non-certified:
NSF & ETL listed: RM-55N Natural gas/RM-55P Propane gas
FOR YOUR SAFETY
Do not store or use gasoline or other
flammable vapors and liquids in the
vicinity of this or any other appliance.
TO THE PURCHASER
Contact your local gas supplier and
ask instructions in the event the user
smells gas. This information should
be posted in a prominent location.
RM-50N Natural gas/RM-50P Propane gas
Automatic Gas Rice Cooker
Owner's Manual
Section I: Installation Instructions
FOOD SERVICE EQ. CO., INC. • 72 BEADEL ST. • BKLYN • NY • 11222
WARNING
Improper installation, adjustment,
alteration, service or maintenance can
cause property damage, injury or
death. Read the Installation, Operat-
ing and Maintenance Instructions
thoroughly before installing or servic-
ing this equipment.
THE INSTALLER MUST
LEAVE THIS MANUAL
WITH THE UNIT AFTER
INSTALLATION.
THE CONSUMER IS TO
RETAIN THIS MANUAL
FOR FUTURE REFERENCE.
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for RiceMaster RM-50N
Summary of Contents for RiceMaster RM-50N
-
Page 1: Section I: Installation Instructions
RM-50N Natural gas/RM-50P Propane gas NSF & ETL listed: RM-55N Natural gas/RM-55P Propane gas Automatic Gas Rice Cooker Owner’s Manual Section I: Installation Instructions FOR YOUR SAFETY WARNING Do not store or use gasoline or other Improper installation, adjustment,... -
Page 2: Component Identification
Congratulations on your purchase of your Ricemaster Automatic Gas Rice Cooker. With proper installation, care and use it should provide years of reliable service. IMPORTANT NOTE: The RM-50 is not NSF or ETL listed. However, its function and specifica- tions are identical to the RM-55. RM-55 parts are interchangeable with RM-50. Except for listings and certification, information in this manual for the RM-55 is the same as the RM-50. - Page 3 INSTALLATION INSTRUCTIONS INSTALLATION: 1. The gas supply line must be of adequate size to insure maximum efficiency of the unit. 2. The installation must conform with the National Fuel Gas Code, ANSI Z223.1, Natural Gas Installation Code, CAN/CGA-B149.1 or the Propane Installation Code, CAN/CGA-B149.2, as applicable, including: a.
-
Page 4: Lighting And Shutdown Instructions
LIGHTING AND SHUT DOWN INSTRUCTIONS LIGHTING AND SHUT DOWN INSTRUCTIONS LIGHTING AND SHUT DOWN INSTRUCTIONS LIGHTING AND SHUT DOWN INSTRUCTIONS LIGHTING AND SHUT DOWN INSTRUCTIONS Always follow these lighting and shutdown instructions when lighting your rice cooker. A five minute complete shutoff period is required before lighting or relighting pilot. - Page 5 OPTIONAL REAR CONNECTION KIT RM-55N RC Kit for Natural Gas RM-55P RC Kit for Propane Gas This kit allows the rice cooker to be connected from the rear; It is optional and is not furnished with the rice cooker unless ordered. Each kit includes: 1-3/4”...
-
Page 6: Section Ii: Operating & Maintenance Instructions
RM-50N Natural gas/RM-50P Propane gas NSF & ETL listed: RM-55N Natural gas/RM-55P Propane gas Automatic Gas Rice Cooker Owner’s Manual Section II: Operating & Maintenance Instructions FOR YOUR SAFETY WARNING Do not store or use gasoline or other Improper installation, adjustment,... -
Page 7: Operating Instructions
OPERATING INSTRUCTIONS 1. Make sure the unit is properly assembled with drip tray, outer jacket, rice pot and cover in their proper positions. The rice should be in the pot prepared by the methods described on page 8. If the components are not properly seated, the unit cannot operate normally. 2. - Page 8 HOW TO USE YOUR RICE COOKER ASSEMBLY & COOKING ASSEMBLY & COOKING ASSEMBLY & COOKING ASSEMBLY & COOKING ASSEMBLY & COOKING Step 1: Place the Rice Pot with rice and water into the Outer Jacket. Make sure that the Rice Pot is level and sitting evenly in the jacket.
- Page 9 HOW TO USE YOUR RICE COOKER RICE PREPARATION RICE PREPARATION RICE PREPARATION RICE PREPARATION RICE PREPARATION 1. Measure rice with measuring cup provided. This unit will cook a maximum of 15 pounds of dry rice. Uncooked rice volume triples after cooking. 2.
-
Page 10: Troubleshooting
TROUBLE SHOOTING If your rice cooker is not working automatically, perform the following diagnostic tests: 1. With the pilot lit and an empty rice pot in the cooker, start the main burner. Expect to hear a click after 3 minutes and 15 seconds. The click is the sound of the sensor reach- ing shut off temperture. - Page 11 TROUBLE SHOOTING CAUSE REMEDY DIFFICULTY Pilot and Main Burner Spillage on Pilot Clean or replace pilot burner Shut off while cooking Pilot orifice clogged Clean or replace pilot orfice Insufficient gas pressure Check gas pressure. Insure all gas valves are open Sensing Element is worn out Replace Sensing Element per...
- Page 12 PARTS DIAGRAM: RM-55N Natural Gas & RM-55P Propane Gas FOOD SERVICE EQUIP. CO., INC. • 72 BEADEL ST. • BKLYN • NY 11222...
- Page 13 PARTS DIAGRAM: RM-55N Natural Gas & RM-55P Propane Gas (718)388-5650 (800) 221-5032 except NY fax: (718)388-5860 townfood.com...
- Page 14 PARTS DIAGRAM: RM-55N Natural Gas & RM-55P Propane Gas PARTS LIST: RM-55N Natural Gas & RM-55P Propane Gas Dwg no. Part no. Description 56881 Cover Handle, Heat Resistant 56882 Stainless Steel Rice Pot Cover 56881-S Cover Handle Screw 56853 Cast Aluminum Rice Pot 56855 Sensing Element, Bimetalic 56856...
-
Page 15: Limited Warranty
LIMITED WARRANTY Town Food Service Equipment Co., Inc. (Town) warrants the equipment to be free of defects in materi- als and workmanship, subject to the terms specified below. This warranty is limited to parts replace- ment and does not include any labor allowance. Any service charges or charges for parts replacement are your responsibility. - Page 16 MEXICAN RICE Try Maria's Mexican Rice*, an authentic recipe from Veracruz. We brought this back from a customer of a Mexican distributor. It is simple to do and yields excellent flavors. 8 oz. vegetable or peanut oil 4 quarts cooled chicken stock 3 pounds washed rice 3 boneless chicken breasts, precooked &...
