- Page 1 FNP1414 FNP1514 FNP1614F FNP1614 operation & installation...
- Page 2 Power line and battery connectors. Insist on it! After all, your new system deserves nothing but the best. To add the finishing touch to your new Rockford Fosgate image order your Rockford wearables, which include everything from T-shirts and jackets to hats and sunglasses.
-
Page 3: Table Of Contents
This manual provides information on the features and installation of the fanaticP System. We suggest you save this manual for future reference. We strongly recommend you have your Authorized Rockford Fosgate Dealer install the fanaticP System. If you do choose to install the system yourself, please be sure to read the entire manual before beginning. -
Page 4: Package Contents
ACKAGE ONTENTS FNP1414 4" fanaticP Component System (2) FNP2401 Tweeters (2) .110 Female Fast-on Connectors Includes 3/4" [20mm] mylar dome (2) .110 Male Fast-on Connectors tweeter, flush mount housing, sur- (2) FNP1404 4" Midrange Speakers face mount housing, wedge mount (2) 4"... -
Page 5: Installation Considerations
2. For best results, mount the crossover(s) next to the amplifier for a deco- rative finish to the installation and provide an easy upgrade (no new wires to run) for a bi-amp Rockford Fosgate system in the future. – 3 –... -
Page 6: Mounting Location
OUNTING OCATION A solid front stage with a good image is one of the most difficult tasks to achieve in a vehicle. No car has the optimum listening environment. This makes proper sound staging very difficult to accomplish. Most speakers tend to be placed where they will fit easily, as opposed to where they can perform the best. -
Page 7: Installation
• Sound radiated from a “point source” has the most optimum stereo imaging because the separation of the acoustical centers between the midrange and tweeter for each channel is at the optimum. Figure 2-A describes a horizontal speaker alignment. In a closed environment such as an automobile, horizontal speaker alignment can cause severe amplitude and phase differences which will degrade not only the imag- ing, but also the frequency response. - Page 8 Flush Mount Tweeter Trim Back Tweeter Flush Ring Plate Housing Surface Mount Tweeter Surface Tweeter Trim Back Housing Ring Plate Wedge Mount Tweeter Tweeter Wedge Housing – 6 –...
- Page 9 Crossover Connections Midrange Positive Negative (Black Wire) – – Midrange Negative – (striped wire Positive (Black/White Stripe Wire) Tweeter Positive (One channel of amplifier) – Tweeter Negative High-Passing the Midrange The fanaticP Component Systems are optimized for full range music reproduction. In cases where a subwoofer is used, the midrange can be high-passed in order to prevent overlapping frequncies from the midrange into the subwoofer.
-
Page 10: Troubleshooting
ROUBLESHOOTING Symptom Diagnosis Remedy No sound from Wires between amplifi- Check and repair or speakers er, crossover or speak- replace wiring as needed. ers not connected properly. Amplifier has no output. Check system with known working amplifier and re- pair or replace as needed. Speaker wires are Check for shorts in the wir- shorted to each other... -
Page 11: Specifications
PECIFICATIONS System Model Number FNP1414 FNP1514 FNP1614F FNP1614 Midrange Model Number FNP1404 FNP1405 FNP1406F FNP1406 Nominal Diameter 4" ⁄ " 6" ⁄ " Nominal Impedance 4Ω 4Ω 4Ω 4Ω Frequency Response 100Hz-8kHz 60Hz-6kHz 61Hz-6kHz 55Hz-5kHz Fs (Hz) 100Hz 60Hz 61Hz 55Hz .907... -
Page 12: Warranty Information
• What is Covered This warranty applies only to Rockford Fosgate products sold to consumers by Authorized Rockford Fosgate Dealers in the United States of America or its pos- sessions. Product purchased by consumers from an Authorized Rockford Fosgate Dealer in another country are covered only by that country’s Distributor and not by Rockford Corporation. -
Page 13: International Information
– 11 –... - Page 14 Es preferible que la instalación de sistema Fanatic X sea realizada por un distribuidor autorizado Rockford Fosgate. Si prefiere realizar la instalación usted mismo, asegurese de leer el manual en su totalidad antes de comen- zar.
- Page 15 de no doblar el marco del altavoz en este proceso. 7. Presione la rejilla en el anillo de montaje. Positivo de Mediorango Negativo (cable Negro) – – – Negativo de Mediorango Positivo de Agudo Positivo (cable Negro con raya Blanca (Un canal del amplificador –...
- Page 16 Fanatic X. Nous vous proposons de garder ce manuel pour toute référence future. Nous vous recommandons vivement de faire installaer votre système punch Fanatic Q par un dealer agréé Rockford Fosgate. Si vous choisissez d'in- staller le système vous même, assurez-vous de lire ce manuel entièrement avant de commencer.
- Page 17 6. Placer le haut-parleur au-dussus du trou central. Visser le haut-parleur dans son emplacement. Faire attention à ne pas tordre le chassis du haut- parleur durant cette étape de montage. 7. Mettre la grille dans l'anneau de montage. Positif du médium Négatif (câble noire) –...
- Page 18 Einbau des Fanatic Q Systems. Wir empfehlen, diese auch für Fragen in der Zukunft sorgfältig aufzubewahren. Es ist empfehlenswert, sich das Fanatic Q System von einem Autorisierten Rockford Fosgate Fachhändler einbauen zu lassen. Sollten Sie den Einbau jedoch selber vornehmen wollen, so empfehlen wir Ihnen, die Bedienungsanleitung sorgfälitg zu lesen.
- Page 19 5. Schlieben Sie die Lautsprecherkabel an. Kontrollieren Sie, ob die Polarität stimmt. Stellen Sie sicher, dab das Lautsprecherkabel an keinen scharfen oder sich bewegenden Teilen anliegt. 6. Plazieren Sie den Lautsprecher im Loch und befestigen Sie diesen. Seien Sie dabei sehr vorsichtig, so dab sich der Lautsprecherkorb nicht verzieht.
- Page 20 Fanatic Q. Vi suggeriamo di conservare questo manuale come riferimento futuro. Raccomandiamo fortemente che is sistema sia installato dal vostro rivendi- tore Rockford Fosgate. Se scegliete di procedere con l'installazione da soli, leggete attentamente tutto il manuale prima di proseguire. OSIZIONAMENTO •...
- Page 21 6. Posizionate l'altoparlante nel foro ed avvitatelo. Assicuratevi di non pie- gare il cestello dell'altoparlante. 7. Incastrate la griglia sull'anello di fissaggio. Positivo Midrange Negativo (cavo nero) – – Negativo Midrange – Positivo (cavo nero/bianco) Positivo Tweeter (Un canale dell’amplificatore) –...
- Page 22 Rockford Fosgate Rockford Corporation 546 South Rockford Drive Tempe, Arizona 85281 U.S.A. In U.S.A., (480) 967-3565 In Europe, Fax (49) 8503-934014 In Japan, Fax (81) 559-79-1265 www.rockfordfosgate.com...
