Healthrider HRTL77105 User Manual

Healthrider treadmill user's manual hrtl77105.0
Hide thumbs

Advertisement

Table of Contents

Model No. HRTL77105.0
Serial No.
Serial
Number
Decal
QUESTIONS?
As a manufacturer, we are com-
mitted to providing complete
customer satisfaction. If you
have questions, or if parts are
damaged or missing, PLEASE
CONTACT OUR CUSTOMER
SERVICE DEPARTMENT
DIRECTLY.
CALL TOLL-FREE:
1-888-922-4222
Mon.–Fri., 6 a.m.–6 p.m. MST
ON THE WEB:
www.healthriderservice.com
CAUTION
Read all precautions and instruc-
tions in this manual before using
this equipment. Save this manual
for future reference.
USER'S MANUAL
Visit our website at
www.healthrider.com
new products, prizes,
fitness tips, and much more!

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the HRTL77105 and is the answer not in the manual?

Questions and answers

Related Manuals for Healthrider HRTL77105

Summary of Contents for Healthrider HRTL77105

  • Page 1 Model No. HRTL77105.0 Serial No. Serial Number Decal QUESTIONS? As a manufacturer, we are com- mitted to providing complete customer satisfaction. If you have questions, or if parts are damaged or missing, PLEASE CONTACT OUR CUSTOMER SERVICE DEPARTMENT DIRECTLY. CALL TOLL-FREE: 1-888-922-4222 Mon.–Fri., 6 a.m.–6 p.m.

  • Page 2: Table Of Contents

    HOW TO FOLD AND MOVE THE TREADMILL ........

  • Page 3: Important Precautions

    11. Use only a single-outlet surge suppressor that meets all of the specifications described on page 10. To purchase a surge suppressor, see your local HealthRider dealer or call the toll- free telephone number on the front cover of this manual and order part number 146148, or see your local electronics store.
  • Page 4 SAVE THESE INSTRUCTIONS The decals shown here have been placed on the treadmill. If a decal is missing, or if it is not legible, call the toll-free telephone number on the front cover of this manual and order a free replacement decal.

  • Page 5: Before You Begin

    H 550i number and serial number before calling. The model number of the treadmill is HRTL77105.0. The serial number can be found on a decal attached to the tread- mill (see the front cover of this manual for the location).

  • Page 6: Assembly

    This is a normal condition and does not affect treadmill performance. If there is lubricant on top of the walking belt, simply wipe off the lubricant with a soft cloth and a mild, non-abrasive cleaner.
  • Page 7 2. Insert the tab on one of the Handrail Brackets (70) into the indicated slot in the right Upright (69). Attach the Handrail Bracket with a 3/4” Tek Screw (65). Attach the other Handrail Bracket (not shown) to the left Upright (not shown) the same way.
  • Page 8 THE TREADMILL FOR USE on page 21). 8. Make sure that all parts are properly tightened before you use the treadmill. Note: Extra hardware may be included. Keep the included allen wrench in a secure place; the allen wrench is used to adjust the walking belt (see page 23).

  • Page 9: How To Use The Chest Pulse Sensor

    If heart rate readings do not appear until you begin perspiring, rewet the electrode areas. • As you walk or run on the treadmill, position your- self near the center of the walking belt. For the console to display heart rate readings, the user must be within arm’s length of the console.

  • Page 10: Operation And Adjustment

    (see drawing 1 at the right). To purchase a surge sup- pressor, see your local HealthRider dealer or call the toll-free telephone number on the front cover of this manual and order part number 146148, or see your local electronics store.

  • Page 11: Features Of The Console

    When the manual mode of the console is selected, you can change the speed and incline of the treadmill with the touch of a button. As you exercise, the console will display continuous exercise feedback. You can even measure your heart rate using the hand- grip pulse sensor or the chest pulse sensor.

  • Page 12: How To Turn On The Power

    Next, stand on the foot rails of the treadmill. Find the clip attached to the key (see the drawing on page 11), and slide the clip onto the waistband of your clothes.
  • Page 13 Step onto the foot rails, press the Stop button, and adjust the incline of the treadmill to the lowest setting. The incline must be at the lowest setting when the treadmill is folded to the storage posi- tion or the treadmill will become damaged.
  • Page 14 If the speed and/or in- cline of the treadmill is about to change, the speed setting and/or the incline setting will flash in the display to alert you.

  • Page 15: How To Create A Custom Program

    When the program ends, make sure that the in- cline of the treadmill is at the lowest setting. Next, remove the key from the console and put it in a safe place. Note: If the display remains lit after the key is removed, the console is in the “demo”...

  • Page 16: How To Use A Custom Program

    HOW TO USE A CUSTOM PROGRAM Insert the key into the console. See HOW TO TURN ON THE POWER on page Select one of the custom programs. To select a custom program, press Custom & Heart Rate Control Programs button repeatedly; “P-11”...

  • Page 17: How To Use A Heart Rate Program

    HOW TO USE A HEART RATE PROGRAM CAUTION: If you have heart prob- lems, or if you are over 60 years of age and have been inactive, do not use the pulse pro- grams. If you are taking medication regularly, consult your physician to find whether the medication will affect your exercise heart rate.
  • Page 18 Speed or Incline buttons. However, when the console compares your heart rate to the target heart rate setting, the speed of the treadmill may automatically change to bring your heart rate closer to the target heart rate setting.
  • Page 19 THE INFORMATION MODE/DEMO MODE The console features an information mode that keeps track of treadmill usage information. The information mode also allows you to select miles or kilometers as the unit of measurement and to turn on and turn off the demo mode.

  • Page 20: How To Fold And Move The Treadmill

    2. Move your right hand to the position shown and hold the treadmill firmly. Using your left hand, pull the latch knob to the left and hold it. Raise the treadmill until the catch is aligned with the pin on the latch knob. Slowly release the latch knob.
  • Page 21 HOW TO LOWER THE TREADMILL FOR USE 1. Hold the upper end of the treadmill with your right hand as shown. Using your left hand, pull the latch knob to the left and hold it. Pivot the treadmill down until the frame is past the pin on the lock knob.

  • Page 22: Troubleshooting

    PROBLEM: The power turns off during use SOLUTION: a. Check the circuit breaker located on the treadmill frame near the power cord (see c. above). If the circuit breaker has tripped, wait for five minutes and then press the switch back in.
  • Page 23 SOLUTION: a. With the key in the console, press one of the Incline buttons. While the incline is changing, re- move the key. After a few seconds, reinsert the key. The treadmill will automatically rise to the maximum incline level and then return to the minimum level. This will recalibrate the incline.
  • Page 24 PROBLEM: The chest pulse sensor does not function properly SOLUTION: a. If the chest pulse sensor does not function properly, see CHEST PULSE SENSOR TROU- BLESHOOTING on page 9. b. If the chest pulse sensor still does not function properly, the battery should be changed.

  • Page 25: Conditioning Guidelines

    For maximum fat burning, adjust the speed and incline of the treadmill until your heart rate is near the middle number in your training zone. Aerobic Exercise If your goal is to strengthen your cardiovascular sys- tem, your exercise must be “aerobic.”...

  • Page 26: Part List

    PART LIST—Model No. HRTL77105.0 To identify the parts listed below, see the EXPLODED DRAWING in the center of this manual. Qty. Description Foot Rail Insert Foot Rail Front Roller Nut Left Foot Rail Cap Frame Pivot Bolt Frame Pivot Spacer...
  • Page 27 Left Fan Grill Extension Leg Extension Cap Incline Warning Decal Console Fan Right Cup Holder Left Cup Holder Book Holder Power Cord Grommet Frame 3/4” Screw Roller Star Washer Right Fan Grill Isolator Strip Hood Cover Idler Arm U-nut 1 1/4” Tek Screw 12”...

  • Page 30: Limited Warranty

    WHAT IS COVERED—The entire HealthRider ® H550i treadmill (“Product”) is warranted to be free of all defects in mate- rial and workmanship. WHO IS COVERED—The original purchaser or any person receiving the Product as a gift from the original purchaser.
