Chassis Layout

Input Jacks – 1/4-inch phone jacks.
1
Volume I control.
2
Volume II volume control.
3
Tone controls – Treble and Bass.
4
Range Expander controls – Low and High.
5
Standby switch.
6
Power Indicator Pilot – Illuminates Red when power is on
7
and Yellow when in Standby mode.
Power connector.
8
Power switch.
9
Impedance switch..
10
Speaker Output Jacks – 1/4-inch phone jacks.
11
Speaker Attenuator switch.
12
