Fujitsu SPARC Enterprise T5440 Getting Started Manual

SPARC Enterprise T5440 Server Getting Started Guide
®
This guide describes the minimum steps you must perform to get your server to power on and boot for the first time using the
preinstalled Solaris™ Operating System (Solaris OS).
SPARC Enterprise T5440 Server
FIGURE 1
Quick Setup Instructions
For quick installation and configuration, follow these steps. For more detailed information, refer to the complete online product
documentation set at:
http://www.fujitsu.com/sparcenterprise/manual/
Understand the following information before you set up the server for the first time:
Choose the best instructions for your situation – These quick setup instructions work for any networking environment, and
■
require the use of a terminal device for connectivity to a serial port. If you have a networking environment running DHCP, you
can configure your system using the Ethernet management port. To take advantage of the DHCP setup method, refer to the online
installation guide instead of these instructions.
Set aside sufficient time – Installation times vary, but if you are performing these setup instructions for the first time, plan to
■
spend about 45 to 75 minutes to complete all of these instructions. Additional time might be required for installing optional
hardware and rackmounting kits.
Gather your configuration information – During the configuration, you are prompted for time zone and networking parameters
■
that are specific to your environment. For a list of information you need, see
Obtain a terminal device – You configure this rackmountable server through the service processor (SP) using the built-in serial
■
and network management ports, and not through a graphical interface and keyboard. For more information about the terminal
device, see Step 3.
Do not apply power at this time – This system includes a service processor (SP) that is used to configure and boot the main
■
host server. To properly configure the host server and view SP messages, do not apply AC power to the server until the SP and
host networking connections are made, as described in this guide.
Shipping Contents
Quantity Item
1 Server
2 RJ-45 Ethernet cable
1 RJ-45 to DB-25 adapter (crossover)
1 RJ-45 to DB-9 adapter (crossover)
1 Wrist strap
4 Power cords (packaged separately)
1 Rackmounting kit with cable management
assembly
Step 9.
