Summary of Contents for Zanussi ZAF2
-
Page 2: For Your Safety
Repairs carried out by installing a cooker hood with discharge tube. unexperienced persons may cause injury or serious malfunctioning. Refer to your local Zanussi Service • In case of intensive or long time use of the Centre. Always insist on genuine Zanussi spare appliance, make the ventilation more efficient, parts. -
Page 3: Table Of Contents
Contents 1. Instruction for the User ..... Pag. 5. Electrical Connection ....Pag. 6. Adaptation to different 2. Cleaning and Maintenance ..Pag. types of gas........ Pag. 3. Technical Data ......Pag. 7. Building In ........Pag. 4. Instruction for the Installer ..Pag. Guarantee ........ -
Page 4: Cleaning And Maintenance
2. Cleaning and Maintenance • Disconnect the appliance from the electrical supply, before carrying out any cleaning or manteinance work. Wash the enamelled components with warm soapy water. Never use abrasive cleaners Frequently wash the "caps" and the "crowns" with hot soapy water, carefully taking away any built-up of food. -
Page 5: Instruction For The Installer
4. Instruction for the Installer The side walls of the unit in which the hob is GAS CONNECTION going to be installed, must not exceed the height It is indispensible that the connection to the gas mains of the working top. are carried out by means of an AGB tap. -
Page 6: Electrical Connection
5. Electrical Connection The appliance is designed to be connected to 230 V monophase electricity supply. The connection must be carried out in compliance with the laws and regulations in force. Before the appliance is connected: 1) check that the main fuse and the domestic installation can support the load (see the rating label);... -
Page 7: Adaptation To Different Types Of Gas
6. Adaptation to different types of gas INJECTORS REPLACEMENT • Remove the pan supports. • Remove the burner's caps and crowns. • With a socket spanner 7 unscrew and remove the injectors (Fig. 7), and replace them with the ones required for the type of gas in use (see table 2). -
Page 8: Building In
7. Building In A = Auxiliary burner R = Rapid Burner These hobs can be inserted in a built-in kitchen unit whose depth is between 550 and 600 mm. The hobs dimensions are shown in Fig. 9. FO 0952 Fig. 9 Paroi arrière INSTALLATION AND ASSEMBLY These hobs can be installed in a kitchen unit with an... - Page 9 Fig. 13 Fig. 12 POSSIBILITIES FOR INSERTION Kitchen unit with door Proper arrangements must be taken in designing the forniture unit, in order to avoid any contact with the bottom of the hob which can be heated when it is operated. The recommended solution is shown in Fig.
