4.4 ASUS Unique Overclocking Utility—
TurboV EVO
ASUS TurboV EVO introduces TurboV, CPU Level UP and Turbo Key—three powerful
tools that allow you to overclock your system effectively. Install ASUS TurboV EVO from the
support DVD that came with the motherboard package.
If the TurboV EVO is correctly installed, you will find the TurboV EVO icon
on the Windows
®
EVO control panel.
•
•
4.4.1

Using ASUS TurboV

ASUS TurboV allow you to overclock the CPU frequency, CPU voltage, CPU/NB voltage,
DRAM voltage, and the integrated GPU voltage/frequency in Windows
takes effect in real-time.
Refer to the CPU documentation before adjusting CPU voltage settings. Setting a high
voltage may damage the CPU permanently, and setting a low voltage may make the
system unstable.
For system stability, all changes made in ASUS TurboV (except for Auto Tuning) will not
be saved to BIOS settings and will not be kept on the next system boot. Use the Save
Profile function to save your customized overclocking settings and manually load the
profile after Windows starts.
Easy Mode
Manual Mode
Load profile
Target values
Start-up values
Advanced GPU
settings
Advanced CPU and
chipset voltage settings
Click to show / hide
more settings
•
•
4-10
notification area. Click on the icon to display the TurboV
Refer to the software manual in the support DVD or visit the ASUS website at
www.asus.com for detailed software configuration.
When TurboV EVO is enabled, ASUS EPU will be set to High Performance mode
automatically.
Click to restore all start-up settings
GPU Boost is available only when you install the GPU Boost driver from the
motherboard support DVD.
For advanced overclock ability, adjust first the BIOS items, and then proceed more
detailed adjustments using TurboV.
® environment and
Applies all changes immediately
Chapter 4: Software support
Auto Tuning Mode
Save the current
settings as a
new profile
Adjustment
sliders
CPU ratio setting
for each CPU core
Undoes all changes
without applying
