LASER LIGHT
AVOID DIRECT EYE EXPOSURE
CLASS 3R LASER PRODUCT
CLASSIFIED PER EN/IEC 60825-1:2007
Complies with FDA performance standards
for laser products except for deviations
pursuant to Laser Notice No. 50, dated
June 24, 2007.

User Manual

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the MiM Laser RBX and is the answer not in the manual?

Questions and answers

Related Manuals for Chauvet MiM Laser RBX

Summary of Contents for Chauvet MiM Laser RBX

  • Page 1: User Manual

    LASER LIGHT AVOID DIRECT EYE EXPOSURE CLASS 3R LASER PRODUCT CLASSIFIED PER EN/IEC 60825-1:2007 Complies with FDA performance standards for laser products except for deviations pursuant to Laser Notice No. 50, dated June 24, 2007. User Manual...

  • Page 2: Table Of Contents

    Returns Procedure ..............................15 Contact Information ..............................15 6. Technical Specifications ............................16 Contact Information World Headquarters United Kingdom & Ireland CHAUVET® CHAUVET® Europe Ltd. General Information General Information Address: 5200 NW 108th Avenue Address: Unit 1C Sunrise, FL 33351...

  • Page 3: Before You Begin

    CHAUVET®, upon receipt of the damaged merchandise. Failure to do so in a timely manner may invalidate your claim with the carrier. In addition, retain the container and all the packing material for inspection.

  • Page 4: Safety Instructions

    Safety Instructions Please read the following notes carefully because they include important safety information about the installation, usage, and maintenance of this product.  Keep this User Manual for future consultation. If you sell this product to another user, be sure that they also receive this document. ...

  • Page 5: Non Interlocked Housing Warning

    Non Interlocked Housing Warning  This unit contains high power laser devices internally.  Do not open the laser housing, due to potential exposure to unsafe levels of laser radiation.  The laser power levels, accessible if the unit is opened, can cause instant blindness, skin burns, and fires.

  • Page 6: Laser Safety Label Reproduction

    Laser Safety Label Reproduction Front Rear Bottom MiN™ Laser RBX User Manual December 2011...

  • Page 7: Laser Emission Data

    LASER EXPOSURE WARNING Laser light - Avoid direct eye contact! Further guidelines and safety programs for safe use of lasers can be found in the ANSI Z136.1 Standard “For Safe Use of Lasers”, available from the Laser Institute of America: www.laserinstitute.org.

  • Page 8: Introduction

    2. I NTRODUCTION Product Overview Mode Button Microphone Wireless Remote Receiver Indicator Laser Output 12 V Power Cooling Fan MiN™ Laser RBX User Manual December 2011...

  • Page 9: Setup

    This product includes an external power supply which is auto-ranging and runs on 100~240 VAC, 50/60 Hz power. Only use the included power supply! To obtain a replacement power supply, contact Chauvet®. To determine the power requirements for a particular product, see the label affixed to the Power Supply back plate of the product or refer to the product’s specifications chart.
  • Page 10 Floor Stand, Flexible Feet (3) Coupler Clamp MiN™ Laser RBX User Manual December 2011...

  • Page 11: Proper Usage

    Proper Usage This product is for overhead mounting only. For safety purposes, CHAUVET® recommends mounting your lighting effect products on steady elevated platforms or sturdy overhead supports using suitable hanging clamps. In all cases, you must use safety cables. You can obtain appropriate mounting hardware from your lighting vendor.

  • Page 12: Operating Instructions

    4. O PERATING NSTRUCTIONS Manual Mode Access the four different operating modes available in this product by using the <MODE> button on the front panel. Pressing and holding the <MODE> button for 2.5 seconds will turn the product on or off. Press <MODE>...

  • Page 13: Appendix

     Check cable connections  Faulty DMX interface  Replace DMX input  Faulty Main PCB  Replace Main PCB If you still have a problem after trying the above solutions, please contact CHAUVET® Technical Support. MiN™ Laser RBX User Manual December 2011...

  • Page 14: Product Maintenance

    Product Maintenance Dust build up reduces light output performance and can cause overheating. This can lead to reduction of the light source’s life and mechanical wear. To maintain optimum performance and minimize wear, you should clean your lighting products at least twice a month.

  • Page 15: Returns Procedure

    Be sure to pack the product properly. Any shipping damage resulting from inadequate packaging will be the customer’s responsibility. As a suggestion, proper UPS packing or double-boxing is always a safe method to use. CHAUVET® reserves the right to use its own discretion to repair or replace returned product(s). Contact Information World Headquarters United Kingdom &...

  • Page 16: Technical Specifications

    6. T ECHNICAL PECIFICATIONS Dimensions and Length Width Height Weight Weight 4.3 in (111 mm) 3.3 in (85 mm) 1.8 in (45 mm) 0.7 lbs (0.3 kg) Note: Dimensions in inches rounded to the nearest decimal digit Power Input Voltage Range Voltage Selection 12 VDC 600 mA...
