Summary of Contents for Husqvarna 87521RES/96143002200
- Page 1 87521RES Owner’s Manual 532 41 29-72 02.21.07 BY Printed in U.S.A.
- Page 2 ROTARY LAWN MOWER - - MODEL NUMBER 87521RES (96143002200) - PRODUCT NUMBER 961 43 00-22...
- Page 3 ROTARY LAWN MOWER - - MODEL NUMBER 87521RES (96143002200) - PRODUCT NUMBER 961 43 00-22 PART PART DESCRIPTION DESCRIPTION 532 18 87-86 Debris Shield 532 19 99-82 Handle, Upper (Includes Foam Grip) 532 19 23-25 Screw 532 19 60-05 Handle, Lower 532 15 04-06 Bolt, Engine 532 40 54-76...
- Page 4 ROTARY LAWN MOWER - - MODEL NUMBER 87521RES (96143002200) - PRODUCT NUMBER 961 43 00-22...
- Page 5 ROTARY LAWN MOWER - - MODEL NUMBER 87521RES (96143002200) - PRODUCT NUMBER 961 43 00-22 PART PART DESCRIPTION DESCRIPTION 532 40 27-90 Drive Control Assembly 532 40 91-48 Nut, Hex, Flangelock 3/8-16 532 19 57-61 Cover, Top, Drive Control 532 85 12-26 Washer 532 18 73-53 Pulley...
