C-3330-800 MW-800 FIXED MONITOR MOUNT
TOOLS REQUIRED:
Power Drill
Drill Bit Set – 1/8" through 3/8"
3/8" and ¼" Drive Standard And Metric
Socket Sets W/6" Extensions
3/8" and ¼" Ratchets
HARDWARE:
QTY DESCRIPTION
6
#8 X 1 ½" Black sheet metal screws
4
10-32 X 2 ½" Machine screws
4
10-32 Keps nuts
2
#8 X 3/8" Black Torx screws
4
10-32 x ½" Machine screws
4
#10 Flat washers
4
#10 Star washers
INSTALL INSTRUCTIONS
1996-2006 FORD CROWN VICTORIA
Phillips and Standard screwdriver set
Wire Cutters
Wire Strippers
Wire Crimping Tool
Standard And Metric Wrench Sets
PART #
GSM33136
GSM33122
GSM30028
CM86508
GSM33118
GSM31003
GSM31034
Monitor Mounting Plate
(CM93349-800)
Rear defroster filler
(CM93604)
Trunk release filler plate
(CM93603)
