- Page 1 HIGH PERFORMANCE RACK MOUNT POWER CAPACITOR BANK ACAP100Q ACAP300Q ACAP500Q...
- Page 2 With four levels of play, one is right for you to get started in the Audiobahn family. Our Technical Department and entire staff look to strive above and beyond the rest of the pack by going that extra mile to help you out.
- Page 3 Table of Contents Table of Contents INTRODUCTION CAPACITOR INTRODUCTION SPECIFICATIONS INSTALLATION AND MOUNTING ADJUSTMENTS AND TROUBLESHOOTING WARNING / DISCLAIMER WARRANTY 10-11...
- Page 4 Congratulations on your purchase of the worlds finest brand of car audio products. Here at Audiobahn Inc. we are devoted to making our musical reproduction the very best, and we are pleased you have chosen our product. Through years of engineering expertise, hand craftsmanship, and critical testing procedures, we have created a wide range of products that reproduce music with all the clarity and richness you deserve.
-
Page 5: Specifications
Specifications MODEL: ACAP100Q 1 FARAD DIGITAL CAPACITOR WITH BANK WITH BLUE DIGITAL VOLTAGE DISPLAY, POSITIVE / NEGATIVE POLE CONNECTING BLOCK Capacitance--------------------------------------------------------------------1,000,000 micro farad (1 Farad) Working Voltage---------------------------------------------------------------24V DC Surge Voltage------------------------------------------------------------------30V DC E.S.R. (Equivalent Series Resistance)----------------------------------0.0012 ohm @ 120Hz / 25 C... -
Page 6: Capacitor Introduction
Capacitor Introduction When installed properly, your new stiffening capacitor will provide years of dependable service. There are many benefits of adding a stiffening capacitor. The most significant benefit is the capacitors ability to improve bass performance in your sound system. This is possible due to the voltage stabilizing effects of the capacitor. -
Page 7: Installation And Mounting
Installation and Mounting Please refer to the following drawing to install screws into the mounting tabs of the capacitor's side rails. Use the lock screws to mount the capacitor brackets to the vehicle. Make sure the capacitor is securely mounted using all four brackets. Brackets are supplied with all rack mount amplifiers. -
Page 13: Troubleshooting
Troubleshooting Should you encounter a problem with your capacitor, you can follow the steps below to make sure that it is working properly. 1. Follow all power (+) and ground (-) connections to and from the capacitor. Make sure there are no kinks in the wire and no cuts either. If there is a problem in the wiring, make sure to use new wire and place the wire in a good location where it will not be roughed up and abused. -
Page 14: Warning / Disclaimer
Using a fuse of different type or rating may result in damage to this system which is not covered by the warranty. Specifications are subject to change without notice. For the most updated Specifications call Audiobahn, or your local Authorized Audiobahn Dealer, or check the Audiobahn website.
