contents Table of Contents INTRODUCTION CAPACITOR INTRODUCTION SPECIFICATIONS CHARGING / DISCHARGING MOUNTING AND INSTALLATION ADJUSTMENTS AND TROUBLESHOOTING WARNING / DISCLAIMER WARRANTY 10-11... -
Page 4: Introduction
Congratulations on your purchase of the worlds finest brand of car audio products. Here at Audiobahn Inc. we are devoted to making our musical reproduction the very best, and we are pleased you have chosen our product. Through years of engineering expertise, hand craftsmanship, and critical testing procedures, we have created a wide range of products that reproduce music with all the clarity and richness you deserve. -
Page 5: Capacitor Introduction
Capacitor Introduction When installed properly, your new stiffening capacitor will provide years of dependable service. There are many benefits of adding a stiffening capacitor. The most significant benefit is the capacitors ability to improve bass performance in your sound system. This is possible due to the voltage stabilizing effects of the capacitor. -
Page 6: Specifications
Specifications Capacitance ACAP7P / ACAP3P------------------------------------------------------------1,000,000 microfarads (1 Farad) Working Voltage ACAP7P---------------------------------------------------------------------------24V ACAP3P---------------------------------------------------------------------------20V Surge Voltage ACAP7P---------------------------------------------------------------------------30V ACAP3P---------------------------------------------------------------------------24V E.S.R. (Equivalent Series Resistance)----------------------------------0.0016 ohm @ 200 Hz / 25 C Capacitance Tolerance------------------------------------------------------+/- 5%... - Page 7 Charging WARNING!!! Before making or breaking any electrical connections, please make sure to read the following instructions on how to properly charge and discharge the capacitor. Not following the charge / discharge instructions can lead to permanent damage to the capacitor, which is not covered under the manufacturer warranty. Charging After mounting the capacitor in its final position, attach the ground to the capacitor and the chassis grounding location.
- Page 8 Discharging Discharging If you plan to store your vehicle or plan on not using the system for a long period of time, we suggest to remove the capacitor. Anytime you disconnect the capacitor's power wire from the battery, you need to properly discharge the capacitor. This is done by using the same supplied bulb as you used for charging the capacitor.
-
Page 9: Installation And Mounting
Installation and Mounting For maximum performance, the capacitor should be installed as close to your amplifier(s) as possible. The ideal location is one which allows for short wiring runs while keeping the capacitors somewhat isolated from the heat created by the amplifier system. The positive (+) power wire should be kept as short as possible and be connected to the amplifier's battery supply input. -
Page 10: Troubleshooting
Troubleshooting Should you encounter a problem with your capacitor, you can follow the steps below to make sure that it is working properly. 1. Follow all power (+) and ground (-) connections to and from the capacitor. Make sure there are no kinks in the wire and no cuts either. If there is a problem in the wiring, make sure to use new wire and place the wire in a good location where it will not be roughed up and abused. -
Page 11: Warranty
Using a fuse of different type or rating may result in damage to this system which is not covered by the warranty. Disclaimer Specifications are subject to change without notice. For the most updated Specifications call Audiobahn, or your local Authorized Audiobahn Dealer, or check the Audiobahn website. www.audiobahninc.com... -
Page 12: Warranty
You must receive prior authorization and an RA# before sending in any complete enclosure). Audiobahn will only replace L.E.D.(s) found to be defective at the time of purchase. Audiobahn warranties do not cover the following: Any product not purchased from an Authorized Audiobahn Dealer (including Internet... - Page 13 Dealer look at the product to confirm the source of the problem. Any product found to have a manufacturer defect will be replaced with a new piece of the same or similar model, or repaired at the discretion of Audiobahn. Any product found to have no manufacturer defect will be returned to the sender at their cost.
