Heartland The Artisan Installation And Operating Instructions Manual

Heartland appliances woodstoves installation and operating instructions classic dual fuel 48" model
Hide thumbs Also See for The Artisan:
Table of Contents

Advertisement

Quick Links

See also: Installation Instructions and Operating Manual
Business (59) 650-5775 Fax (519) 650-3773 Toll Free Phone: 1-877-650-5775 Toll Free Fax: 1-800-327-5609
SAVE ThESE
INSTRUCTIONS
fOR fUTURE USE
Note: Please read these instructions
thoroughly before attempting to
install this unit.
SAfETY NOTICE: If this stove is not properly installed,
a house fire may result, for your safety, follow the
installation directions, contact local building or fire
officials about restrictions and installation inspection
requirements in your area.
IMPORTANT: Check around oven chamber on a
weekly basis for soot and creosote accumulation.
Clean the chamber thoroughly from the top, side
and bottom with the rake provided. Burn the stove
hot daily to reduce creosote accumulation. Use only
dry wood aged for one year. failure to do so could
result in chimney fire and void the warranty.
OVERfIRING CAUTION:
Repeated or extended overfiring
will void warranty on this appliance.
See page 8 for details.
PLEASE NOTE: Specifications contained in this manual are subject to change with out notice
Manual #1705 051502
1050 Fountain St N. Cambridge, Ontario, Canada N3H-4R7
The Artisan is listed to
ULC Standard S-627 & UL
1482 by Warnock Hersey
P r o f e s s i o n a l
S e r v i c e s
© 2006 HEARTLAND APPLIANCES INC.
WOODSTOVES
ATTENTION INSTALLER: Leave this manual with appliance
INSTALLATION
AND OPERATING
INSTRUCTIONS
The Artisan
The temperature registered by the oven door
thermometer may not necessarily correspond with the
reading taken with a thermometer inside the oven.


Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the The Artisan and is the answer not in the manual?

Questions and answers

Related Manuals for Heartland The Artisan

Summary of Contents for Heartland The Artisan

  • Page 1 1050 Fountain St N. Cambridge, Ontario, Canada N3H-4R7 Business (59) 650-5775 Fax (519) 650-3773 Toll Free Phone: 1-877-650-5775 Toll Free Fax: 1-800-327-5609 The Artisan is listed to ULC Standard S-627 & UL 1482 by Warnock Hersey P r o f e s s i o n a l...

  • Page 2: For Your Safety

    — fOR YOUR SAfETY— DO NOT STORE OR USE GASOLINE OR OThER fLAMMABLE VAPOURS OR LIQUIDS IN ThE VICINITY Of ThIS STOVE. Stove Location - If the stove must be located near a window, avoid using long curtains which could blow over the stove top, causing a fire hazard. Any openings in the wall behind the stove or in the floor under the stove must be sealed.
  • Page 3 CONSUMER WARRANTY ENTIRE PRODUCT –LIMITED ONE YEAR WARRANTY HEARTLAND warrants the replacement or repair of all parts of the Artisan which prove to be defective in mate- rial or workmanship. Painted porcelain enamel finish or plated surfaces have a 90 day warranty from the date of original purchase.

  • Page 4: Table Of Contents

    ) Welcome……………………………………………………………...…………..Pg 5 ) Installation……………………………………………………………...………...Pg 6 ) Installation Requirements...Pg 7 4) Clearances Single Wall Stove Pipe..……………………………...………..Pg 8 5) Clearances Double Wall Stove Pipe.……………………………...………..Pg 9 6) Installing the Chimney Connector…………………………….…...………..Pg 0 7) Chimney and Draft...Pg. 8) floor Protection...Pg. 9) User Instructions.………………………………………………………...……..Pg  0) Door Operation…………………………………………………...……………...Pg  ) Lighting the fire……………………………………………………...………….Pg  ) Refueling………………………………………………………………...………..Pg  ) Break-In fire...………………………………………………………...………….Pg 5 ) flue way Cleaning…...………………………………………………………….Pg 6 5) fresh Air Kit……………...……………………………………………………….Pg 7 6) Understanding Combustion……...…………………………………………...Pg 7 17) Over firing.………………………………………………...………………………Pg 18 8) Trouble Shooting….………………………………………...…………………...Pg 8 9) Contact Information...…..…………………………..……...……………...Pg  TABLE Of CONTENTS...

  • Page 5: Getting Acquainted

    The test standards are ULC S-627for Canada and UL 1482 for U.S. The Artisan is listed for burning wood only. Do not burn other materials or garbage. The Artisan is not listed for installation in mobile homes. Do not install the stove in mobile homes.

  • Page 6: Installation

    Place the stove in the intended position and lift out the hotplate, checking that the joint between the underside of the hob and the top of the stove is intact. Any joints which have opened should be made good with the fire cement provided.

  • Page 7: Installation Requirements

    Due to continuing product improvements, Heartland Appliances reserves the right to amend specifications without notice. Please contact Heartland for the most up to date information, as it applies to product being purchased, or download latest Site Preparation Specifications from www.heartlandapp.com.

  • Page 8: Clearances Single Wall Stove Pipe

    Clearances to Combustibles Single Wall Chimney Connector All measurementrs must be done before starting the intsallation. All drawings are for reference only, showing approximate dimensions for rough-in purposes.Ins ome installations, two or more clearances to combustible walls may contradict each other. The clearance with the greater numerical value is to be used Dimensions Non combustible hearth must extend 8 inches (203mm) to the sides and back of the unit.

  • Page 9: Clearances Double Wall Stove Pipe

    Clearances to Combustibles Listed Double Wall Chimney Connector All measurementrs must be done before starting the intsallation. All drawings are for reference only, showing approximate dimensions for rough-in purposes.Ins ome installations, two or more clearances to combustible walls may contradict each other. The clearance with the greater numerical value is to be used Dimensions Non combustible hearth must extend 8 inches (203mm) to the sides and back of the unit.
  • Page 10 MUST be fully relined with a listed solid fuel chimney liner. horizontal Connection The Heartland Artisan has the ability to connect stove pipe out the top of the flue box vertically or out the back of the flue box horizontally.

  • Page 11: Chimney And Draft

    Recommended Chimney Clearances The chimney must: 1) extend at least 14 ft. above the collar of the stove. 2) extend at least 3 ft. above the point where it passes through the roof. 3) be at least 2 ft. above anything within a 10 ft.

  • Page 12: User Instructions

    Any air inlet grilles must be maintained so that they are free from blockage. Failing to maintain your stove properly can lead to a chimney fire. Chimney fires occur when combustible deposits on the inner walls of the chimney ignite. These combustible deposits, called “creosote”, are a natural...

  • Page 13: Door Operation

    CAUTION- ThESE DOORS ARE EXTREMELY hOT DURING OPERATION. USE ThE UTENSIL PROVIDED TO OPEN AND CLOSE ThE DOORS (See figure Below). Slowly open the doors to allow the stove to clear of smoke. To open the doors. Use the utensil provided to turn door release screw 1/4 turn counterclockwise. Screw will back off enough to open door.It is not possible to open lower door without first opening upper door.

  • Page 14: Refueling

    A correctly fueled fire will last a minimum of 2 hours burning wood when maintaining the maximum rated output of the stove with intermittent cooking periods included. Once refueling has been completed, close the firebox door immediately and open only for refueling charges.

  • Page 15: Break-In Fire

    This results in most of the heat being wasted up the chimney. The flue chamber box has a removeable door on the front for cleaning access to the flueway. The stove is not to be operated with this door removed. This could result in a dangerous backdraft condition.

  • Page 16: Flueway Cleaning

    Damaged firebricks should be replaced as soon as possible but it may be temporarily repaired with stove cement. The firebricks fitted to the Heartland Artisan are of first quality manufacture, and providing the stove has been installed and used correctly will have a reasonable life.

  • Page 17: Fresh Air Kit

    Using an outside source for combustion air has its advantages. If your home is tight and well insulated, the fire in the stove may be “starved” of combustible air, it will be difficult maintaining a fire, and you may have back drafting problems.

  • Page 18: Over Firing

    See page 20, "What to do if you have a chimney fire" 6. During operation, if any parts of the stove or pipe begin to glow the stove is overfired. Do not add fuel. Close all doors, dampers and draft controls completely until glowing is eliminated and safe temperatures are restored.

  • Page 19: Trouble Shooting

    This competition for air supply can make a fire slow to kindle or cause a stove to smoke when its door is opened. Chimneys are often blamed for this type of performance. Stack Effect in houses In winter, the air in houses is much warmer and, therefore, more buoyant than the outside air.
  • Page 20 can give you good advice on the suitability of an existing chimney. Masonry chimneys should be checked for deterioration including damaged bricks, crumbling and missing mortar, cracks in the drip cap at the top of the chimney, and loose flashings at the roof line. The liner should be checked for cracks and mis-alignment.

  • Page 21: Fresh Air Kit

    For our complete line of kitchen appliances, visit our website at www.heartlandapp. com or phone 1-877-650-5775 and ask to speak to a sales representative. For pricing please call your dealer, or call Heartland Appliances (519) 650-5775 or Fax (519) 650-3773...
