Nieco 980 GAS Owner's Manual

Automatic gas boiler
Hide thumbs
Table of Contents

Advertisement

Quick Links

Download this manual
AUTOMATIC
FOODSERVICE
EQUIPMENT
AUTOMATIC GAS BROILER
MODELS 980 GAS, 950 GAS AND 930 GAS
OWNER'S MANUAL
IMPORTANT: RETAIN THIS MANUAL IN A SAFE PLACE
FOR FUTURE REFERENCE.
FOR YOUR SAFETY:
Do not store or use gasoline or other flammable vapors or liquids in
the vicinity of this or any other appliance.
WARNING: Improper installation, adjustment, alteration, maintenance
can cause property damage, injury, or death. Read the installation,
operating and maintenance instructions thoroughly before installing
or servicing this equipment.
Broiler area must be kept free of combustible materials, and the flow of combustion and ventilation air must not
be obstructed. Operating personnel must not perform any maintenance or repair functions. Contact your Nieco
Authorized Dealer.
In a prominent location, post instructions to be followed in the event the user smells gas. This information shall be
obtained by consulting your local gas supplier.

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the 980 GAS and is the answer not in the manual?

Questions and answers

Related Manuals for Nieco 980 GAS

Summary of Contents for Nieco 980 GAS

  • Page 1 Broiler area must be kept free of combustible materials, and the flow of combustion and ventilation air must not be obstructed. Operating personnel must not perform any maintenance or repair functions. Contact your Nieco Authorized Dealer.

  • Page 3: Table Of Contents

    TABLE OF CONTENTS General Information ........................4 Description Machine Installation ........................5 Pre-Installation Mounting Hood Requirements Clearance Gas Connection Electrical Connection Pre-Operation Check Gas Connectors and Restraining Device Operation ............................8 Controls and Indicators Gas System Controls Step-by-Step Lighting Procedure Shutdown Procedure Automatic Temperature Control Bun Platen Adjustment Assembly/Disassembly and Cleaning..................11 Conveyor Belt Removal .......................14...

  • Page 4: General Information

    Model 930 Gas DESCRIPTION The Nieco Automatic Gas Broiler is a compact self-contained unit designed to broil hamburgers or other food products by use of a conveyorized cooking section. In addition, these broilers are equipped with a bun grilling section which caramelizes the buns to a golden brown.

  • Page 5: Pre-Installation

    B. INSTALLATION PRE-INSTALLATION Uncrate the broiler, and inspect for shipping damage. Contact the factory if there is obvious damage. Remove the tape securing the machine parts, and install the parts in their proper location. Refer to the Parts and Location section of this manual. If you find concealed damage to any part of this unit, contact your freight carrier immediately.

  • Page 6: Electrical Connection

    pilot tubing and inlet connections as soon as the appliance is connected to the gas supply. Note: This appliance and its individual shutoff valve must be disconnected from the gas supply piping system during any pressure testing of that system at test pressures in excess of 1/2 psig (3.45 kPa).
  • Page 7 INSTALLING GAS APPLIANCE CONNECTORS AND FLEXIBLE GAS LINES CORRECTLY WRONG RIGHT For safety in the kitchen area, and to insure maxi- Avoid sharp bends and Minimum pull of equip- mum service life, it is vitally important to correctly kinks when pulling equip- ment is permissible for install connectors.

  • Page 8: Operation

    C. OPERATION Controls and Indicators Gas Gauge Recommended Settings: Natural Gas - 3” Low, 5” High Propane - 8” Low, 11” High Gas Safety Valve (red push button) Motor Breaker Switch Motor Speed Control 5 Amp Fuse Main On/Off Switch Pilot Ignitor Power On Indicator Lamp (red)

  • Page 9: Step-By-Step Lighting Procedure

    STEP-BY-STEP LIGHTING PROCEDURE Before lighting, make sure that all parts are installed in the proper location, all controls are turned off, and the ventilation hood fan is turned on. 1. Turn on Main Power Switch. 2. Turn on Motor Switch. 3.

  • Page 10: Automatic Temperature Control

    AUTOMATIC TEMPERATURE CONTROL (ATC) The Nieco Automatic Temperature Control (ATC) is a system that operates the broiler at two different energy input rates; a high energy input for initial warm-up and periods of high volume, and low energy for regular operation. This dual input rate and the ATC allow the broiler to operate at a very consistent tem- perature throughout the day and thus provide a very consistently broiled product.

  • Page 11: Assembly/Disassembly And Cleaning

    D. ASSEMBLY/DISASSEMBLY AND CLEANING If this appliance is connected to the gas supply by a flexible gas line and quick disconnect coupling, it must also be con- nected to a restraining device (see installation instructions). If the appliance is moved and then returned to its original position, it must be reconnected to the restraining device and the casters locked before resuming operation.
  • Page 12 9. Remove the Burner Access Cover. 10. Slide the Lower Burners out and remove the Protective Shields. Clean the shields by scraping off any built up residue, then soak in soap and water. Clean the shields daily. This will help to prolong the life of the burner and keep the broiler cooking properly.
  • Page 13 WEEKLY CLEANING In addition to the daily cleaning, perform these steps on a weekly basis. 1. Remove the Upper Burners and clean as following the steps outlined below (see A,B & C). 2. Clean all Pilot Burners and Main Burner Orifices with rubbing alcohol and a pipe cleaner.

  • Page 14: Conveyor Belt Removal

    E. CONVEYOR BELT REMOVAL Before beginning, notice the way the belt runs through the broiler. Also notice the direction the knuckles face. Be sure to re-assemble in the same way. 1. Run belt until the Master Link is near the front idler shaft. 2.

  • Page 15: Conveyor Belt Tension

    F. CONVEYOR BELT TENSION Maintain proper tension on the conveyor belts to prevent jamming. Bearing spacers (pictured below) are supplied with the broiler to make minor tension adjustments. Major tension adjustments are made by removing a link or links from the belt. The diagram on the left shows the spacer in the stored position.

  • Page 16: Parts And Location

    G. PARTS AND LOCATION Model 980 Gas - Feed End View...
  • Page 17 G. PARTS AND LOCATION Model 980 Gas - Left Side View...
  • Page 18 G. PARTS AND LOCATION Model 980 Gas - Right Side View...

  • Page 19: Model 950

    G. PARTS AND LOCATION Model 950 Gas - Feed End View...
  • Page 20 G. PARTS AND LOCATION Model 950 Gas - Left Side View...
  • Page 21 G. PARTS AND LOCATION Model 950 Gas - Right Side View...

  • Page 22: Model 930

    G. PARTS AND LOCATION Model 930 Gas - Feed End View...
  • Page 23 G. PARTS AND LOCATION Model 930 Gas -Left Side View...
  • Page 24 G. PARTS AND LOCATION Model 930 Gas - Right Side View...

  • Page 25: Troubleshooting Guide

    H. Troubleshooting Guide PROBLEM PROBABLE CAUSES SOLUTION 1. Pilot Burner dirty, or orifice plugged. Pilot Burners won't light. 1. Clean pilot burner, replace orifice. 2. Push button valve not fully depressed. 2. Repeat start-up procedure. 3. Air in pilot line. 3.
  • Page 26 PROBLEM PROBABLE CAUSES SOLUTION 1. Conveyor belt jammed Motor control switch trips. 1. Remove jam, reset switch. 2. Switch defective. 2. Replace. 3. Drive chain binding. 3. Adjust tension of chain. 4. Shorted wire to motor. 4. Repair wire. 5. Gear motor defective. 5.

  • Page 27: Specifications

    I. SPECIFICATIONS Model 980 Weight PPROXIMATE HIPPING Exhaust 1100 1869 YPICAL Dimensions INCH 1270 ENGTH ⁄ 1638 EIGHT ⁄ IDTH Energy - Gas Model 3/4" N.P.T. ONNECTION 208-240V/120V 1Ø LECTRICAL ONNECTION 50/60 H SPECIFY EXACT VOLTAGE . KW/ 3" W.C. 5"...
  • Page 28 I. SPECIFICATIONS Model 950 Weight PPROXIMATE HIPPING Exhaust 1360 YPICAL Dimensions INCH 1143 ENGTH ⁄ EIGHT ⁄ IDTH Energy - Gas Model 3/4" N.P.T. ONNECTION 208-240V/120V 1Ø LECTRICAL ONNECTION 50/60 H SPECIFY EXACT VOLTAGE . KW/ 3" W.C. 5" W.C. ATURAL BTU/ 75,000...
  • Page 29 Model 930 Gas Weight PPROXIMATE Exhaust 1020 YPICAL Dimensions INCH ENGTH ⁄ EIGHT ⁄ IDTH Energy - Gas Model 1/2" N.P.T. ONNECTION 208-240V/120V 1Ø LECTRICAL ONNECTION 50/60 H SPECIFY EXACT VOLTAGE . KW/ 3" W.C. 5" W.C. ATURAL BTU/ 54,000 70,000 KCAL/ 12,350...

  • Page 30: Wiring Diagrams

    J. WIRING DIAGRAM 930, 950, 980 Gas - Domestic U.S.A.
  • Page 31 J. WIRING DIAGRAM 930, 950, 980 Gas - Export...
  • Page 32 Nieco Corporation • 15 Guittard Rd. • Burlingame, CA 94010 • (650) 697-7335 • Fax (650) 697-3014 Reorder # 9999-99113 2/00 e-mail: nieco@nieco.com Printed in the USA MP...
