UNDERCOUNTER MOUNTING FOR CULINAIRE™
COLLECTION STAINLESS STEEL
KITCHEN SINKS
MODELS 7501.000, 7502.000, 7504.000, 7507.000
Thank you for selecting American-Standard...the
benchmark of fine quality for over 100 years.
To ensure that your installation proceeds smoothly--
please read these instructions carefully before you begin.
BEFORE YOU BEGIN...
Unpack new sink and inspect carefully for damage. Notify your American Standard distributor of any damage. Replace the
sink in its original packing carton to protect it until you are ready to begin installation.
Recommended Tools & Materials:
Putty Knife
Pipe Wrench
Channel Lock Pliers
Phillips Screwdriver
Regular Screwdriver
Adjustable Wrench
Drill
CAUTION
Minimum countertop thickness is 12mm (1/2") for marble and solid surface material.
SINK CUTOUTS:
Locate and mark center lines of sink on countertop. Provide proper clearance under the countertop for the faucet
supply lines and the structural parts of the cabinet. Do not use permanent markers to indicate the center lines.
Cut the inner portion from the supplied template and discard.
Attach the outer portion of the template to the countertop using masking tape. Be sure that the center lines on
the template are aligned with those on the counter.
A. After cutout is complete, mark underside of countertop at approximate locations shown in 1 for appropriate
model. Locate holes 1" back from cutout edge. Drill 1/4" diameter holes ('E' drill) 1/4" deep for brass inserts.
Tap in brass inserts, slotted end first.
B. Some products are supplied with a plastic film. This film protects the product during the shipping and has to be
removed before mounting. Apply sealant to mounting surface.
C. Mount hardware shown in Step 3 by first threading wingnut well up on screw near the head with washer and
slotted clip. Tighten screw securely to lock brass insert.
When sink is correctly positioned over cutout, tighten wing nuts evenly to secure sink.
(Refer to Step 3 on page 3.)
Installation
™
Instructions
Basin Wrench
Saber Saw
Plumbers' Putty or Caulking
Tubing Cutter
Tape Measure
Hacksaw
Mineral Spirits
Silicone Sealant
STAINLESS STEEL SINKS
Certified to comply with ANSI A112.19.3.M
CAN/C.S.A. B-45
Observe local plumbing and building codes.
1
7 9 0 7 6 6 - 1 0 0
© A M E R I C A N S T A N D A R D I N C . 2 0 0 2
