REMOTE KEY WITH PCC* – PERSONAl CAR COMMuNICATOR
PCC*
1
Green light: vehicle is locked.
2
Yellow light: vehicle is unlocked.
3
Red light: alarm has been triggered.
4
Alternatively flashing red lights: the alarm
was triggered less than 5 minutes ago.
STARTING THE ENGINE
– Holding the end of the remote key with the base of
the key blade, insert the remote key into the ignition
slot and press it in as far as possible.
– Press the START/STOP/
ENGINE button briefly to start
the engine.
the doors and trunk and arms
Locks
the alarm
.
A
the doors and trunk, and dis-
Unlocks
arms the alarm
Trunk (press once to unlock; press twice to
open the trunk slightly).
Approach lighting illuminates lights in door
mirrors, cabin, footwells, license plates. Turn
signals and parking lights illuminate.
"Panic" alarm.
Press and hold to sound the alarm.
–
Turn off alarm with unlock button.
nformation about the vehicle can be
I
gathered within a range of 300 ft.
(100 m).
Press the button and wait for 7 sec-
–
onds.
If the vehicle is out of range when the
button is pressed, the most recently
stored status information will be shown.
A
The accessory inclination and movement alarm sensors
can be turned off. See the "Alarm" section of your owner's
manual for information.
B
Automatic relock occurs if no door/trunk is opened within 2
.
minutes after unlock
– Press the brake pedal.
COlDSTART
NOTE
After cold starts, your engine will idle at a
higher speed for a short time.
B

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the S80 and is the answer not in the manual?

Questions and answers

Related Manuals for Volvo S80

Summary of Contents for Volvo S80

  • Page 1 REMOTE KEY WITH PCC* – PERSONAl CAR COMMuNICATOR the doors and trunk and arms Locks the alarm the doors and trunk, and dis- Unlocks arms the alarm Trunk (press once to unlock; press twice to open the trunk slightly). Approach lighting illuminates lights in door mirrors, cabin, footwells, license plates. Turn signals and parking lights illuminate. “Panic” alarm. Press and hold to sound the alarm. – Turn off alarm with unlock button. nformation about the vehicle can be gathered within a range of 300 ft. (100 m). PCC* Press the button and wait for 7 sec- – Green light: vehicle is locked. onds. Yellow light: vehicle is unlocked. If the vehicle is out of range when the button is pressed, the most recently Red light: alarm has been triggered. stored status information will be shown. Alternatively flashing red lights: the alarm The accessory inclination and movement alarm sensors was triggered less than 5 minutes ago. can be turned off. See the “Alarm” section of your owner’s manual for information.

  • Page 2: Blind Spot Information System (Blis)

    SWITCHING OFF THE ENGINE AND RE- BlIND SPOT INFORMATION SYSTEM (BlIS)* MOvING THE REMOTE KEY If the BLIS indicator lights illuminate even when there Park the vehicle and press are no vehicles in the blind area, this may be due to the START/STOP ENGINE button to switch off the light reflected from a wet road surface, the vehicle’s engine. own shadow against a large, light, smooth surface, or sunlight directly in the camera when the sun is low Pull the remote key out of on the horizon. the ignition slot. If there is a fault with the system, Blind spot syst. Service required will be displayed. IGNITION MODES 0 AND I The brake To access the following ignition modes: Modes Active functions pedal must not be depressed.

  • Page 3: Cd/Dvd Player

    INFOTAINMENT Center console display main view Turn to adjust volume. Infotainment systems modes (RADIO, MEDIA, Press and hold for ON/OFF . Press briefly to TEL, etc). Press and hold EXIT for several sec- mute/unmute. onds to display. Press to choose AM, FM1, etc. The selected mode’s main functions. In the Press MEDIA to choose Disc, AuX/ uSB , etc. example above, Radio mode is selected and the various radio wavebands are displayed. Press for sound settings such as Bass, Treble or Surround* – Turn vOl (1) to adjust. RADIO Turn to choose a station. For FM1/FM2, an automatically generated list of the strongest stations is displayed. Search for stations with the left/right arrow keys. Press and hold to find the strongest stations. Navigating the menus Press briefly to tune to preset stations. Store up to 10 stations each for FM1/FM2/AM Press briefly Left/right arrow keys: to search holding in buttons 0–9 until the stored station is for the next radio station, change tracks on a Press and hold confirmed in the display.

  • Page 4: Electronic Climate Control-Ecc

    ElECTRONIC ClIMATE CONTROl—ECC AuTOMATIC CONTROl MANuAl CONTROl In AuTO mode, ECC controls all functions Heated driver/front passenger seat*. automatically and makes driving more pleasant Max. defroster. Directs maximum air flow to the with optimal air quality. windshield and front side windows. Turn the control to the desired temperature Blower speed. on the left/right sides of the cabin. The set temperature is shown in the display. Air distribution. Press to automatically control the tempera- Heated rear window and door mirrors. ture and other functions. Recirculation. Air conditioning Off/On to cool the cabin and defog the windows. STORAGE SPACES, 12-vOlT SOCKETS & AuX/uSB CONNECTOR The function in 12-volt sockets in the cabin CAuTION ignition modes I or II. Using the optional 12-volt socket in the trunk The always functions.

  • Page 5: Steering Wheel Adjustment

    ODOMETER AND TRIP COMPuTER The display shows two separate trip odome- ters, T1 & T2. Fuel gauge The fuel filler door is on the right, as indica- ted by the arrow. Low fuel level indicator When the symbol illuminates, refuel as soon Press to display or erase a message. as possible. Turn to show trip computer information Trip computer display. Select function with alternatives. (8). A short press resets the current function. Clock: Adjust in the MY CAR menu system A long press resets all functions. or with control (6). NOTE Multi-function control Turn the control clockwise or counterclock- The display text Miles to empty tank is an wise to set the clock. approximation, based on recent average fuel A short press toggles between T1 & T2. consumption. A long press resets the displayed odometer. Setting the clock: turn as far as possible and continue turning until a click is audible. STEERING WHEEl ADjuSTMENT BluETOOTH Make the cell phone discoverable/visible. Press the TEl button on the center console control panel briefly.

  • Page 6: Driver Support Systems

    lIGHTING PANEl Display & instrument panel lighting. Front fog lights. Rear fog light (driver’s side only). High beam flash Automatic headlights. only Parking lights. turn off when ignition is Headlights: switched off, high/low beams Open the fuel filler door. High beam flash Press once to unlock the trunk, press twice to pop open the trunk slightly. Toggle between high/low beams. Home safe lighting. DRIvER SuPPORT SYSTEMS WARNING The driver is always responsible for operating the vehicle correctly and for keeping a safe distance to the vehicle ahead. City Safety™ is a supplemental aid to the driver. It can never replace his/her attention to traffic con- ditions or responsibility for operating the vehicle in a safe manner. Pedestrian detection does not provide warnings and braking action at speeds above 50 mph (80 km/h). It does not function in darkness and in tunnels and cannot detect pedestrians who are partially hidden, who are less than 32 in. (80 cm) tall or who are wearing clothing that obscures the CITY SAFETY™ AND COllISION WARNING contours of their bodies.

  • Page 7: Electric Parking Brake

    ADjuSTING THE FRONT SEAT Lumbar support. Backrest tilt. Raise/lower the seat. Raise/lower the front edge of the seat cushion. Forward/rearward. Folding down the passenger’s seat back- rest. WINDSHIElD WIPERS AND RAIN SENSOR* Single wiper sweep. Turn (2) to adjust. Intermittent wipers. Normal wiper speed. High wiper speed. Windshield/headlight washers. Displayed when the rain sensor is active. Rain sensor On/Off with the lever in the 0 position. Turn to adjust intermittent wiper speed or rain sensor sensitivity where applicable. ElECTRIC PARKING BRAKE Setting – Press the button. The light flashes until the park- ing brake is fully applied, then glows continu- ously. Releasing Ignition mode 0 or higher. Press the brake pedal and pull the button gently. Release automatically – Select a gear and begin driving. The parking brake will release automatically (the driver’s seat belt must be fastened).

  • Page 8: Quick Guide

    VOLVO S80 Quick guide WElCOME TO THE GlOBAl FAMIlY OF vOlvO OWNERS! Getting to know your new vehicle is an exciting experience. This Quick Guide provides a brief overview of the most common features and functions in your Volvo. However, for the most up-to-date and detailed descriptions and instructions, as well as important warnings and other information not included in this folder, please refer to your Owner’s Manual.
