Summary of Contents for Princeton SENERGY2383

  • Page 2: Fcc Information

    FCC Information This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation.

  • Page 3: Important Safety Instructions

    Important Safety Instructions Read the Safety Instructions carefully and keep it for later use. Beware of all warning and instruction signs marked on the products. When cleaning, cut off the electrical supply at all times. Never use liquid or aerosol detergent, use a damp rag instead.

  • Page 4: Table Of Contents

    CONTENTS Note: To access our Users Guide Homepage (Page 3) at anytime, simply click on the below Homepage icon or use the arrow icon(s) to browse through each page. When in Homepage, clicking on your desired topic will automatically open each page.

  • Page 5: Getting Started

    Getting Started Congratulations on your purchase of a TFT LCD Color Monitor. This section lists package contents, features, precautions, as well as cleaning and installation instructions. Important! Please keep the original box and all packing material for future shipping needs. Package Contents Your TFT LCD Color Monitor package includes the following: TFT LCD Color Monitor...

  • Page 6: Srs Trademark And Logo

    • SRS and the symbol are trademarks of SRS Labs, Inc. SRS technology is incorporated under license from SRS Labs, Inc. Precautions Sit at least 18"(45 cm) away from the TFT LCD Color Monitor. Do not press on the LCD panel as it is very fragile. Do not touch the LCD panel with your bare hands, as the grease from your skin is difficult to remove and may damage the screen.

  • Page 7: Quick Installation

    Quick Installation 1. Make sure the computer and the LCD monitor are both turned off. 2. Attach the power cord to the LCD monitor. 3. When using a power cord, plug the male end in a wall socket. 4. If using a PC power cord, plug the male end in the socket of the computer power supply (if equipped).

  • Page 8: Front Control Panel

    OPERATIONS To turn the TFT LCD COLOR Monitor on, push the power button at the front of the LCD monitor to active. When the power light turns green, the LCD is ready to use. To turn the LCD off, push the power switch button to de- activate the monitor.

  • Page 9: Panel Tilt

    Panel Tilt Diagram 1 Diagram 2 TILT ANGLE-BACK Diagram 2-1 Diagram 2-2 SWIVEL ANGLE-L SWIVEL ANGLE-R Diagram 1 – Illustrates the display can tilt forward or backwards. Diagram 2 – Illustrates the display can rotate left or right. Diagram 2 –1 Swivel angle left Diagram 2 –2 Swivel angle right...

  • Page 10: Osd Main Menu

    MAIN MENU The Main Menu is shown below. CONTRAST / BRIGHTNESS IMAGE ADJUST COLOR ADJUST ADVANCED MENU AUDIO MENU SETUP MENU MEMORY RECALL : EXIT : SELECT CONTRAST adjusts the difference between the image background (black level) and the foreground (white level). BRIGHTNESS adjusts the background black level of the screen image.

  • Page 11: Image Adjust Menu

    IMAGE ADJUST MENU The Image Adjust Menu is shown below. IMAGE ADJUST AUTO TUNE H. / V. POSITION H. SIZE PHASE ZOOM : EXIT : SELECT AUTO – TUNE automatically sizes, enters, and fine-tunes the video signal to eliminate noise and distortion. Press [ B ] button to activate Auto-tune.
  • Page 12 H. SIZE (Horizontal Size) adjusts the width of the screen image. H. SIZE : EXIT ] button decreases the width of the screen image, ] button increases the width of the screen image. PHASE minimizes the video distortion. PHASE : EXIT Press the [ ] or [ ] button to adjust your preference.

  • Page 13: Color Adjust Menu

    COLOR ADJUST MENU The Color Adjust Menu is shown below: COLOR ADJUST COLOR TEMPERATURE USER COLOR TEMPERATURE : EXIT : SELECT COLOR TEMP SELECT provides several color options: several preset color temperatures User Color which allows you to adjust the Red (R), Green (G), and Blue (B). The factory setting for this product is 9300K (9300 Kelvin).
  • Page 14 USER COLOR TEMP. Individual adjustments for red, green, and blue. Press [ ] button to increase red, blue or green. Press [ ] button to decrease USER COLOR TEMPERATURE Gamma Press to Enter : EXIT : SELECT GAMMA Individual adjustments for white, red, blue and green colors. Press [ ] or [ ] to select and make your adjustments.

  • Page 15: Audio Menu

    AUDIO MENU The Audio Menu is shown below. AUDIO MENU VOLUME MUTE SRS ON / OFF : SELECT : EXIT VOLUME adjusts the volume of the audio output. VOLUME : EXIT Press [ ] button to decrease the volume, [ ] button to increase the volume.

  • Page 16: Advanced Menu

    ADVANCED MENU Selecting the Advanced Menu from the main menu takes you to the submenu shown below. ADVANCED MENU SCALING SHARPNESS INFORMATION : EXIT : SELECT SCALING adjusts the video input signal to the screen size using the following options. SCALING Fill All FILL ASPECT RATIO...

  • Page 17: Setup Menu

    SETUP MENU The Setup Menu takes you to the sub-menu shown below. SETUP MENU INPUT SELECT LANGUAGE SELECT OSD POSITION OSD TIME OUT : EXIT : SELECT INPUT SELECT allows you to toggle between two input ports between an analog and digital signal.
  • Page 18 OSD POSITION allows you to move the on-screen display menus and control screens. OSD POSITION H. POSITION V . POSITION : EXIT : SELECT Press [ ] or [ ] button OSD TIMEOUT sets the length of time the on-screen display screen is displayed. For example, with a “30 second”...

  • Page 19: Specifications

    Specifications Type 23.1" (full 23.1" viewable diagonal area) TFT (Thin Film Transistor), Active Matrix Panel Pixel Pitch 0.294mm pixel pitch Color Filter Pixel RGB vertical stripe Color 16.7M (8 bit color) Glass surface Anti-Glare Response time Ton = 15 ms (Typ.), Toff = 10 ms (Typ.) Maximum Horizontal 160°...

  • Page 20: Factory Preset Timing

    Factory Preset Timing Polarity Timing Hor. Freq. (KHZ) Ver. Freq. (HZ) (H/V) VGA 640 X 350 31.47 70.08 + / - VGA 720 X 400 31.47 70.08 - / + VGA 640 X 400 31.47 70.08 - / + VGA 640 X 480 31.47 59.94 - / -...
