QuickSpecs
Overview
1. Menu
Opens, selects or exits the OSD menu.
2. Minus/ Audio
If the OSD menu is on, press to navigate
backward through the OSD menu and
decrease adjustment levels.
3. Plus/Input
If the OSD menu is on, press to navigate
forward through the OSD menu and
increase adjustment levels.
If the OSD is inactive, press to activate input
button that chooses the video signal input
(VGA or DVI).
Boost Productivity with Dual Monitor Work Solution
(Multi-monitor support depends on your PC capability. Monitors and stands are sold
separately.)
DA - 14486 Worldwide — Version 6 — July 12, 2013
HP ProDisplay P201 20-inch LED Backlit Monitor
4. OK/Auto
If the OSD menu is on, press to select the
highlighted menu item.
If the OSD menu is inactive, press to
activate the auto adjustment feature to
optimize the screen image.
5. Power
Turns the monitor on or off.
6. Power LED
White = Fully powered.
Amber = Sleep mode.
Flashing Amber = Sleep Timer mode.
Use two P201 monitors with an HP Adjustable Dual Display Stand
(AW664AA) for a small footprint, high productivity work solution.
Page 1

Advertisement

loading
Need help?

Need help?

Do you have a question about the ProDisplay P201 and is the answer not in the manual?

Questions and answers

Related Manuals for HP ProDisplay P201

Summary of Contents for HP ProDisplay P201

  • Page 1 (VGA or DVI). Boost Productivity with Dual Monitor Work Solution Use two P201 monitors with an HP Adjustable Dual Display Stand (AW664AA) for a small footprint, high productivity work solution. (Multi-monitor support depends on your PC capability. Monitors and stands are sold separately.)
  • Page 2 QuickSpecs HP ProDisplay P201 20-inch LED Backlit Monitor Overview Model: C9F26AA DA - 14486 Worldwide — Version 6 — July 12, 2013 Page 2...

  • Page 3: Technical Specifications

    Color Gamut Color Support** Can display up to 16.7 million colors *All performance specifications represent the typical specifications provided by HP's component manufacturers; actual performance may vary either higher or lower. ** With the use of FRC technology. On Screen Display Buttons or Switches Menu, Minus ("-")/Audio, Plus ("+")/Input, OK/Auto and Power...
  • Page 4 QuickSpecs HP ProDisplay P201 20-inch LED Backlit Monitor Technical Specifications User Programmable Yes (10) Modes Anti-Glare Default Color 6500 K Temperature Video/Other Inputs Plug and Play Input Connectors VGA (analog); DVI with HDCP support Input Impedance 75 Ohms Sync Input...

  • Page 5: Additional Information

    This product is in compliance with the Restrictions of Hazardous Substances (RoHS) directive – 2002/95/EC. This HP product is designed to comply with the Waste Electrical and Electronic Equipment (WEEE) Directive – 2002/96/EC. This product is in compliance with California Proposition 65 (State of California;...
  • Page 6 RoHS Directive on a worldwide basis. By July 1, 2006, RoHS substances will be virtually eliminated (virtually = to levels below legal limits) for all HP electronic products subject to the RoHS Directive, except where it is widely recognized that there is no technically feasible alternative (as indicated by an exemption under the EU RoHS Directive).
  • Page 7 HP sales office. Recycling Products returned to HP will be recycled, recovered or disposed of in a responsible manner. The EU WEEE directive (2002/95/EC) requires manufacturers to provide treatment information for each product type for use by treatment facilities. This information (product disassembly instructions) is posted on the Hewlett Packard web site at: http://www.hp.com/go/recyclers.
  • Page 8 ENERGY STAR® is a US registered mark of the United States Environmental Protection Agency. The HP Quick Release has been designed to support a maximum of up to 24 lbs (10.9 kg) for all devices mounted. Because mounting surfaces vary widely and the final mounting method and configuration may vary, mounting fasteners are not supplied (other than the VESA-compliant screws).
  • Page 9 All specifications represent the typical specifications provided by HP's component manufacturers; actual performance may vary either higher or lower. The only warranties for HP products and services are set forth in the express warranty statements accompanying such products and services. Nothing herein should be construed as constituting an additional warranty. HP shall not be liable for technical or editorial errors or omissions contained herein.
