INSTALLATION & MAINTENANCE
The User's Manual is for common use.
Make use of the User's Manual depending upon your washing machine model.

■ ENVIRONMENT

Leave some space
Maintain at least 10cm between the washer and the wall.
Place the washer on a sturdy flat surface.
If the washer is placed on an uneven or weak surface, noise or vibration occurs.
(Allowable is 1˚)
Adjust the legs for even placement.
Never install the washer near water.
Do not place the washer in steamy rooms or where the washer is directly exposed
to rain. Moisture may destroy the electrical insulation causing an electrical shock
hazard.
Avoid direct sunlight or heaters.
As plastic an electrical components are affected by direct heat, never place the
washer near furnaces, boilers, etc. Do not place under direct sunlight.

■ LEVELLING

• If the washer is not leveled with the ground, it makes the machine tremble
more or be out of order. So, make sure that the washer is leveled properly.
SEE IF THE MACHINE IS PLACED LEVEL BY CHECKING THE POSITION OF THE
WASHING TUB.
• Open the lid of the machine, pour water into
the tub up to the level just below the pulsator,
and adjust the legs so that the pulsator is
positioned at the center of the water as shown
in the figure.
• Place the machine more than 10cm away from the wall.
• Adjust the legs on feet.
Leveling With the Leveling Screw (Manual Adjustable Feet)
• Gently lift up the machine • When done, put
and turn the adjustable it down to the
feet to the left to find the original position.
optimal balance.
ADJUSTMENT THE HEIGHT OF THE MACHINE
Waterdrop
mark
Water
• After adjusting
the feet, do not
forget to fasten
the locking nut for
safety purposes.
(Failing to do so
may cause it to
loosen)
- 10 -
Adjust the legs to level the washer.
Be careful not to put in your hand under the legs.
Pull the handles located at the right and left of the
front side and slide off.
Adjust the height of the machine upward or
downward.
When the adjustment is finished, push the handles
to fix the adjusting legs.
Cause How to level
The front part is Level it by adjustable legs.
lower
The back part is Adjust the height by using the adjustable
lower rubber or prop at the back.
The left part is lower Adjust the left part by using the
adjustable legs at the front and the
adjustable rubber at the back.
The right part is Adjust the right part of the washer by
lower using the adjustable leg at the front and
the adjustable rubber at the back.
