Summary of Contents for Zoombak ZB100
- Page 1 Advanced GPS Car Locator User Guide...
- Page 2 NOTICES This document neither grants any license nor conveys any rights with respect to the subject matter hereof or otherwise. Zoombak expressly retains all intellectual and other property rights with respect to this document and all matters set forth herein. This document is neither an offer nor an acceptance.
-
Page 3: Table Of Contents
Table of Contents Introduction ....................1 Getting Started .................... 2 Key Functions ....................2 Zoombak Car Locator Package Contents ..........3 Using the Car Locator .................4 Charging the Battery ..................4 Battery Life ....................5 Powering the Car Locator ON/OFF ............6 Monitoring the Car Locator Status ............ -
Page 5: Introduction
This Guide will introduce you to all of the features of your Zoombak Car Locator device. If you have any questions, please contact Zoombak Customer Care on freephone 0800 028 0101 or visit our website at www.zoombak.co.uk. -
Page 6: Getting Started
• Zoombak Car Locator Package Contents Front / Aerial View of Locator Key Functions • USB Charger Jack – Connects the Zoombak Car Locator to the AC Wall Charger (included) or 12 Volt DC Car Charger (included for installed option) •... -
Page 7: Zoombak Car Locator Package Contents
Zoombak Car Locator Package Contents When you purchase the Zoombak Car Locator, the package should contain the following: • Zoombak Car Locator • Zoombak Car Locator Installation Kit (bracket, screws, Velcro set, zip ties and 2-sided tape) • AC Wall Charger •... -
Page 8: Using The Car Locator
• Placing the Locator In Your Car Charging the Battery Before using the Zoombak Car Locator for the first time, you will need to fully charge the battery. Follow these simple instructions to charge the battery. The initial battery charge time will be 6 hours; each subsequent battery charge will be approximately 4 hours. -
Page 9: Battery Life
User Guide titled “Charging the Battery.” Rechargeable batteries have a limited number of charge cycles and may eventually need to be replaced. The Zoombak Locator battery is not user replaceable; it can only be replaced by an authorized service provider. -
Page 10: Powering The Car Locator On/Off
Powering the Car Locator ON/ OFF In order to power the Zoombak Car Locator on or off, follow these simple instructions: 1. Power ON—Press and hold the Power Button until the Locator Status LED Indicator begins to glow (approximately two seconds). Blinking green indicates operation OK. -
Page 11: Placing The Locator In Your Car
• In the glove box • In the centre console If you choose to install your Zoombak Car Locator using the included 12 Volt DC Car Charger and Zoombak Car Locator Installation Kit, please review carefully the Zoombak Car Locator Installation Guide before installing and using your Zoombak Car Locator. -
Page 12: Safety And Warranty Information
Leakage of ingredients contained within the battery pack or the combustion of ingredients can cause personal injury to you or your car, as well as damage to your Zoombak Car Locator. If battery leakage occurs, avoid contact with skin. If contact occurs, immediately wash thoroughly with soap and water. -
Page 13: Zoombak Weee Compliance Statement
The European Union’s Waste Electrical and Electronic Equipment (WEEE) Directive has been implemented in member states during 2006. There are a number of obligations imposed on Zoombak as a supplier of mobile and electronic equipment. Zoombak’s compliance approach for each of these obligations is provided below. -
Page 14: Warranty Information
Care Centre on freephone 0800 028 0101 for troubleshooting information and repair or replacement options. In most cases, it will be necessary to ship the product to Zoombak. Please do not send any products to Zoombak without first contacting our Customer Care Centre. -
Page 15: Contacting Customer Care
Contacting Customer Care Need help troubleshooting or operating your Zoombak Car Locator? Contact Zoombak Customer Care via the internet at www.zoombak.co.uk or call freephone 0800 028 0101, Monday – Sunday, 24 hours a day (times subject to change) to speak to a Customer Care representative. -
Page 16: Specifications And Certifications
Feature Specification Size 72.9 x 43.1 x (19.07 ~ 20.07) mm Weight 71 grams Model Number ZB100 Model Number ZB101 GSM 850 = ZB-100 GSM 900 = ZB-101 824 – 849 MHz (Tx) 880 – 915 MHz (Tx) 925 – 960 MHz (Rx) 869 –... -
Page 17: Certifications
Services that rely on location information depend on your device’s ability to acquire satellite signals (often not available indoors) and network coverage. Estimated future coverage subject to change. See www.zoombak.co.uk for coverage map and details. zoombak.co.uk... - Page 18 www.zoombak.co.uk...
