Technical specifications – AXIS 232D+ Network Dome Camera
Camera
Models AXIS 232D+ 60 Hz
AXIS 232D+ 50 Hz
Image sensor 1/4" Exview HAD CCD
Lens
f=4.1 – 73.8 mm, F1.4 – 3.0, autofocus, manual/automatic
day/night
Horizontal angle of view: 48° – 2.8°
Minimum
Color: 0.3 lux at 30IRE F1.4
illumination
B/W: 0.005 lux at 30IRE F1.4
Shutter time
1/10000 s to 1 s
Pan/Tilt/Zoom
18x optical and 12x digital zoom , total 216x zoom
Pan: 360° endless, 360°/s pan speed
Tilt: 0° – 90° (± 3°), 360°/s tilt speed
20 preset positions
Guard tour
Supports Windows compatible joysticks
Video
Video MPEG-4 Part 2 (ISO/IEC 14496-2)
compression Motion JPEG
Resolutions
704x480 to 176x120 (60 Hz)
704x576 to 176x144 (50 Hz)
Frame rate Up to 30/25 fps (60/50 Hz) at 2CIF/CIF/QCIF
MPEG-4
Frame rate
Up to 30/25 fps (60/50 Hz) in all resolutions
Motion JPEG
Video streaming Simultaneous MPEG-4 and Motion JPEG
Controllable frame rate and bandwidth
VBR/CBR MPEG-4
Image settings
WDR (Wide Dynamic Range), compression, brightness,
sharpness, white balance, exposure control
Text and image overlay
De-interlacing
Dimensions
131.5 mm (5.2")
143.5 mm (5.6")
131.5 mm (5.2")
180 mm (7.1")
131.5 mm (5.2")
143.5 mm (5.6")
143.5 mm (5.6")
©2011 Axis Communications AB. AXIS COMMUNICATIONS, AXIS, ETRAX, ARTPEC and VAPIX are registered trademarks or trademark applications of Axis AB
in various jurisdictions. All other company names and products are trademarks or registered trademarks of their respective companies. We reserve the right
to introduce modifications without notice.
180 mm (7.1")
187 mm (7.4")
180 mm (7.1")
187 mm (7.4")
Network
Security
Password protection, IP address filtering, HTTPS encryption,
IEEE 802.1X network access control
Supported IPv4/v6, HTTP, HTTPS, QoS Layer 3 DiffServ, FTP, SMTP, Bonjour,
protocols UPnP, SNMPv1/v2c/v3 (MIB-II), DNS, DynDNS, NTP, RTSP, RTP,
TCP, UDP, IGMP, RTCP, ICMP, DHCP, ARP, SOCKS
System integration
Application Open API for software integration, including VAPIX®
Programming
from Axis Communications available at www.axis.com
Interface
Intelligent video Video motion detection
Alarm triggers
Intelligent video and external input
Alarm events File upload via FTP, HTTP and email
Notification via email, HTTP and TCP
External output activation
Video buffer
9 MB pre- and post alarm
General
Processors and
ETRAX 100 LX, ARTPEC-2, 32MB RAM, 8MB Flash
memory
Power 24 – 36 V DC, max 28 W
19 – 28 V AC, max 25 VA
Connectors
RJ-45 Ethernet 10BASE-T/100BASE-TX PoE,
Terminal block for 4 alarm inputs and 4 outputs
Operating 5 – 50 °C (41 – 122 °F)
conditions
Humidity 20 – 80% RH (non-condensing)
Approvals
EN 55022 Class B, EN 55024, EN 61000-3-2, EN 61000-3-3,
FCC Part 15 Subpart B Class A, VCCI Class A, ICES-003 Class A,
C-tick AS/NZS CISPR 22 Class A, EN 60065
Power supply: EN 60950-1, UL, CSA
Weight
1.8 kg (4.0 lb)
Included Power supply, mounting brackets for hard and drop ceiling
accessories mount, smoked and transparent covers, Installation Guide, CD
with installation tools, recording software and User's Manual,
Windows decoder 1-user license
More information is available at www.axis.com

Optional accessories

187 mm (7.4")
Various housings
AXIS T8310
Video Surveillance Control Board
For information on AXIS Camera Station and
video management software from
Axis' Application Development Partners,
see www.axis.com/products/video/software/
Outdoor mains power
adaptor
AXIS T90A Illuminators
