Combi Shuttle 8087 Series Instruction Manual

Infant car seat
Hide thumbs
Table of Contents

Advertisement

Quick Links

Download this manual
Hole Punch ONLY - DO NOT Print Lines Or These Words
Keep this instruction manual for future use.
Store in the pocket at the back of the infant car seat.
© 2007 Combi USA, Inc.
Combi USA • 1962 Hwy 160 West, Suite #100 • Fort Mill, SC 29708
• For technical questions, call 1-800-992-6624
• Se Habla Español 1-803-548-6633 • Fax 1-803-548-3663
• 8:30 a.m. - 5:00 p.m. Eastern Time • Monday - Friday
• www.combi-intl.com
Instruction
Storage Pocket
SICS 09/07
Hole Punch ONLY - DO NOT Print Lines Or These Words
Shuttle
Infant Car Seat
™
Shuttle 8087 Series
INSTRUCTION MANUAL
22 lbs. or less
(10 kg o menos)
WARNING
•
Correct installation and use
can be a matter of life or death!
•
Read and understand these
instructions before using this
car seat.
•
Certified for use in motor vehicles
and aircraft.
•
Meets or exceeds all applicable
requirements of Federal Motor
Vehicle Safety Standard 213.
Para instrucciones en Español,
llamar al: 1-800-992-6624
or log onto www.combi-intl.com
