NOTE:
Please read all instructions
carefully before using this
product
Table of Contents
Safety Notice
Hardware Identifier
Assembly Instruction
Parts List
Warranty
Ordering Parts
Model
TC-3500
Retain This
Manual for
Reference
08-5-06
OWNER'S
MANUAL
POWER STATION
14777 DON JULIAN RD., CITY OF INDUSTRY, CA 91746
Tel: (800) 999-8899 Fax: (626) 961-9966
www.impex-fitness.com
info@impex-fitness.com
APEX
TC-3500
®
IMPEX
INC.
Advertisement
Table of Contents
Related Manuals for Impex APEX TC-3500
Summary of Contents for Impex APEX TC-3500
- Page 1 NOTE: Please read all instructions carefully before using this product APEX Table of Contents POWER STATION Safety Notice Hardware Identifier TC-3500 Assembly Instruction Parts List Warranty Ordering Parts Model TC-3500 Retain This Manual for Reference 08-5-06 OWNER'S MANUAL ® IMPEX INC.
-
Page 2: Table Of Contents
WARRANTY....................…. 11 ORDERING PARTS..................… 11 BEFORE YOU BEGIN ® Thank you for selecting the APEX TC-3500 by IMPEX INC. For your safety and benefit, read this manual carefully before using the machine. As a manufacturer, we are committed to provide you complete customer satisfaction. -
Page 3: Important Safety Notice
IMPORTANT SAFETY NOTICE PRECAUTIONS This exercise machine is built for optimum safety. However, certain precautions apply whenever you operate a piece of exercise equipment. Be sure to read the entire manual before you assemble or operate your machine. In particular, note the following safety precautions: 1. - Page 4 WARNING LABEL REPLACEMENT The warning labels shown here have been placed on the Rear Frame. If the labels are missing or illegible, please call customer service at 1-800-888-8899 for replacements. Apply the labels in the location shown.
-
Page 5: Hardware Identifier
HARDWARE PACK... -
Page 6: Assembly Instruction
ASSEMBLY INSTRUCTION Tools Required Assembling the Machine: Two Adjustable Wrenches and Allen Wrenches NOTE: It is strongly recommended two or more people assembling this machine to avoid possible injury. STEP 1 (See Diagram 1) A.) Attach the Lower Vertical Frame (#5) to the Rear Frame (#1). Attach the Right & Left Stabilizers (#3 &... - Page 7 STEP 2 (See Diagram 2) A.) Attach the Upper Vertical Frame (#6) onto the Lower Vertical Frame (#5). Secure it with one M10 x 3 1/8” Allen Bolt (#24), two ¾” Washers (#27), and one M10 Aircraft Nut (#28). Do not tighten the nut and bolt yet. B.) Insert the Upper Frame (#2) into the Rear Frame (#1).
- Page 8 STEP 3 (See Diagram 3) A.) Attach the Right and Left Dip Supports (#8 & #9) to the Upper Vertical Frame (#6). Secure them with two M10 x 3 5/8” Carriage Bolts (#23), ¾” Washers (#27), and M10 Aircraft Nuts (#28). B.) Insert a Vertical Handle (#10) into the hole on each Dip Support.
- Page 9 STEP 4 (See Diagram 4) A.) Attach the Backrest Pad (#12) to the Upper Vertical Frame (#6). Secure it with two M8 x 2 ¾” Allen Bolts (#26) and 5/8” Washers (#29). B.) Attach the Arm Pads (#11) to the Right & Left Dip Supports (#8 & #9). Secure each Arm Pad with two M8 x 2 ¾”...
-
Page 10: Exploded Diagram
EXPLODED DIAGRAM... -
Page 11: Parts List
Parts list KEY NO. DESCRIPTION Q’ty Rear Frame Upper Frame Right Stabilizer Left Stabilizer Lower Vertical Frame Upper Vertical Frame Chin-up Bar Right Dip Support Left Dip Support Vertical Handle Arm Pad Backrest Pad 5 3/8” Handle Grip Sleeve Foam Tube Foam Roll Foam Roll End Cap 8 ¼”... -
Page 12: Limited Warranty
® IMPEX INC. LIMITED WARRANTY ® IMPEX Inc. ("IMPEX ") warrants this product to be free from defects in workmanship and material, under normal use and service conditions, for a period of two years on the Frame from the date of purchase. This warranty extends only to the original purchaser. IMPEX's obligation under this Warranty is limited to replacing or repairing, at IMPEX's option.
