Allied Telesis AT-9424Ts/XP Datasheet

Datasheet | Switches
AT -9424Ts/XP
24 Port 10/100/1000T Managed Layer 3 Switch with 2 10GbE XFP Bays
and a Stacking Module Expansion Bay with 48Gbps Stack Backplane
AT -9424Ts/XP
Layer 3 stackable switch with 20 port
10/100/1000T, 4 x 10/100/1000T / SFP
combo ports plus 2 XFPs bays
(unpopulated) and AT-StackXG module bay
Product Overview
The AT-9424Ts/XP is a Layer 3 Gigabit Ethernet
(10/100/1000) switch with built in 10GbE
front-side XFP bays for 10Gbps backbone
connectivity. It is the ideal 10GbE backbone
gateway at the edge and aggregation tiers of
the network. It comes in a 1RU form factor
and provides rich QoS and IGMP capabilities
for voice and video enabled networks.
The relative affordability of the AT-9424Ts/XP
makes 10GbE backbones a reality for small to
medium enterprises. It offers an extensive set
of standards-based features to ensure ease
of management and integration into existing
networks.
Built-in 10GbE Bays
The AT-9424Ts/XP switch is designed to meet
the growing bandwidth needs that advanced
applications and connectivity options are
requiring of networks. It features two built-in
bays for 10 Gigabit Ethernet connectivity to
provide an excellent uplink subscription ratio
(1.2 to 1 using both bays). No additional
module is required to house the XFP
transceivers. It provides an extraordinary
amount of bandwidth capacity making it an
ideal investment for organizations that seek 7 to
10 years of service or more from their
switches.
Allied Telesis
Resilient Ring Stacking
The AT-9424Ts switch is designed to meet the
growing bandwidth needs that advanced
applications and connectivity options are
requiring of networks. It features a stacking
expansion bay capable of tapping in 48Gbps of
stacking bandwidth.This switch can also be
stacked with 10Gbps capable 9400s switches to
further improve network performance while
keeping costs down. It provides high bandwidth
capacity making it an ideal investment for
organizations that seek 7 to 10 years of service
or more from their switches.
Management Stacking
Enhanced Stacking TM provides CLI-based
management of up to 24 switches with the
same effort as for one switch.The Allied Telesis
solution uses open standards ethernet
interfaces as stacking links so that many
switches can be remotely stacked across
different sites.
Network QoS and IGMP for Video
and Voice-over-IP
A rich offering of voice and video networking
features is incorporated to ensure support for
demanding multimedia networking applications
in the enterprise. Converged networking is
enhanced with QoS/CoS including eight priority
queues for IEEE 802.1p/ToS/DiffServ traffic.
The high performance hardware platform
makes latency a non-issue.The IGMP
implementation on the AT-9424Ts/XP is
capable of transmitting broadcast quality video
throughout the enterprise network.
Key Features
10 Gigabit Ethernet Support
• Two integrated XFP bays for 10GbE
Stacking
• Simplified management
• Up to 48Gbps stacking bandwidth
• Remote 'Enhanced Stacking' of up to 24
switches
Layer 3 Support
• RIPv2
• Static routing
• ECMP
Performance
• Non-blocking, line rate switching for all
packet sizes
• Switch fabric 136Gbps
• Stacking bandwidth 48Gbps
• 4K VLANs (static and dynamic)
• 256 static Layer 2 multicast groups
• 255 dynamic Layer 2 multicast groups
• 9K jumbo frame support
Layer 2-4 Intelligence
• Packet inspection and classification at MAC, IP,
TCP/UDP layers
• Set QoS, ACL, mirroring, and rate-limiting
using traffic classes
Security
• DoS attack protection
• Radius/TACACS+
• Port security
• SSH/SSL
• IEEE 802.1x
• Access Control Lists
Advanced Services
• Rate limiting (ingress and egress)
• 8 QoS service levels
• IEEE 802.1p for MAC-based QoS
• DSCP for IP-based QoS
Resiliency
• IEEE 802.1s Multiple STP
• IEEE 802.3ad link aggregation
• IEEE 802.1D Spanning-Tree
• IEEE 802.1w Rapid STP
• Temperature threshold alert
Management
• Telnet
• Web GUI
• CLI
• Dedicated management port
• Compact flash slot
